  • Page 1: Quick Reference Guide

    Quick Reference Guide 604P17528 MAXIMIZE YOUR PRODUCTIVITY..by taking advantage of all the capabilities of your device. A Training and Information CD was supplied with your product. The CD provides animated tutorials and interactive screens. When installed on your network it will always be available to everyone, or load it on your hard drive for easy access.
  • Page 2 The information in this document is correct at the time of publication. Xerox reserves the right at any time to change the information without notice. Changes and technical updates will be added in subsequent editions of the documentation. For the latest information go to www.xerox.com.
  • Page 3: Table Of Contents

    US Regulatory Information for the Fax Kit option...1-12 Canadian Regulatory Information for the Fax Kit option ...1-14 Illegal Copying...1-15 2 Product Overview ...2-1 Introduction ...2-2 CopyCentre C165/C175...2-3 WorkCentre M165/M175...2-5 WorkCentre Pro 165/175...2-7 3 Getting Started...3-1 Control Panel Overview...3-2 Quick Reference Guide...
  • Page 4 Power On or Off ...3-3 Loading Paper ... 3-4 Making Copies... 3-5 Sending an Embedded Fax ...3-6 Sending a Server Fax ...3-7 Sending an Internet Fax ...3-8 Scanning a Document to a File... 3-9 Sending an E-mail ...3-10 Printing from a PC ... 3-11 Printing with Internet Services ...
  • Page 5 5 Fax...5-1 Fax ...5-2 Basic Faxing - Embedded Fax ...5-3 Dialing Options...5-4 Resolution ...5-7 Sides Scanned ...5-8 Image Adjustment ...5-9 Image Quality ...5-10 Original Input...5-11 Bound Originals...5-12 Added Fax Features...5-13 Fax Sending Features...5-13 Fax Reports...5-19 Mailboxes ...5-20 Comment Setup ...5-21 Advanced Fax Features ...5-21 Dial Directory Setup ...5-24 Basic Faxing - Server Fax ...5-25...
  • Page 6 Message Body ...6-15 Authentication Mode ... 6-16 7 Network Scanning... 7-1 Scan ... 7-2 Scanning Resources ...7-2 Network Scanning...7-3 Repositories ...7-4 Template Overview ...7-4 Template Destinations ... 7-5 Destination Details ...7-6 Image Adjustment ...7-7 Image Quality ... 7-8 More Image Quality...7-9 Sides Scanned ...7-10 Edge Erase ...
  • Page 7 Cleaning the Machine ...10-4 Further Assistance...10-5 11 Troubleshooting ...11-1 General...11-2 Fault Clearance ...11-3 Paper jams ...11-3 Document jams ...11-3 Xerox Welcome and Support Center...11-4 Locating the serial number...11-4 Troubleshooting Tips ...11-5 Power ...11-5 Document Handler ...11-5 Paper Handling ...11-6 Finisher ...11-7 Output Quality ...11-8...
  • Page 8 Page -vi Quick Reference Guide...
  • Page 9: Welcome

    1 Welcome Introduction ...1-2 Additional Resources ...1-3 Conventions ...1-4 Overview of Features at the Machine ...1-6 Overview of Features at the Workstation...1-8 Safety...1-9 Environmental Compliance ... 1-11 Regulatory Information ...1-12 Illegal Copying ...1-15 Quick Reference Guide Page 1-1...
  • Page 10: Introduction

    Introduction Welcome to your new Xerox machine. This Quick Reference Guide provides you with an overview of the features and options that may be available on your machine. To help you familiarize yourself with your new machine please refer to:...
  • Page 11: Additional Resources

    Additional Resources System Administration CD (CD1) Contained in the CD Pack delivered with your machine, the System Administration CD (CD1) offers detailed information on configuring your machine for network printing and instructions on installing any of the optional features. The System Administration CD (CD1) is intended for System/Machine Administrators.
  • Page 12: Conventions

    Conventions Throughout this Guide, you will find that some terms are used interchangeably: Paper is synonymous with media. Document is synonymous with original. CopyCentre/WorkCentre/WorkCentre Pro is synonymous with the machine. The following pages offer further information about the conventions used within this Guide.
  • Page 13: Bracket Text Typeface

    Bracket text typeface: The [Bracket Text] typeface is used to emphasise the selection of a feature mode or button. For example: Select [Machine Details]. Notes Notes are statements that provide additional information. For example: NOTE: Originals must be loaded in the Document Handler when using this feature. Hints Hints help users to perform a task.
  • Page 14: Overview Of Features At The Machine

    Overview of Features at the Machine Using the powerful features available on your machine you can: Scan Once and Print Many When making copies your machine only has to scan a document once regardless of the number of copies needed. This reduces the risk of jams and damage to originals.
  • Page 15 Use the Mixed Size Originals feature to copy mixed size originals simultaneously. Produces copies on uniform size paper or mixed size paper. Be Environmentally Friendly This product complies with a variety of international standards for environmental protection and is compatible with most recycled paper. Scan Documents to Create Electronic Files (Optional) This feature, available on the WorkCentre Pro configuration, allows you to create electronic files from your originals which can be:...
  • Page 16: Overview Of Features At The Workstation

    Overview of Features at the Workstation If your machine is connected to a network you can use the following features. Contact your System Administrator to get connected. CentreWare Print Drivers The Print Driver extends the productivity power of your machine to your desktop. Options include: •...
  • Page 17: Safety

    Safety Introduction Your Xerox product and supplies have been designed and tested to meet strict safety requirements. These include safety agency approval and compliance to established environmental standards. Please read the following instructions carefully before operating the product and refer to them as needed to ensure the continued safe operation of your product.
  • Page 18: Laser Safety

    This product contains laser warning labels. These labels are intended for use by Xerox Service Representatives and are placed on or near panels or shields that require special tools for removal. Do not remove any of the panels. There are no operator serviceable areas inside these covers.
  • Page 19: Environmental Compliance

    Xerox product is part of the program. For more information about Xerox environmental programs, visit www.xerox.com/environment. If you are managing the disposal of your Xerox product, please note that the product contains lead, mercury and other materials whose disposal may be regulated due to environmental considerations.
  • Page 20: Regulatory Information

    Changes or modifications to this equipment not specifically approved by the Xerox Corporation may void the user’s authority to operate this equipment. WARNING:Shielded cables must be used with this equipment to maintain compliance with FCC regulations.
  • Page 21 US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g., 02 is a REN of 0.2). If this Xerox equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
  • Page 22: Canadian Regulatory Information For The Fax Kit Option

    Repairs to the machine should be made only by a Xerox representative or an authorized Xerox service agency. This applies at any time during or after the service warranty period.
  • Page 23: Illegal Copying

