Electrical Part Lists - Bose SoundDock 10 Service Manual

Resistors
Reference Description
Designator
R1000 5.11K, 0603, .1W, 1%
R1001 5.11K, 0603, .1W, 1%,
R1002 75 OHM, 0805, 1/10W, 5%
R1003 51 OHM , 0805, 1/10W, 5%
R1004 51 OHM , 0805, 1/10W, 5%
R1005 51 OHM , 0805, 1/10W, 5%
R1100 51 OHM, 0603, 100MW, 5%,
R1101 51 OHM, 0603, 100MW, 5%,
R1102 51 OHM, 0603, 100MW, 5%,
R1103 51 OHM, 0603, 100MW, 5%,
R1104 51 OHM, 0603, 100MW, 5%,
R1105 51 OHM, 0603, 100MW, 5%
R200 4.99K, 0805, .125W, 1%
R201 4.99K, 0805, .125W, 1%
R202 4.99K, 0805, .125W, 1%
R203 4.99K, 0805, .125W, 1%
R204 1M , 0603, .1W, 1%,
R205 1M , 0603, .1W, 1%,
R206 1M , 0603, .1W, 1%,
R207 1M , 0603, .1W, 1%,
R208 14K, 0603, .1W, 1%,
R209 14K , 0603, .1W, 1%
R210 15K, 0603, .1W, 1%
R211 14K , 0603, .1W, 1%
R212 15K, 0603, .1W, 1%
R213 14K, 0603, .1W, 1%,
R214 15K, 0603, .1W, 1%
R215 15K, 0603, .1W, 1%
R217 15K, 0603, .1W, 1%
R218 15K, 0603, .1W, 1%
R219 47OHM, 0603, SMD, 100MW, 5%
R220 47 OHM, 0603, SMD, 100MW, 5%
R221 47 OHM, 0603, SMD, 100MW, 5%
R222 47 OHM, 0603, SMD, 100MW, 5%
R223 15K, 0603, .1W, 1%
R224 15K, 0603, .1W, 1%
R225 1.00K, 0805, 1/10W, 5%
R233 JUMPER, CHIP, 0603
R234 51 OHM , 0805, 1/10W, 5%
R300 1.5KOHM, ARRAY, SMT, 50V, 5%
R301 130K, 0603, 100MW, 1%
R304 4.99K, 0805, .125W, 1%
R305 4.99K, 0805, .125W, 1%
R309 2K, 0603, .1W, 1%
R310 2K, 0603, .1W, 1%
R311 2.49K, 0603, .1W, 1%
R400 1K, 0603, .1W, 5%
R401 22 OHMS, 0603, .1W, 5%
R402 6.04K, 0603, .1W, 1%
R403 6.04K, 0603, .1W, 1%
R404 3.3K, 0603, .1W, 5%
R405 20K, 0603, .1W, 5%
R406 0.47 OHM, 1210, 500mW, 5%
R407 100 OHM, 1206, 1/4W, 1%
R408 1K, 0603, .1W, 5%
R409 680 Milli- OHMS, 1210, 500mW, 5%,
R410 6.8 OHM, 1206, 1/4W, 5%
R411 330 OHMS, 0603, .1W, 5%,
R412 22.1K, 0603, .1W, 1%
R413 42.2 K, 0603, .1W, 1%
R414 510 OHM, 0603, .1W, 1%, 510
R415 825 OHM, 0603, SMD, 100MW, 1%
R416 1K, 0603, .1W, 5%
R417 130K , 0402, 63MW, 1%
R419 1.27K, 0603, 1/10W, 1%
R420 3.9K, 0603, .1W, 1%
R421 121 OHM, 0603, .1W, 1%,
R422 210 OHM, 0603, .1W, 1%,
R423 JUMPER, CHIP, 0603
R424 JUMPER, CHIP, 0603
R425 JUMPER, CHIP, 0603
R426 22 OHMS, 0603, .1W, 5%
R427 10K, 0603, .1W, 1%
R428 2.2 OHM, 1206, 1/4W, 5%
R429 6.8 OHM, 1206, 1/4W, 5%
ELECTRICAL PART LIST
DSP PCB Assembly
Part Number Note
191465-5111 4
191465-5111 4
133626-7505 4
133626-5105 4
133626-5105 4
133626-5105 4
199403-510 4
199403-510 4
199403-510 4
199403-510 4
199403-510 4
199403-510 4
133625-4991 4
133625-4991 4
133625-4991 4
133625-4991 4
191465-1004 4
191465-1004 4
191465-1004 4
191465-1004 4
191465-1402 4
191465-1402 4
191465-1502 4
191465-1402 4
191465-1502 4
191465-1402 4
191465-1502 4
191465-1502 4
191465-1502 4
191465-1502 4
199403-470 4
199403-470 4
199403-470 4
199403-470 4
191465-1502 4
191465-1502 4
133626-1025 4
196042 4
133626-5105 4
186433-1524 4
191465-1303 4
133625-4991 4
133625-4991 4
191465-2001 4
191465-2001 4
191465-2491 4
199403-102 4
199403-220 4
191465-6041 4
191465-6041 4
199403-332 4
199403-203 4
318356-471J 4
124894-1000 4
199403-102 4
318356-681J 4
124895-6R85 4
199403-331 4
191465-2212 4
191465-4222 4
191465-5100 4
191465-8250 4
199403-102 4
268361-1303 4
191465-1271 4
191465-3901 4
191465-1210 4
