3 Product description

3.6 Notes on the panel's ports

3.6.1 KNX terminal

A terminal of the following specification is used for the KNX connection:
KNX WAGO 243 211, conductor diameter: 0.6-0.8 mm.
Note: The KNX fieldbus can only be used with PEAKnx software.

3.6.2 Power supply

The plug-in terminal for power supply has a usable wire cross-section of 0.75 to 1.31 mm².
Note: Only use power supplies with a nominal voltage of 24 V DC to supply the unit. Higher


voltages can cause damage to the unit.

3.6.3 Ethernet port

Note: A cable of category CAT5e or higher is recommended for using the 1000 Mbit LAN


connection.

3.6.4 Connections for external mouse and keyboard

There are two USB ports on the panel front under the glass cover, e.g. for using a USB wireless
adapter for a cordless keyboard and mouse. There is also a USB-C 3.2 port on the back of the
panel for fast data transfer to the panel.

3.7 Controls

Avoid danger of injury from falling parts!
Ensure that small children cannot access to the magnetically adhering glass cover and
▪
cannot accidentally loosen it.

3.7.1 Graphical user interface

Touch the panel to operate. A brief touch of the panel is interpreted as a mouse click. A right
mouse click is obtained by a prolonged touch (approx. 3 seconds).
Text entries can be made using the Windows on-screen keyboard. This can be found in the task
bar at the bottom right. If not, refer to chapter 7.2 Activating keyboard input. If you swipe from
the right side of the screen, you can also switch to tablet mode in the menu that appears so that
the keyboard appears automatically when you type in a text box.
Caution
12
