Zico SURE-GRIP XL SG-VM-XL Parts And Instruction Manual

SURE-GRIP XL™ Tool Mount - 2" to 4" Dia.
Model SG-VM-XL
Parts and Instruction manual
MODEL
SG-VM-XL
ITEM
1
2
3
4
5
6
7
8
9
10
DESCRIPTION
SURE-GRIP XL Bracket - 2" - 4" Dia. grip range
PART NUMBER
3085-505-105
3085-505-107
3085-505-109
9125-191306 SCREW, #6-20 x 3/8", PLASTIC THREAD
9010-262528 SCREW, 1/4-20 x 1 3/4" TRUSS HEAD ZPS
9013-172500 NUT, 1/4-20 HEX HEAD, LOW-PRO NYLON
9014-262500 LOCK WASHER, 1/4" EXTERNAL TOOTH,
9014-161600 FENDER WASHER, #8 X 1.000 O.D. ZPS
3085-505-901
9014-112500
DESCRIPTION
SURE GRIP BASE
STRAP PLATE
STRAP. VARIABLE
CUTTING, SS, 94629A70
LOCK, ZPS
ZPS
PAD WITH ADHESIVE, 3" x 4"
FLAT WASHER, 1/4" ZPS
ZICO
®
3085PM3
WT./@
IN LBS.
.90
QTY.
1
1
1
4
2
2
2
1
1
2