    Illegal Copying Congress, by statute, has forbidden the copying of the following subjects under certain circumstances. Penalties of fine or imprisonment may be imposed on those guilty of making such copies. Obligations or Securities of the United States Government, such as: Certificates of Indebtedness Coupons from Bonds Silver Certificates...
  • Page 24 Copyrighted material (unless permission of the copyright owner has been obtained or the copying falls within the “fair use” or library reproduction provisions of the copyright law). Further information of these provisions may be obtained from the Copyright Office, Library of Congress, Washington, DC 20559 (circular R21) Certificates of Citizenship or Naturalization.
  • Page 25: Product Overview

    2 Product Overview Introduction ...2-2 CopyCentre C165/175 ...2-3 WorkCentre M165/M175...2-5 WorkCentre Pro 165/175 ...2-7 Quick Reference Guide Page 2-1...
  • Page 26: Introduction

    65 or 75 copies/ prints a minute. All three configurations are fully upgradable so as to meet any future requirements you may have. Please contact your local Xerox representative for further information. CopyCentre C165/175 - A stand-alone copier which offers the copying functionality available on conventional copiers, combined with the added feature capabilities of the digital copier technology.
  • Page 27: Copycentre C165/C175

    CopyCentre C165/175 Control Panel (Touch Screen and Numeric Keypad) Bypass Tray (Folds up when not in use) Paper Trays 1 & 2 The following options are available for the CopyCentre. Offset Catch Delivers output either face up or face down, collated or uncollated. Each set or stack Tray will be offset from the previous to enable easy separation.
  • Page 28 Foreign Enables the attachment of a third party access and accounting device, such as a Interface card or coin operator. Device Fax Line 1 Provides a single telephone line connection. Fax Line 2 Provides a second telephone line. Once installed enables your machine to send and receive faxes at the same time.
  • Page 29: Workcentre M165/M175

    WorkCentre M165/M175 Control Panel (Touch Screen and Numeric Keypad) Shelf Bypass Tray (Folds up when not in use) Paper Trays 1 & 2 The following options are available for the WorkCentre: Offset Catch Delivers output either face up or face down, collated or uncollated. Each set or stack Tray will be offset from the previous to enable easy separation.
  • Page 30 Fax Line 2 Provides a second telephone line. Once installed enables your machine to send and receive faxes at the same time. E-mail Enables the creation of an electronic image file by scanning an original hard copy document. The scanned image is sent as an e-mail attachment to the specified recipient(s).
  • Page 31: Workcentre Pro 165/175

    WorkCentre Pro 165/175 Control Panel (Touch Screen and Numeric Keypad) Shelf Bypass Tray (Folds up when not in use - shown closed) Paper Trays 1 & 2 The following options are available for the WorkCentre Pro: Offset Catch Delivers output either face up or face down, collated or uncollated. Each set or stack Tray will be offset from the previous to enable easy separation.
  • Page 32 Hole Punch This option is available if your machine is equipped with any of the three finishers. The kits available are 2 hole or 3 hole long edge feed or 2 hole short edge feed for legal size paper. Each sheet is punched individually, so there is no limit to the number of sheets in the set.
  • Page 33: Getting Started

    3 Getting Started Control Panel Overview ...3-2 Power On or Off ...3-3 Loading Paper ...3-4 Making Copies ...3-5 Sending an Embedded Fax ...3-6 Sending a Server Fax ...3-7 Sending an Internet Fax ...3-8 Scanning a Document to a File...3-9 Sending an E-mail ...3-10 Printing from a PC ...
  • Page 34: Control Panel Overview

    Control Panel Overview NOTE: The Touch Screen displayed is for a fully configured WorkCentre Pro configuration. The touch screen Displays and selects all the available programming features, plus fault clearance procedures and general machine information. Features Displays the job features on the screen.
  • Page 35: Power On Or Off

    Power On or Off To power ON: Press the ON/OFF switch. The powering up process takes less than 3 minutes. NOTE: Certain functions of the machine, e.g. copying, will be available before other functions e.g. printing. To power OFF: Press the ON/OFF switch. A confirmation screen will appear asking you to select a power down option.
  • Page 36: Loading Paper

    Loading Paper Open the required paper tray. NOTE: Paper trays 1 and 2 are fully adjustable for all stock sizes between 8.5" x 5.5" to 11" x 17". Paper trays 3 and 4 are dedicated paper trays which can be adjusted to hold either 8.5"...
  • Page 37: Making Copies

    Making Copies Load the documents either in the Document Handler or on the Document Glass. NOTE: Documents in the handler are only scanned once. Access the Basic Copy screen - if necessary select the Features button on the control panel. Select the required features on the touch screen.
  • Page 38: Sending An Embedded Fax

    Sending an Embedded Fax Embedded Fax is an optional walk up fax feature on your machine. If the Basic Fax screen matches that displayed in step 2 then Embedded Fax is enabled. Please contact your System Administrator for further assistance. NOTE: Both Embedded and Server Fax can be installed on the WorkCentre Pro at the same time, however only one service can be enabled for use.
  • Page 39: Sending A Server Fax

    Sending a Server Fax Server Fax is an optional feature which is only available on the WorkCentre Pro configuration. If the Basic Fax screen matches that displayed in step 2 then Server Fax is enabled. Please contact your System Administrator for further assistance. NOTE: Both Embedded and Server Fax can be installed on the WorkCentre Pro at the same time, however only one service can be enabled for use.
  • Page 40: Sending An Internet Fax

    Sending an Internet Fax Internet Fax is an optional feature which is only available on the WorkCentre Pro configuration. Please contact your System Administrator for further assistance. Load the documents either in the Document Handler or on the Document Glass. NOTE: Documents in the handler are only scanned once.
  • Page 41: Scanning A Document To A File

    Scanning a Document to a File Network Scanning is only available on the WorkCentre Pro configuration. Please contact your System Administrator for further assistance. Load the documents either in the Document Handler or on the Document Glass. NOTE: Documents in the handler are only scanned once.
  • Page 42: Sending An E-Mail

    Sending an E-mail E-mail is an optional feature which is only available on the WorkCentre and WorkCentre Pro configuration. Please contact your System Administrator for further assistance. NOTE: E-mail is only supported on the WorkCentre via the Ad Hoc E-mail options kit.
  • Page 43: Printing From A Pc

    Printing from a PC If your machine is connected to a network, documents can be printed directly from your PC using the CentreWare print driver supplied.The print driver must be loaded on each PC which uses the machine for printing. Select [Print] in your application.
  • Page 44: Printing With Internet Services

    Printing with Internet Services Printing with Internet Services is available on the WorkCentre Pro, and on the WorkCentre if the postscript option is installed. Internet Services uses a Web User Interface embedded in the machine to communicate between the HTTP server and the machine.
  • Page 45: Logging On / Logging Off