191465-2100 4
196042 4
196042 4
196042 4
199403-220 4
191465-1002 4
124895-2R25 4
124895-6R85 4
9
Resistors
Reference Description
Designator
R430 10K, 0603, .1W, 1%
R431 3.9K, 0603, .1W, 1%
R432 1.00K, 0805, 1/10W, 5%
R600 10K, 0603, .1W, 5%
R601 10K, 0603, .1W, 5%
R602 330 OHM, 0603, .1W, 1%,
R603 330 OHM, 0603, .1W, 1%
R604 2K, 0603, .1W, 1%
R605 10K, 0603, .1W, 5%
R606 100K, 0603, .1W, 5%
R607 49.9K, 0603, .1W, 1%
R608 475 OHM, 0603, .1W, 1%,
R609 100 OHM, 0603, .1W, 5%
R611 51 OHM, 0805, 1/10W, 5%
R612 51 OHM, 0805, 1/10W, 5%
R613 51 OHM, 0805, 1/10W, 5%
R614 51 OHM , 0805, 1/10W, 5%
R615 51 OHM , 0805, 1/10W, 5%
R616 51 OHM , 0805, 1/10W, 5%
R617 100 OHM, 1206, 1/4W, 1%
R800 330 OHM, 0805, 1/10W, 5%
R801 1K, 0603, .1W, 5%
R802 10K, 0603, .1W, 5%
R803 49.9 OHM, 0402, 63MW, 1%
R804 100 OHM, 0603, .1W, 5%
R805 51 OHM , 0805, 1/10W, 5%
R806 10K, 0603, .1W, 5%
R807 10K, 0603, .1W, 5%
R808 10K, 0603, .1W, 1%
R809 330 OHM, 0805, 1/10W, 5%
R810 330 OHM, 0805, 1/10W, 5%
R811 330 OHM, 0805, 1/10W, 5%
R812 330 OHM, 0805, 1/10W, 5%
R813 330 OHM, 0805, 1/10W, 5%
R814 330 OHM, 0805, 1/10W, 5%
R815 330 OHM, 0805, 1/10W, 5%
R816 330 OHM, 0805, 1/10W, 5%
R817 330 OHM, 0805, 1/10W, 5%
R818 330 OHM, 0805, 1/10W, 5%
R819 330 OHM, 0805, 1/10W, 5%
R820 330 OHM, 0805, 1/10W, 5%
R821 51 OHM, 0805, 1/10W, 5%
R822 51 OHM , 0805, 1/10W, 5%
R823 51 OHM, 0805, 1/10W, 5%
R824 330 OHM, 0805, 1/10W, 5%
R825 330 OHM, 0805, 1/10W, 5%
R826 330 OHM, 0805, 1/10W, 5%
R827 49.9 OHM, 0402, 63MW, 1%
R828 49.9 OHM, 0402, 63MW, 1%
R829 49.9 OHM, 0402, 63MW, 1%
R830 49.9 OHM, 0402, 63MW, 1%
R831 49.9 OHM, 0402, 63MW, 1%
R832 4.7K, 0603, .1W, 5%,
R833 10K, 0603, .1W, 1%
R834 10K, 0603, .1W, 1%
R835 330 OHM, 0603, .1W, 1%
R836 10K, ARRAY, SMT, 4 POS, 5%
R837 49.9 OHM, 0402, 63MW, 1%
R838 10K, 0603, .1W, 1%
R839 10K, 0603, .1W, 1%
R840 10K, 0603, .1W, 5%
R841 10K , ARRAY, SMT, 4 POS, 50V, 5%
R842 0603, .1W, 1%, 100K
R846 10K, ARRAY, SMT, 4 POS, 5%
R850 10K, 0603, .1W, 5%
R851 10K, 0603, .1W, 5%
R854 JUMPER, CHIP, 0603
R855 JUMPER, CHIP, 0603
R856 JUMPER, CHIP, 0603
R857 JUMPER, CHIP, 0603
R859 330 OHM, 0805, 1/10W, 5%
R900 10K, 0603, .1W, 5%
R901 47 OHM, 0603, SMD, 100MW, 5%
R902 47 OHM, 0603, SMD, 100MW, 5%
R903 4.7K, 0603, .1W, 5%,
Part Number Note
191465-1002 4
191465-3901 4
133626-1025 4
199403-103 4
199403-103 4
191465-3300 4
191465-3300 4
191465-2001 4
199403-103 4
199403-104 4
191465-4992 4
191465-4750 4
199403-101 4
133626-5105 4
133626-5105 4
133626-5105 4
133626-5105 4
133626-5105 4
133626-5105 4
124894-1000 4
133626-3315 4
199403-102 4
199403-103 4
268361-49R9 4
199403-101 4
133626-5105 4
199403-103 4
199403-103 4
191465-1002 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-3315 4
133626-5105 4
133626-5105 4
133626-5105 4
133626-3315 4
133626-3315 4
133626-3315 4
268361-49R9 4
268361-49R9 4
268361-49R9 4
268361-49R9 4
268361-49R9 4
199403-472 4
191465-1002 4
191465-1002 4
191465-3300 4
186433-1034 4
268361-49R9 4
191465-1002 4
191465-1002 4
199403-103 4
186433-1034 4
191465-1003 4
186433-1034 4
199403-103 4
199403-103 4
196042 4
196042 4
196042 4
196042 4
133626-3315 4
199403-103 4
199403-470 4
199403-470 4
199403-472 4
