Model: SG-VM-275 and SG-VM-275-Y
Parts and Instruction Manual
•
2 3/4" Stand off from mounting surface to bottom of the tool craddle.
•
3/4" to 2" Grip Range
•
Molded-in support arm provides assistance and stability while securing tool
•
High-tensile strength plastic base
•
1" wide heavy-duty, all-weather hook & loop straps that have secured your tools and equipment for over 20
years.
•
Strap conforms to the handle, no matter the shape, providing a tighter, more "true" grip on every tool.
•
Dual rubber pads combine for a premium grip
ZICO
3085PM10
Scan this code to visit our
website for more information
®
Advertisement
Related Manuals for Zico Sure-Grip SG-VM-275
Summary of Contents for Zico Sure-Grip SG-VM-275
- Page 1 ZICO ® Sure-Grip Tool Mounts 3085PM10 Model: SG-VM-275 and SG-VM-275-Y Parts and Instruction Manual • 2 3/4" Stand off from mounting surface to bottom of the tool craddle. • 3/4" to 2" Grip Range • Molded-in support arm provides assistance and stability while securing tool •...
- Page 2 Parts Diagram/Breakdown Item # Part # Description 3085-650-101 BASE, SURE GRIP 2 3/4" 3085-650-103 STRAP, BLACK 3085-655-103 STRAP, YELLOW 9114-161312 FENDER WASHER, #6 X 3/4" O.D. S/S 9125-191306 SCREW, #6 x 3/8" THREAD CUTTING, PHIL PAN HD, SS 3085-650-105 RUBBER PAD WITH ADHESIVE Page 2...
- Page 3 Dimensions Note: 2" Spacing designed to mount easily to Zico Tool Boards. Page 3...