    Logging On / Logging Off If the Internal Auditron or the optional Network Accounting has been enabled, a valid User Number needs to be entered in order to access the machine functions. The Internal Auditron automatically tracks Copy jobs for billing purposes, as well as preventing unauthorized access to the machine.
  • Page 46: Customizing Your Machine

    Customizing your Machine Your machine can be customized to suit your working environment and practices. The System Management Tools enable your System or Machine Administrator to setup, customize and maintain the machine. After your machine is installed, it is recommended that the settings and options are customized to fully meet the requirements of the Users.
  • Page 47: Further Assistance

    Refer to the Training and Information CD (CD2), contained in the CD Pack delivered with your machine. Contact your System and/or Machine Administrator. Visit our Customer Web Site at www.xerox.com or contact the Xerox Welcome and Support Center quoting the machine serial number Press the Machine Status button on the control panel.
  • Page 48 Page 3-16 Quick Reference Guide...
  • Page 49: Copy

    4 Copy Copy ...4-2 Basic Copying ...4-3 Image Adjustment ...4-12 Output Format...4-19 Job Assembly ...4-26 Quick Reference Guide Page 4-1...
  • Page 50: Copy

    Copy The Copy feature is standard on your machine. Access to the Copy features is gained using the Features button on the control panel. Depending on the options enabled and how your machine has been configured, you may have to select All Services in the top right-hand corner first. This chapter contains information about the options available within Copy.
  • Page 51: Basic Copying

    Basic Copying The Basic Copying tab is the default Copy screen. Use the Basic Copying tab to select the standard features for a copy job. Depending on the options enabled and how your machine has been configured, you may have to select the All Services button in the right-hand corner to access Copy. Touch any of the top level buttons to select a feature.
  • Page 52: Output

    Output Output is used to select the finishing requirements for the job. The options will depend on the finishing output device installed. Options: Select Collated for output stacked in sets to match the sequence of the originals. Collated Select Uncollated for output sorted into stacks of individual pages. Uncollated Hole Punched This option is available if your machine is equipped with a finisher and a 2 Hole or 3 Hole Punch.
  • Page 53 The Stapling options are as follows: Stapling TAPLES INGLE OUBLE ULTI Collated and uncollated stapled sets will be delivered offset. Staples 2 - 50 sheets of 20lb, substance 20 paper. The maximum number of sheets is 20 when stapling heavyweight paper. Off-line This function is also available on all 3 finishers.
  • Page 54: Index

    If your machine is fitted with the Professional Finisher the Booklet Maker option can Booklet Maker be used to fold and staple (saddle stitch) your output to produce booklets. The Booklet Maker options are as follows: OLDED AND TAPLED OLDED The paper sizes that can be used are A3, 11"...
  • Page 55 Options: Use this option for 1 sided originals when 1 sided copies are required. 1 Sided Use this option for 1 sided originals when 2 sided copies are required. 2 Sided This option produces 2 sided copies from 1 sided originals and rotates every second 2 Sided, side image.
  • Page 56: Reduce/Enlarge

    Reduce/Enlarge The Reduce / Enlarge option provides a variety of reduction and enlargement options. Originals placed on the Document Glass or sent to the machine electronically can be reduced or enlarged between 25% and 400%. Originals fed through the Document Handler can be reduced or enlarged between 25% and 200%.
  • Page 57 Custom options are as follows: Produces an image on the copies the same size as the image on the 100% original. Automatically fits the image of the original onto the paper selected. Enables you to customize the width (x) and height (y) reduction or X50% Y100% enlargement to suit your own requirements.
  • Page 58: Paper Supply

    Paper Supply Use the Paper Supply options to select Auto Paper or a paper tray for the copy job. Options: With this option selected the machine chooses the correct paper for the copy job Auto Paper based on the size of the originals being scanned. Use this option to select the paper loaded in Tray 1.
  • Page 59 The Bypass Tray holds 100 sheets of 20lb paper, substance 20. Weight ranges from 16 - 80lb (US Cover), substance 16 - 80. Sizes range from 4.25” x 5.5”SEF to 11” x 17”SEF. Most stocks can be used (for example transparencies, tabbed stock, letterhead), except for envelopes.
  • Page 60: Image Adjustment

    Image Adjustment The Image Adjustment tab provides copy features used for adjusting the appearance of the copy output. NOTE: If the ’More Copy Features’ tab is displaying, this must be selected to access the Image Adjustment tab. Review Summary Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 61: Image Quality

    Image Quality Use this feature to enhance the quality of your output. Options: Use this option to enhance the copy quality of the output based on the type of Original Type original being scanned. Original Type options are as follows: ORMAL ALFTONE HOTO...
  • Page 62: More Image Quality

    More Image Quality Use this feature in addition to the settings selected using the Image Quality option, to further enhance the quality of your output. Options: This option controls the differences between the image densities within the copy. Contrast Select a lower setting to improve the copy quality of pictures. Select a higher setting to produce more vivid blacks and whites for sharper text and lines.
  • Page 63: Bound Originals

    Bound Originals This feature is used to copy pages from bound documents onto separate single- sided or double-sided pages. The bound original is placed face down on the Document Glass with the spine of the book lined up with the marker on the rear edge of the glass. Align the top of the bound original against the rear edge of the document glass.
  • Page 64: Edge Erase

    Erases a specified area from the centre of the book to eliminate unwanted marks Binding Erase caused by scanning the binding. When Left Page or Right Page is selected, between 0 and 1.0 inch can be erased. When Both Pages is selected, between 0 and 2.0 inches can be erased.
  • Page 65: Original Input

    Original Input Use this option to program the size of the originals being scanned or enable the machine to recognize the size of the originals. Options: Use this option to allow the machine to recognize the size of the originals being fed Auto through the Document Handler.
  • Page 66: Image Shift

    Image Shift This feature enables the position of the image on the page to be adjusted. Options: The image position is not adjusted. No Shift Use to automatically center the scanned image on the output paper. Auto Center Use to create a binding edge for the document. The image can be adjusted up or Margin Shift down on the page and/or shifted to the right or left.
  • Page 67: Output Format

    Output Format The Output Format tab is used to produce different options for the finished output. NOTE: If the ’More Copy Features’ tab is displaying, this must be selected to access the Output Format tab. Review Summary Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 68: Transparencies

    Transparencies Use this feature to add either a blank or printed divider between each transparency within a set. Always load transparencies in the Bypass Tray. Transparency jobs will be delivered single-sided and collated with no finishing. The quantity can only be set to one for this feature. Options: The feature is switched off.
  • Page 69: Booklet Creation

    Booklet Creation Use this feature to create multipage booklets from a sequential set of either single- sided or double-sided originals. The machine produces 2 sided output automatically, which when folded produces a booklet with all the pages in the correct location. The machine will also reduce and correctly position each image to fit on the selected paper.
  • Page 70: Multi-Up

