Solar hot water calorifer
BSL 150...400
BESL 200...400
User Guide
300028413-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BSL 150 400 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DeDietrich BSL 150 400 Series

Summary of Contents for DeDietrich BSL 150 400 Series

  • Page 1 Solar hot water calorifer BSL 150...400 BESL 200...400 User Guide 300028413-04...

  • Page 2: Table Of Contents

    Contents Safety instructions ..................4 Safety instructions ..........4 Recommendations ..........6 Liabilities ...............7 1.3.1 Manufacturer’s liability ..........7 1.3.2 Installer’s liability .............7 1.3.3 User’s liability ............8 About this manual ..................9 Symbols used ............9 2.1.1 Symbols used in the manual ........9 2.1.2 Symbols used on the equipment ......9 Abbreviations ............9 Technical description ................10 Homologations ............10...
  • Page 3 Contents Starting and stopping the control system ..18 Checking and maintenance ..............19 General instructions ...........19 Safety valve or safety unit .........19 Cleaning the casing material ......19 Checking the magnesium anode .......19 Troubleshooting ..................20 Incidents and solutions ........20 Technical specifications ................21 Solar domestic hot water calorifier ....21 Composition of the NF CESI solar systems packages (For France) ........22...
  • Page 4 08/09/2015 - 300028413-04...

  • Page 5: Safety Instructions

    BSL 150...400 BESL 200...400 1. Safety instructions Safety instructions Safety instructions DANGER This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 1. Safety instructions BSL 150...400 BESL 200...400 CAUTION Allowance must be made for a means of disconnection in the fixed pipes in accordance with the regulations on installations. CAUTION If a power cord is provided with the appliance and it turns out to be damaged, it must be replaced by the manufacturer, its after sales service or persons with similar qualifications in order to obviate any danger.

  • Page 7: Recommendations

    BSL 150...400 BESL 200...400 1. Safety instructions Recommendations WARNING Only qualified professionals are authorised to work on the appliance and the installation. Never drain the installation. Do not replace or add water or solar fluid to the installation. These actions must be carried out by a qualified technician To take advantage of the guarantee, no modifications must be made to the appliance.

  • Page 8: Liabilities

    1. Safety instructions BSL 150...400 BESL 200...400 Liabilities 1.3.1. Manufacturer’s liability Our products are manufactured in compliance with the requirements of the various applicable European Directives. They are therefore delivered with [ marking and all relevant documentation. In the interest of customers, we are continuously endeavouring to make improvements in product quality.

  • Page 9: User's Liability

    BSL 150...400 BESL 200...400 1. Safety instructions 1.3.3. User’s liability To guarantee optimum operation of the appliance, the user must respect the following instructions: 4 Read and follow the instructions given in the manuals provided with the appliance. 4 Call on qualified professionals to carry out installation and initial start up.

  • Page 10: About This Manual

    2. About this manual BSL 150...400 BESL 200...400 About this manual Symbols used 2.1.1. Symbols used in the manual In these instructions, various danger levels are employed to draw the user’s attention to particular information. In so doing, we wish to safeguard the user’s safety, highlight hazards and guarantee correct operation of the appliance.

  • Page 11: Technical Description

    BSL 150...400 BESL 200...400 3. Technical description Technical description Homologations 3.1.1. Certifications n NF certification This product complies to the requirements to the european directives and following standards: 4 2006/95/EC Low Voltage Directive. Reference Standard: EN 60.335.1. Reference Standard: EN 60.335.2.21. 4 2004/108/EC Electromagnetic Compatibility Directive.
  • Page 12 3. Technical description BSL 150...400 BESL 200...400 BSL 150: Internal view Solar exchanger Anode M003277-B BSL 200...400: External view Expansion vessel Top inspection trap Side inspection plate Solar station Solar regulator Electrical back-up (Option) Safety control unit for the solar circuit All components are checked for leaks and tested in the factory.

  • Page 13: Control Panels

    BSL 150...400 BESL 200...400 3. Technical description BESL 200...400: External view Expansion vessel Top inspection trap Side inspection plate Solar station Solar regulator Electrical back-up Safety control unit for the solar circuit All components are checked for leaks and tested in the factory.

  • Page 14: Description Of The Display

    3. Technical description BSL 150...400 BESL 200...400 3.3.2. Description of the display n System schematics (System-Screen) Solar sensor probe Solar collectors Solar circulation pump Solar exchanger Solar hot water calorifer Solar sensor Back-up (except BSL 150) DHW sensor - Back-up M002760-A n Operating indicators Steady symbol Flashing...
  • Page 15 BSL 150...400 BESL 200...400 3. Technical description n LED display LED message Heating pump status Description code Pump relay is closed. Regulation operating normally Continuously (System Operating). green Initialisation The installation is in Green/red phase manual mode: Set the flashing regulator to automatic Manual mode mode.

  • Page 16: Operating The Appliance

    4. Operating the appliance BSL 150...400 BESL 200...400 Operating the appliance Reading out measured values Scroll down the values measured using the ( and ) keys. Parameter Description Remarks Collector temperature S1 sensor. The value TC shows the temperature in °C given by the collector sensor in real time. Calorifier temperature S2 sensor.

