- Page 1 ASSEMBLY MANUAL SKU: 166-1-11 MODEL NAME: Kungshamn Konsumentkontakt Arc E-commerce AB Box 3124 13603 Haninge...
- Page 2 Attention! Please note that at first all screws should be inserted slightly by hand! Turn 2-3 times so that the screw grips on its own and connects all elements loosely. The screws must only be driven in tightly when all elements are connected with each other in this way.
- Page 3 Component Hardware 11 pcs M6 x 40 2pcs Back Frame 31 pcs M6 x 30 Panel Frame B 9pcs 40 pcs M6 x 25 6pcs Panel Frame C 2 pcs Seat Cushion 2pcs Seat Frame 1 pc Seat Cushion Corner 2 pcs Back Cushion Right Back Frame...
- Page 4 STEP 1(Chair Assembly) STEP 2 Connect 2x Panel Frame B(B) & Back Connect the part from STEP 1 & Panel Frame(A) with Bolt (2) & Allen key. Frame C (C) with Bolt (2) & Allen key. STEP 3 STEP 4 Connect the part from STEP 2 &...
- Page 5 STEP 6 (Corner Sofa Chair Assembly) STEP 5 Put on Seat Cushion (4) & Back Cushion(6) Connect Right Back Frame (E) & Left Back to complete the chair. Frame (F) with Bolt (1) & Allen key STEP 7 STEP 8 Connect Panel Frame B(B) &...
- Page 6 STEP 10 STEP 9 Overturn the part from STEP 9 & connect Connect the part from STEP 8 & Seat the Sofa Leg (10) with Bolt(3) & Allen key. Frame H (H) with Bolt (1),(2) & Allen key. STEP 12 (Table Assembly) STEP 11 Put on Seat Corner Cushion (5) &...
- Page 7 STEP 14 STEP 13 Connect the part from STEP 12 & Panel Connect the part from STEP 13 & Table Top Frame C (C) with Bolt (2) & Allen key. Frame (I) with Bolt (2) & Allen key STEP 15 STEP 16 Overturn the part from STEP 14 &...
- Page 8 STEP 17 (Stool Assembly) STEP 18 Connect the part from STEP 17 & Panel Connect 2x Panel Frame B(B) & Panel Frame C (C) with Bolt (2) & Allen key. Frame C (C) with Bolt (2) & Allen key. STEP 19 STEP 20 Connect the part from STEP 18 &...
- Page 9 STEP 21 Put on Cushion Stool (11) to Finish the table...