    Multi-Up This feature is used to create documents with multiple images on each page. It is ideal for creating handouts, storyboards or documents used for archival purposes. NOTE: Originals must be loaded in the Document Handler when using this feature. Options: The feature is switched off.
  • Page 71: Invert Image

    Invert Image This feature enables Mirror Image or Negative Image copies to be produced. Options: Use this option to change the direction of the original image, creating a mirror of the Mirror Image original. This option is primarily used to change the position of a graphic. Use Negative Image to create copies that are the opposite of the original document, Negative Image the white areas become black and the black areas become white.
  • Page 72: Covers

    Covers Use this feature to automatically add covers to your copied set using stock taken from a different tray than the copies. HINT: Covers and Inserts can be selected in the same job. Options: The feature is switched off. No Covers Use this option to add a front cover to the copies.
  • Page 73 Use this option to select the imaging requirements for the covers. Output Cover Output Cover Images options are as follows: Images LANK IDED IDED IDED Use this option to select the tray required for the cover stock. Cover Stock Quick Reference Guide Adds Blank covers to the copies.
  • Page 74: Job Assembly

    Job Assembly The Job Assembly tab is used to combine multiple documents into a single job, produce a sample set of a job or for storing the programming of up to 10 jobs. NOTE: If the ’More Copy Features’ tab is displaying, this must be selected to access the Job Assembly tab.
  • Page 75 To use Build Job, split the job into programming and scanning segments. Select the Build Job option and select On. Program and scan the first segment. Continue to program and load segments until the whole job has been scanned. When the entire job has been scanned, select Build Job Controls and select End Build Job.
  • Page 76: Sample Set

    Sample Set This feature is used to review the output to ensure that it is exactly what is required prior to printing a large quantity. Options: The feature is switched off. Use to enable the Sample Set feature. One complete set of the job will be printed. To print the remainder of the job, press the Job Status button and select your job in the queue.
  • Page 77: Stored Programming

    Stored Programming Use this feature to program up to 10 commonly used programming sequences. For example, combinations of selections such as Edge Erase and Bound Originals. The machine stores only the programming features for the job, NOT the images. Each time a stored job is used the images must be scanned. To use this feature, use the up and down scroll buttons on the scrolling list to select the required storage location, then select a function button - Store or Recall Programming.
  • Page 78: Inserts

    Inserts Use this feature to add up to two additional stock types to your job. For example, you can separate sections using blank sheets or tab stock, or print the first page of each section on different colored stock to separate chapters. A combination of standard size media, tab stock, card or colored paper can be used for the inserts.
  • Page 79 If a second stock is required, use this option to program the inserts requiring a Second Insert different stock. Tray Select the Second Insert Tray option. Using the up/down arrow keys, enter the page number of the first insert and select Add Insert. The page number displays in the Insert Page as Side window.
  • Page 80 Page 4-32 Quick Reference Guide...
  • Page 81: Fax

    5 Fax Fax ...5-2 Basic Faxing - Embedded Fax...5-3 Image Adjustment ...5-9 Added Fax Features ...5-13 Basic Faxing - Server Fax...5-25 More Fax Features ...5-29 Authentication Mode ...5-34 Quick Reference Guide Page 5-1...
  • Page 82: Fax

    Fax is an optional feature which may not be available on your machine. There are two types of Fax service - Embedded Fax and Server Fax. Although both Fax services can be installed, only one fax service can be enabled. Your System Administrator will set up the default fax service.
  • Page 83: Basic Faxing - Embedded Fax

    Basic Faxing - Embedded Fax The Basic Faxing tab is the default Embedded Fax screen. Use the options available on this screen to enter the recipient telephone number and to select the standard features for your fax job. Access to the Basic Faxing features is gained using the Features button on the control panel.
  • Page 84: Dialing Options

    Dialing Options Use the Dialing Options to enter the destination fax number or numbers for the fax job. Individual fax numbers can be entered using the keypad, using the Speed Dial function or selected from the Directory. The Directory is a listing of Individual or Group numbers which have been previously setup and stored.
  • Page 85 The Send List is used when the fax is being sent to multiple destinations. Fax Send List numbers can be entered into the Send List manually using the keypad, using Speed Dial or by using the Directory. The Directory stores and displays the fax recipient details. Information includes the recipient’s name, fax number and transmission preferences, for example the resolution and communication mode.
  • Page 86 RIVATE ELIMITER DENTIFIER DENTIFIER This feature allows users to create a single fax recipient by adding two or more fax Chain Dialing numbers together. For example, an area code may be stored separately to the telephone number, Chain Dialing combines these entries into a single fax number. Chain Dialing is accessed from the Send List.
  • Page 87: Resolution

    Resolution The Resolution affects the appearance of the fax at the receiving fax terminal. A higher resolution produces better quality for photos. However, a lower resolution reduces communication time. Options: 200 x 100 dpi - Recommended for text documents. It requires less communication Standard time, but does not produce the best image quality for graphics and photos.
  • Page 88: Sides Scanned

    Sides Scanned This is used to specify whether the originals are single-sided or double-sided. For 2-sided originals the orientation can also be programmed. Options: Use this option for originals that are printed on one side only. 1 Sided Use this option for originals that are printed on both sides. 2 Sided Page 5-8 Quick Reference Guide...
  • Page 89: Image Adjustment

    Image Adjustment The Image Adjustment tab provides further features that can be applied to your fax job. NOTE: If the ’More Fax Features’ tab is displaying, this must be selected to access the Image Adjustment tab. Review Summary Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 90: Image Quality

    Image Quality Use this feature to enhance the quality of the outgoing fax. Options: Use this option to enhance the quality of the fax based on the type of original being Original Type scanned. Original Type options are as follows: ORMAL ALFTONE HOTO...
  • Page 91: Original Input

    Original Input This feature enables users to specify the size of the original document when scanning from the Document Glass or Document Handler. The machine uses this information to calculate the size of your original and the scanned image. Options: This is the default option.
  • Page 92: Bound Originals

    Bound Originals Use this option to program which page or pages of a bound document are to be scanned and faxed. The bound original is placed face down on the Document Glass with the spine of the book lined up with the marker on the rear edge of the glass. Align the top of the bound original against the rear edge of the document glass.
  • Page 93: Added Fax Features

    Added Fax Features The Added Fax Features tab provides further fax features which can be used when transmitting faxes. NOTE: If the ’More Fax Features’ tab is displaying, this must be selected to access the Added Fax Features tab. Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 94: Transmission Options

    Transmission Options Allows transmission information to be included with your fax job. Options: This report contains details about the fax together with a reduced copy of the Transmission image from the first page. When sending a fax to multiple recipients, a Report Transmission Report will be printed listing all of the recipients.
  • Page 95 Reduce/Split Use this option to choose how your faxed document is printed if your document paper size is larger than the receiving machines capability. Options: Reduces the faxed document to fit the paper size of the receiving fax machine. Reduce to fit If this option is selected the receiving fax machine will either split the faxed Split across document into two equal parts, or print the majority of the image on to one page and...
  • Page 96: Cover Letter

