3 Product description

3.3 Installation options

3.3.1 Flush-mounted version

3.3.2 Wall-mounted version

Position
Description
A1
Flush-mounted box
A2
Panel
A3
Glass cover
Position
Description
B1
Wall-mounted frame
B2
Panel
B3
Glass cover
9
