Habitat RAYNER 1979288 Manual

Cat No. Product Description
1979288 RAYNER PLUG IN WALL LIGHT BLACK
1979295 RAYNER PLUG IN WALL LIGHT SATIN BRASS
Caution: This product contains one light source of energy efficiency class E
Care & Instruction Manual
For household and indoor use only. Please read and retain these instructions for future reference
IMPORTANT! The external flexible cable or cord of this luminaire cannot be replaced. If the cord is damaged,
the luminaire shall be destroyed.

Installation

1. Carefully unpack the lamp and put it on a soft and flat surface
2. Remove the mounting bracket (②) from the fitting (④), by unscrewing the retaining screws (⑤) on the sides
of the lamp. Using the mounting bracket (②) as a template, mark the position of the fixing holes on the
mounting surface.
3. Pre-drill fixing holes taking care not to damage any pipes or mains cables beneath the surface.
4. Securely fasten the metal mounting bracket (②) to the wall using mounting screws (③) and wall plugs (①),
(supplied). Ensure that you do not trap or strain any cables between the mounting surface and the bracket.
5. Place th e canopy of the fitting ( ④ ) over the mounting bracket and secure back into position by replacing
the two retaining screws ( ⑤ ).
6. Place the bulb (⑥) (ES/E27 LED 4W bulb, bulb is included) into the lamp holder.
7. Use the cable clips (⑦) provided to secure the cable to the wall.
8. Plug in the lamp. Then switch on/off the lamp.

Replacement Lamp

1. Switch off the mains power supply.
2. Before replacing the bulb, allow it to cool down for at least 10 minutes.
3. Never touch the bulb with your fingers directly, cover it with a cloth.
4. Loosen the bulb and remove it from the lamp.
5. Replace a new bulb with same voltage and wattage
Image reference