    Cover Letter Use this option to add a cover letter to your fax job. Users can add text in the ’To’, ’From’ and ’Comment’ fields. NOTE: The Cover Letter title is added automatically. Options: Displays the recipient’s fax number or name. Select the keyboard button to amend the recipient’s name.
  • Page 97: Starting Rate

    Starting Rate Use this option to set the transmission speed of your fax job. Options: Used in areas of low quality communication, when experiencing telephone noise or Forced 4800 bps when fax communications are susceptible to errors. Determines the communication mode to be used based on the maximum Super G3 (33.6 capabilities of the remote machine.
  • Page 98: Delayed Send

    Delayed Send Use Delayed Send to specify a time at which to send a fax. The time can be set between 15 minutes and 23 hours 59 minutes. This feature is very useful when transmitting faxes during off-peak hours or when sending to another country or time zone.
  • Page 99: Fax Reports

    Fax Reports This feature enables you to obtain hard copy information about the status of the fax feature on your machine. Options: Fax Reports options are as follows: CTIVITY IRECTORY EPORT ROUP IRECTORY EPORT PTIONS ENDING EPORT Quick Reference Guide Displays the last 50 fax activities completed on the machine.
  • Page 100: Mailboxes

    Mailboxes Enabled by your System Administrator, this option allows you to store documents in a mailbox. The mailbox can be located on the same machine you are using (local mailbox), or sent to a mailbox on a remote machine (remote mailbox). Documents held within the mailbox are recognized as stored for polling, printing or deleting by the user.
  • Page 101: Comment Setup

    Comment Setup This feature allows you to create, modify or delete comments that you want to appear on the fax Cover Letter. Up to 10 comments can be stored on the machine. To add or modify a comment select a numbered comment box from the comment list and select Edit.
  • Page 102 Build Job Use this feature to build a job that requires different settings for each page. For example, if a set of documents consists of some pages with text and some with photos, the appropriate setting for each original can be applied and the job can still be completed as a single job.
  • Page 103 Offers options which can be selected when using Build Job. Build Job Controls Build Job Controls options are as follows: UILD ELETE EGMENT ELETE SEGMENTS Polling Polling enables you to store fax documents into the machine’s memory for retrieval by another remote fax machine, or poll a remote fax machine or mailbox Options: This option allows users to scan documents and store them.
  • Page 104: Dial Directory Setup

    Dial Directory Setup Use this feature to store destination names, fax numbers and transmission settings in your machine. Entries stored here will be available for selection within the Send List feature on the Basic Faxing tab. Dialing Groups can also be set up, comprising of many individual entries. HINT: This feature saves time when sending faxes to frequently used destinations.
  • Page 105: Basic Faxing - Server Fax

    Basic Faxing - Server Fax The Basic Faxing tab is the default Server Fax screen. Use the options available on this screen to enter the recipient telephone number and to select the standard features for a fax job. Access to the Basic Faxing features is gained using the Features button on the control panel.
  • Page 106: Dialing Options

    Dialing Options The Dialing Options area contains a window where the telephone number entered is displayed. Once it is displayed, it can be added to a list of destination telephone numbers, a special character can be added, or a list of up to 30 stored telephone numbers can be accessed.
  • Page 107: Resolution

    ASSWORD WITCH ULSE WITCH AIT FOR ETECTION OCAL HARACTER ID [ OCAL HARACTER The Phone List can store up to 30 fax numbers. Enter the fax number and select Phone List Phone List. Select an empty number and then select Enter Number In Phone List, the number will be stored.
  • Page 108: Sides Scanned

    200 x 200 dpi - Recommended for line art and photos. This is the default resolution Fine and the best choice in most cases. Sides Scanned This is used to specify whether the originals are single-sided or double-sided. For 2-sided originals the orientation can also be programmed. Options: Use this option for originals that are printed on 1 side only.
  • Page 109: More Fax Features

    More Fax Features The More Fax Features tab provides additional fax features which can be used with your fax job. Review Summary Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 110: Image Quality

    Image Quality Use this feature to enhance the quality of the outgoing fax. Options: Use this option to enhance the quality of the fax based on the type of original being Original Type scanned. Original Type options are as follows: ORMAL ALFTONE HOTO...
  • Page 111: More Image Quality

    More Image Quality Use this feature in addition to the settings selected using the Image Quality option, to further enhance the quality of your output. Options: Adjusts the difference between the image densities within the scanned image. Contrast Increasing sharpness improves the sharpness of text; decreasing sharpness Sharpness reduces the moiré...
  • Page 112: Original Input

    Original Input Use this option to program the size of the originals being scanned or enable the machine to recognize the size of the originals automatically. Options: Use this option to enable the machine to recognize the size of the originals being Auto fed through the Document Handler.
  • Page 113: Delayed Send

    Delayed Send Use Delayed Send to specify a time, within the next 24 hours, at which to send a fax. This feature can be used to transmit faxes during off-peak hours or is useful when sending to another country or time zone.The time to send is added to the job information sent to the fax server with the scanned image.
  • Page 114: Authentication Mode

    Authentication Mode Authentication is a useful network security management tool - limiting, restricting and monitoring access to the network via the machine. Authentication can be set up by the System Administrator to restrict access to the features within E-mail, Network Scanning, Server Fax and Internet Fax.
  • Page 115 6 Internet Fax Internet Fax...6-2 Image Adjustment ...6-6 Output Format...6-12 Authentication Mode ...6-16 Quick Reference Guide Page 6-1...
  • Page 116: Internet Fax

    Internet Fax Internet Fax is an optional feature which is only available on the WorkCentre Pro configuration. This chapter contains information about the options available within Internet Fax. Internet Fax allows you to send your scanned images as an e-mail attachment to a specified recipient or recipients.
  • Page 117: Send

    Send: Use the Send options to enter recipient information. Options: This option provides information about the sender and is pre-set by the system or From the System Administrator and cannot be changed. NOTE: If Internet Fax is accessed via Authentication Mode the information contained will be linked with the login name.
  • Page 118: Entering An E-Mail Address For Internet Fax

    Entering an E-mail Address for Internet Fax E-mail addresses can be entered in one of two ways - manually or via an address book. NOTE: When entering e-mail details you can change the keypad to show upper or lower case, accented characters or numbers by selecting the appropriate button. Use the Back button to delete the previously entered character.
  • Page 119: Public Address Book

    Address Book Types If configured there are two different types of address book on your machine, Public and Internal. Public Address Book The Public Address Book stores external company addresses on the machine. The address book contains a list of user names and their e-mail addresses. The file must be a CSV (Comma Separated Value) format for your machine to be able to read the file contents.
  • Page 120: Image Adjustment