  • Page 17: User Settings

    BSL 150...400 BESL 200...400 4. Operating the appliance User settings 4.2.1. Setting the time 1. Select the HRE channel with the ( and ) keys. 2. Press the B key for 2 seconds. 3. Set the hour with the ( and ) keys. 4.

  • Page 18: Setting The Dhw Calorifier Outlet Temperature

    4. Operating the appliance BSL 150...400 BESL 200...400 1. Set the 3-position switch to 0. 2. Go forward to the last display channel (HRE) with the ( key. 3. Press the ( key for 5 seconds. A setting parameter is displayed, with the symbol T . 4.

  • Page 19: Setting The Thermostatic Mixing Valve

    BSL 150...400 BESL 200...400 4. Operating the appliance 4.3.2. Setting the thermostatic mixing valve Domestic cold water inlet Domestic hot water outlet The mixing valve is set in the factory for a DHW outlet temperature of 60°C (position 6). To lower this temperature, remove the top cover and turn the wheel anti-clockwise.

  • Page 20: Checking And Maintenance

    5. Checking and maintenance BSL 150...400 BESL 200...400 Checking and maintenance General instructions CAUTION Maintenance operations must be done by a qualified engineer. Only original spare parts must be used. Safety valve or safety unit The safety valve or unit on the domestic cold water inlet must be operated at least once a month to ensure proper operating and to prevent from any overpressure which may that may damage the domestic hot water calorifier.

  • Page 21: Troubleshooting

    BSL 150...400 BESL 200...400 6. Troubleshooting Troubleshooting Incidents and solutions Description Checks Solutions The indicator light is off. The current has been cut. Restore the current. 08/09/2015 - 300028413-04...

  • Page 22: Technical Specifications

    7. Technical specifications BSL 150...400 BESL 200...400 Technical specifications Solar domestic hot water calorifier BSL 150 BSL 200 BSL 300 BSL 400 Primary circuit: Solar exchanger Maximum operating temperature °C Maximum operating pressure Mpa (bar) 1 (10) 1 (10) 1 (10) 1 (10) Exchanger capacity litres...

  • Page 23: Composition Of The Nf Cesi Solar Systems Packages (For France)

    BSL 150...400 BESL 200...400 7. Technical specifications BESL 200 BESL 300 BESL 400 Water content litres Top up volume (Electric) litres Solar volume litres Weight Gross weight Net weight Performance Cooling constant Cr Wh/24h·L·K 0.23 0.20 0.18 Maintenance consumption (ΔT=45K) kWh/24h Composition of the NF CESI solar systems packages (For France) Check the composition of the NF CESI solar system package against the table below.
  • Page 24 7. Technical specifications BSL 150...400 BESL 200...400 CESI System Array of collectors Domestic hot water production Solar fluid INISOL Type of package / package / Volume Back-up package / mounting Reference calorifier Reference (litres) Reference type/Model ER 502 : On roof 7608052 ER 503 : On roof...
  • Page 25 BSL 150...400 BESL 200...400 7. Technical specifications CESI System Array of collectors Domestic hot water production Solar fluid INISOL Type of package / package / Volume Back-up package / mounting Reference calorifier Reference (litres) Reference type/Model ER 500 : On roof 7608050 ER 501 : On roof...
  • Page 26 7. Technical specifications BSL 150...400 BESL 200...400 CESI System Array of collectors Domestic hot water production Solar fluid INISOL Type of package / package / Volume Back-up package / mounting Reference calorifier Reference (litres) Reference type/Model ER 502 : On roof 7608052 ER 503 : On roof...

  • Page 27: Warranty

    BSL 150...400 BESL 200...400 8. Warranty Warranty General You have just purchased one of our appliances and we thank you for the trust you have placed in our products. Please note that your appliance will provide good service for a longer period of time if it is regularly checked and maintained.
  • Page 28 8. Warranty BSL 150...400 BESL 200...400 The warranty is limited to the exchange or repair of such parts as have been recognised to be faulty by our technical department and does not cover labour, travel and carriage costs. The warranty shall not apply to the replacement or repair of parts damaged by normal wear and tear, negligence, repairs by unqualified parties, faulty or insufficient monitoring and maintenance, faulty power supply or the use of unsuitable fuel.

  • Page 29: Directives

    Appendix Information on the ecodesign and energy labelling directives...
  • Page 30 Contents Contents Specific information ................. . 3 Recommendations .
  • Page 31 1 Specific information Specific information Recommendations Note Only qualified persons are authorised to assemble, install and maintain the installation. Ecodesign Directive This product conforms to the requirements of European Directive 2009/125/EC on the ecodesign of energy-related products. Technical data - Hot water storage tank Tab.1 Technical parameters for BSL hot water storage tanks BSL 150...
  • Page 32 1 Specific information BSL 150 BSL 200 BSL 300 BSL 400 Solar hot water storage tank - Storage volume 0.150 0.225 0.300 0.400 Power consumption - Pump Power consumption - Standby 0.36 0.36 0.36 0.36 Annual auxiliary energy consumption Tab.4 Product fiche for BESL solar devices BESL 200 BESL 300...