    Image Adjustment The Image Adjustment tab is used to temporarily program features to enhance the appearance and style of the scanned Internet Fax image. Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 121: Image Quality

    Image Quality Use this feature to enhance the quality of your scanned originals. Options: Use this option to enhance the quality of the output based on the type of original Original Type being scanned. Original Type options are as follows: ORMAL ALFTONE HOTO...
  • Page 122: More Image Quality

    More Image Quality Use this feature in addition to the settings selected using the Image Quality option, to further enhance the quality of your output. Options: This option controls the differences between the image densities within the output. Contrast Select a lower setting to improve the image quality of pictures. Select a higher setting to produce more vivid blacks and whites for sharper text and lines.
  • Page 123: Sides Scanned

    Sides Scanned This feature is used to specify whether the originals are single-sided or double- sided. For 2-sided originals the orientation can also be programmed. Options: Use this option for originals that are printed on 1 side only. 1 Sided Use this option for originals that are printed on both sides.
  • Page 124: Resolution

    Resolution Resolution affects the appearance of the scanned image. The higher the scanning resolution the better the image quality. Options: Produces the smallest image file size and is only recommended for use with simple 200x100 text documents. (Standard) NOTE: 200x100 is disabled if the Document Format is PDF. Recommended for use with average quality text documents and line art.
  • Page 125: Original Input

    Original Input Use this option to program the size of the originals being scanned or program the machine to determine the size of the originals automatically. Options: Use this option to allow the machine to automatically determine the size of the Auto originals being fed through the document handler.
  • Page 126: Output Format

    Output Format Use this feature to temporarily change the settings required for the scanned image. Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required. Multiple options can be selected for each fax job if required.
  • Page 127: Document Format

    Document Format Use the Document Format option when your job is to be sent with a different file format than that set as the default. Options: Multi-Page Tagged-Image File Format. One TIFF file containing several pages of Multi-page Tiff scanned images. Portable Document Format.
  • Page 128: Acknowledgment Report

    Acknowledgment Report Use this feature to print a report containing the delivery status of your job. The report will include the number of successful, failed and unconfirmed recipients. Options: Use this option to switch the feature off. Disabled NOTE: If the default setting for this feature is already Enabled you will not be able to disable this feature.
  • Page 129: Message Body

    Message Body Use this feature to edit the default e-mail message being transmitted with the job. The message body is the text contained within the e-mail and not the e-mail subject line. The message entered will only be available for the current job. NOTE: The default message is set up by your System Administrator.
  • Page 130: Authentication Mode

    Authentication Mode Authentication is a useful network security management tool - limiting, restricting and monitoring access to the network via the machine. Authentication can be set up by the System Administrator to restrict access to the features within Scan to E-mail, Network Scanning, Server Fax and Internet Fax.
  • Page 131: Network Scanning

    7 Network Scanning Scan...7-2 Network Scanning...7-3 Image Adjustment ...7-7 Output Format...7-14 Refresh Destinations ...7-18 Authentication Mode ...7-19 Quick Reference Guide Page 7-1...
  • Page 132: Scan

    Services open your web browser and enter the machine’s IP Address in the Address or Location field. Resources Provided on the World Wide Web www.xerox.com www.centreware.com Contains CentreWare general information with links to Page 7-2 This is a source of general solution overview and options for upgrade.
  • Page 133: Network Scanning

    Network Scanning Access to the Network Scanning features is gained using the Features button on the control panel. Depending on the options enabled and how your machine has been configured, you may have to select All Services in the top right-hand corner first. Use the Network Scanning tab on the touch screen to select the standard features for a scan job.
  • Page 134: Repositories

    Repositories Repositories are directories or filing locations set up on a server where your scanned files are held. Before you can use Network Scanning your System Administrator must set up the repositories available to your machine. The repositories are defined in the template and cannot be changed at the machine. Up to 5 repositories (1 default and 4 additional) can be defined.
  • Page 135: Template Destinations

    Template Destinations The Template Destination lists the templates stored on the machine. On installation the factory default template ’DEFAULT’, in upper case, will be displayed in the Template Destination list. The default template appears at the top of the list and is selected automatically.
  • Page 136: Destination Details

    Destination Details The Destination Details section on the right side of the screen displays information about the selected template. Each time you select another template file, this area will update to display information associated with the selected template. NOTE: Any changes made to the template at the machine are temporary. Permanent changes must be made with the same utility that created the template.
  • Page 137: Image Adjustment

    Image Adjustment The Image Adjustment tab is used to program features relating to the scanned images. Review Summary Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required. Multiple options can be selected for each scan job if required.
  • Page 138: Image Quality

    Image Quality Use this feature to enhance the quality of your scanned originals. Options: Use this option to enhance the quality of the output based on the type of original Original Type being scanned. Original Type options are as follows: ORMAL ALFTONE HOTO...
  • Page 139: More Image Quality

    More Image Quality Use this feature in addition to the settings selected using the Image Quality option, to further enhance the quality of your output. Options: This option controls the differences between the image densities within the output. Contrast Select a lower setting to improve the image quality of pictures. Select a higher setting to produce more vivid blacks and whites for sharper text and lines.
  • Page 140: Sides Scanned

    Sides Scanned This is used to specify whether the originals are single-sided or double-sided. For 2-sided originals the orientation can also be programmed. Options: Use this option for originals that are printed on 1 side only. 1 Sided Use this option for originals that are printed on both sides. 2 Sided Use this option for originals that are printed on both sides and the second side has 2 Sided, Rotate...
  • Page 141: Edge Erase

    Edge Erase Use this feature to “refresh” the quality of an original that has become torn or frayed at the edges, or that has hole punch, staple or other marks. Options: Erases equal amounts on all edges of your output image. Up to 2.0 inches in Border Erase 0.05 in.
  • Page 142: Original Input

    Original Input Use this option to program the size of the originals being scanned or enable the machine to recognize the size of the originals. Options: Use this option to allow the machine to determine the size of the originals being fed Auto through the document handler.
  • Page 143: Resolution

    Resolution Resolution affects the appearance of the scanned image. The higher the scanning resolution the better the image quality. Options: Recommended for use with average quality text documents and line art. Does not 200x200x1 produce the best image quality for photos and graphics. Recommended for use with high quality text documents, that are destined to pass 300x300x1 through OCR applications.
  • Page 144: Output Format

    Output Format Use the features available to temporarily change the format of the scanned image file at the destination server. Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required. Multiple options can be selected for each scan job if required.
  • Page 145: If File Already Exists

    If File Already Exists Use this option to tell the machine what to do when the document destination folder already contains a document with the same name as your current scan job. Options: Use this option when you want the machine to name the new file (or folder) with a Rename New unique name.
  • Page 146: Document Format

    Document Format Use this feature to temporarily change the file type of the scanned image file at the destination server. The default setting is the same as the value entered in the selected template. Options: Tagged-Image File Format. A graphic file that can be opened in a variety of graphic Tiff software packages across a variety of computer platforms.
  • Page 147: Document Management Fields

    Document Management Fields Document Management Fields allows you to enter information into the template from your machine which is unique to your scanning requirements. These fields must be enabled when creating the template at the Web UI. NOTE: If your selected template does not contain any enabled fields the Document Management Fields button will not be available.
  • Page 148: Refresh Destinations

    Refresh Destinations Select the Refresh Destinations tab to access the Update Template List feature. Touch the Update Template List button if the template has been recently created or modified. The system automatically updates the Template List. Page 7-18 Quick Reference Guide...
  • Page 149: Authentication Mode

    Authentication Mode Authentication is a useful network security management tool - limiting, restricting and monitoring access to the network via the machine. Authentication can be set up by the System Administrator to restrict access to the features within E-mail, Network Scanning, Server Fax and Internet Fax.
  • Page 150 Page 7-20 Quick Reference Guide...
  • Page 151: 8 E-Mail

    8 E-mail E-mail...8-2 Image Adjustment ...8-6 Output Format...8-13 Authentication Mode ...8-17 Quick Reference Guide Page 8-1...
  • Page 152: E-Mail

    E-mail E-mail is an optional feature which is only available on the WorkCentre and WorkCentre Pro. This chapter contains information about the options available within E-mail. NOTE: E-mail is only supported on the WorkCentre via the Ad Hoc E-mail options kit.
  • Page 153: Send

    Send: Use the Send options to enter recipient information. Options: This option provides information about the sender and is pre-set by the system or From the System Administrator and cannot be changed. NOTE: If E-mail is accessed via Authentication Mode the information contained will be linked with the login name.
  • Page 154: Address List

    Address List Displays all the recipient addresses entered for the current scan to e-mail job. Up to 128 recipients addresses can be entered in the list. Entering an E-mail Address The e-mail address can be entered in one of two ways - manually or via an address book.
  • Page 155 If one or more matches are found based on the search criteria, the matches are displayed on the touch screen. Use the up and down scroll bars to locate the recipient. Highlight the recipient in the list and select the Add button. Continue this process until you have added all the required recipients and on completion select Done.
  • Page 156: Image Adjustment

    Image Adjustment The Image Adjustment tab is used to temporarily programme features to enhance the appearance and style of the scanned e-mail image. Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 157: Image Quality

    Image Quality Use this feature to enhance the quality of your scanned originals. Options: Use this option to enhance the quality of the output based on the type of original Original Type being scanned. Original Type options are as follows: ORMAL ALFTONE HOTO...
  • Page 158: More Image Quality

    More Image Quality Use this feature in addition to the settings selected using the Image Quality option, to further enhance the quality of your output. Options: This option controls the differences between the image densities within the output. Contrast Select a lower setting to improve the image quality of pictures. Select a higher setting to produce more vivid blacks and whites for sharper text and lines.
  • Page 159: Sides Scanned

    Sides Scanned This is used to specify whether the originals are single-sided or double-sided. For 2-sided originals the orientation can also be programmed. Options: Use this option for originals that are printed on 1 side only. 1 Sided Use this option for originals that are printed on both sides. 2 Sided Use this option for originals that are printed on both sides and the second side has 2 Sided, Rotate...
  • Page 160: Edge Erase

    Edge Erase Use this feature to “refresh” the quality of an original that has become torn or frayed at the edges, or that has hole punch, staple or other marks. Options: Erases equal amounts on all edges of your output image. Up to 2.0 inches in Border Erase 0.05 in.
  • Page 161: Original Input

    Original Input Use this option to programme the size of the originals being scanned or enable the machine to recognize the size of the originals automatically. Options: Use this option to allow the machine to recognize the size of the originals being fed Auto through the document handler.
  • Page 162: Resolution

    Resolution Resolution affects the appearance of the scanned image. The higher the scanning resolution the better the image quality. Options: Recommended for use with average quality text documents and line art. Does not 200x200x1 produce the best image quality for photos and graphics. This is the default option. Recommended for use with high quality text documents, that are destined to pass 300x300x1 through Optical Character Recognition (OCR) applications.
  • Page 163: Output Format

    Output Format Use this feature to change the Reply To e-mail address and to identify the file format required for the e-mail scanned image. Review Summary Touch any of the top level buttons to select a feature. To view all the options for a feature, select the feature required.
  • Page 164: Document Format

    Document Format Use the Document Format option when the job is to be sent with a different file format than that set as the template default. Options: Tagged-Image File Format. A graphic file that can be opened in a variety of graphic Tiff software packages across a variety of computer platforms.
  • Page 165: Reply To

    Reply To Use the Reply To feature to alter the default address to which replies to an e-mail job can be sent. Message Body Use this feature to edit the default e-mail message. The message body is the text contained within the e-mail and not the e-mail subject line. Quick Reference Guide Page 8-15...
  • Page 166: Secure Send

    Secure Send This feature enables secure sending of your e-mails using a third party secure e- mail server solution. The secure e-mail server ensures that the e-mail transmission cannot be intercepted by an unauthorised recipient. This feature will only be available if the following conditions apply: - E-mail is installed and enabled.
  • Page 167: Authentication Mode

    Authentication Mode Authentication is a useful network security management tool - limiting, restricting and monitoring access to the network via the machine. Authentication can be set up by the System Administrator to restrict access to the features within E-mail, Network Scanning, Server Fax and Internet Fax.
  • Page 168 Page 8-18 Quick Reference Guide...
  • Page 169: Print

    9 Print Introduction to Print...9-2 Print Driver Features...9-3 Print Drivers ...9-4 Quick Reference Guide Page 9-1...
  • Page 170: Introduction To Print

    Introduction to Print The Xerox WorkCentre and WorkCentre Pro printer produces high quality prints from electronic documents. Simply access the printer from your PC application as normal. A print driver converts the code within the electronic document into a language that the printer can understand. Although generic print drivers can be used on this printer they will not enable all the features.
  • Page 171: Print Driver Features

    Print Driver Features Control Options There are a number of options which appear on all of the printer driver screens: Saves all the new settings and closes the driver or dialog. These new settings remain in effect until changed or until the software application is closed and the printer driver options revert to the default settings.
  • Page 172: Print Drivers

    Print Drivers NOTE: The following provides an overview of the features available on the WorkCentre Pro Postscript Print Driver - the appearance of other print drivers may vary. For more information about a specific feature, please refer to the on-line Help facility provided as part of the Print Driver software.
  • Page 173: Advanced

    Advanced Select this tab to access the postscript options and advanced programming features for your print job. Use the scroll arrows to move through the options. Clicking on a plus symbol will display further choices. Image Options Use the options available in this tab to modify the appearance of your print job. This feature can also be used to set the margins.
  • Page 174: Layout/Watermark

    Layout/Watermark Used to change the layout of a document and add watermarks. Documents can be printed 1 Up, 2 Up and so on, up to 16 Up. Booklets can also be created. Use the Watermark option to display, for example, the word DRAFT or CONFIDENTIAL across each page.
  • Page 175: Maintenance

    10Maintenance Consumables ...10-2 Cleaning the Machine ...10-4 Further Assistance ...10-5 Quick Reference Guide Page 10-1...
  • Page 176: Consumables

    Consumables Consumables are items on the machine that need replenishing or replacing, such as paper, staples, and customer replaceable units.To place an order for Xerox consumables, please contact your local Xerox Representative giving your Company Name, product number and the machine serial number.
  • Page 177: Staple Cartridges

    Maintenance section of the Training and Information CD (CD2), contained in the CD Pack delivered with your machine. HINT: To place an order for any Xerox consumables, please contact your local Xerox Representative giving your Company Name, product number and the machine serial number.
  • Page 178: Cleaning The Machine

    Document Glass and Constant Velocity Transport Glass Apply Xerox Cleaning Fluid or Xerox Anti-Static Cleaner, to a to a lint-free cloth. Liquid should never be poured directly onto the glass.
  • Page 179: Further Assistance

    Further Assistance For any additional help visit our customer web site at www.xerox.com or contact the Xerox Welcome and Support Cente Press the Machine Status button on the control panel. The Machine Information screen will be displayed. Select [Machine Details].
  • Page 180 Page 10-6 Quick Reference Guide...
  • Page 181: Troubleshooting

    11Troubleshooting General ... 11-2 Fault Clearance ... 11-3 Xerox Welcome and Support Center ... 11-4 Troubleshooting Tips... 11-5 Quick Reference Guide Page 11-1...
  • Page 182: General

    General A variety of situations can affect the quality of your output. For optimal performance, ensure the following guidelines are followed: • Do not position the machine in direct sunlight or near a heat source such as a radiator. • Avoid sudden changes in the environment surrounding the machine. When a change occurs, allow the machine at least two hours to adjust to its new environment, depending on the extent of the change.
  • Page 183: Fault Clearance

    If you are unable to clear the fault, refer to the next section to contact your local Xerox Welcome and Support Center for assistance. NOTE: For additional Troubleshooting information please refer to the Training and Information CD (CD2) or the System Administration CD (CD1).
  • Page 184: Xerox Welcome And Support Center

    If a fault cannot be resolved by following the touch screen instructions, check the Troubleshooting Tips in the next section - they may help to solve the problem quickly. If the difficulty persists, contact the Xerox Welcome and Support Center. The Welcome and Support Center will want to know the following information: The nature of the problem, the Machine Serial number, the fault code (if any) plus the name and location of your company.
  • Page 185: Troubleshooting Tips

    Troubleshooting Tips For additional Troubleshooting information please refer to the Training and Information CD (CD2), the System Administration CD (CD1) or www.xerox.com. Power The machine will not power on: Check to see that the machine is not in Low Power Mode as indicated by the green light on the control panel.Touch the User Interface screen to re-activate.
  • Page 186: Paper Handling

    Paper Handling Repeated paper jams, misfeeds or multisheet feeds Ensure that the correct paper size is displayed on the Touch Screen. Ensure that the paper tray is not filled above the MAX line. Ensure that the edge guides are adjusted to touch the sides of the paper. Flip the paper over in the paper tray, ’fanning’...
  • Page 187: Finisher

    Check that the Touch Screen is displaying the correct size for the paper in use. Load fresh paper. Repeated Check Tray Messages on the Touch Screen and the paper is loaded in the tray Adjust the edge guides against the stack of paper in the tray. If the edge guides were not set against the paper stock in the tray when Start was selected, delete the job in the job queue and begin again.
  • Page 188: Output Quality

    The Finisher does not staple or hole punch correctly For incorrect stapling, use less than 50 sheets of paper if the paper is heavier than 20 lb. The maximum number of sheets is 20 when stapling heavyweight paper. Check the correct option has been selected on the Touch Screen. Check the Touch Screen for a fault message indicating no staples.
  • Page 189 Streaks, lines, spots, or black, solid, or dotted lines on the prints Clean the Document Glass and, if using the Document Handler, also clean the Constant Velocity Transport Glass (the thin strip of glass to the left of the document glass), especially near the plastic ramp on the glass. Clean the white underside of the Document Handler/Document Cover.
  • Page 190 Clean the Document Glass and if using the Document Handler also clean the Constant Velocity Transport Glass (the thin strip of glass to the left of the document glass), especially near the plastic ramp on the glass.Refer to “Document Glass and Constant Velocity Transport Glass” on page 10-4. Missing characters on output Load fresh paper.
  • Page 191: Fax

    Output does not reflect the selections made on the Touch Screen Press Clear All between jobs. If a Save button displays on the touch screen, ensure Save is selected after each selection. The image is reduced on a transmission Confirm the original size of the documents. Documents may be reduced on the available paper supply at the receiving fax machine.
  • Page 192 Page 11-12 Quick Reference Guide...
  • Page 193 12Index Numerics 2-Sided Copy 4-6 Acknowledgment Report Internet Fax 6-14 Add File Destination Network Scanning 7-17 Added Fax Features Embedded Fax 5-13 Additional Resources 1-3 Address List E-mail 8-4 Advanced Print 9-5 Advanced Fax Features Embedded Fax 5-21 Authentication Mode E-mail 8-17 Internet Fax 6-16 Network Scanning 7-19...
  • Page 194 Dialing Options Server Fax 5-26 Dialling Options Embedded Fax 5-4 Document Format E-mail 8-14 Internet Fax 6-13 Network Scanning 7-16 Document Glass Constant Velocity Transport Glass Document Handler Troubleshooting Tips 11-5 Document Management Fields Network Scanning 7-17 Document Name Network Scanning 7-14 Edge Erase Copy 4-16 E-mail 8-10...
  • Page 195 Print 9-6 Loading Paper 3-4 Locating the serial number 11-4 Logging On / Off 3-13 Machine Features Overview 1-6 Mailboxes Embedded Fax 5-20 Maintenance Power On or Off 3-3 Making Copies 3-5 Message Body E-mail 8-15 Internet Fax 6-15 More Fax Features Server Fax 5-29 More Image Quality Copy 4-14...
  • Page 196 Training and Information CD Additional Resources 1-3 Transmission Options Embedded Fax 5-14 Transparencies Copy 4-20 Troubleshooting Tips 11-5 Utilities CD Additional Resources 1-3 WorkCentre Overview 2-5 WorkCentre Pro Overview 2-7 Workstation Features Overview 1-8 Xerox Welcome and Support Center 11-4 Quick Reference Guide...

Table of Contents
