LEDWALL4025IP
40x25W RGBW LED Wash Light
This product manual contains important information about the safe installation and use of the light. Please read
and follow these instructions carefully and keep this manual in a safe place for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LEDWALL4025IP and is the answer not in the manual?

Questions and answers

Related Manuals for Avtech LEDWALL4025IP

Summary of Contents for Avtech LEDWALL4025IP

  • Page 1 LEDWALL4025IP 40x25W RGBW LED Wash Light This product manual contains important information about the safe installation and use of the light. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
  • Page 2 2/14...

  • Page 3: Table Of Contents

    Content Safety warning instructions Installation Signal and power connection Function setting DMX address setting Operation menu DMX Channel Maintenance Trouble shooting Technical data Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good condition before installation and use.
  • Page 4 Safety warning information After receiving the lights, please open to check whether there is any damages caused by transportation. In case of damages caused of transportation, please don’t this device and contact your dealer or manufacturer as soon as possible. he projector is for indoor and outdoor use, IP65.

  • Page 5: Signal And Power Connection

    Always disconnection from Power before the device’s installation, cleaning and maintenance Installation Take out 2 clamps and 1 safety rope, install the 2 clamps on the bottom of the fixture with the 4 quick knob attached to the clamps , then hang the fixture on the fixed support with the clamp, and tighten the clamp lock bolt to fix the fixture.
  • Page 6 For the connection of control signals, 2-pin shielded cables with a diameter not less than 0.5 mm must be used between the fixture and the controller and between the fixtures. Please use the 3-pin signal output / incoming line of the lamp to connect. The connections between the 3-pin signal line ports are shown in the figure above. It must be noted that the 3 pin of the XLR plug / socket must not be in contact with the inner shell or between the cores when connecting.

  • Page 7: Dmx Address Setting

    Function and installation power-on password: UP - DOWN- UP - DOWN- ENTER Press button UP or DOWN if you want to browse through the various Setup Options. Press button ENTER to save your settings or enter the next menu. Press button UP or DOWN to shift. Press button Menu will return to the upper menu one by one.

  • Page 8: Operation Menu

    Operation menu Level 1 Level 2 Level 3 DMX address 1-512 Cancel Enter DMX channel mode 4 channel mode 1 10 channel mode 2 37 channel mode ONCA (Only XLR) ONWR (Only wireless) DMXS PPCA (XLR first) DMX setting PRWR (wireless first) WTOC (wireless to XLR) PAIR Dimmer curve...

  • Page 9: Dmx Channel

    DMX channel Run time Use time Temperature Remarks： 1、 Only one fixture can be set to host in one signal line, remove DMX control signal when using host function 2. In the synchronous control of multiple fixtures parameters can be transmitted from the master including: DMX mode, display setting, operation mode (user memory data included);...
  • Page 10 4 Channel Channel Name DMX Value DMX Percentage Description 0-255(65535) 0-100% 0-100% R Green 0-255(65535) 0-100% 0-100% G Blue 0-255(65535) 0-100% 0-100% B White 0-255(65535) 0-100% 0-100% W 10 Channel ( CTC) Channel Name DMX Value DMX Percentage Description Dimmer 0-255 0-100% 0-100%Intensity...

  • Page 11: Maintenance

    200-244 78.4%-95.7% Variable Random Strobe 245-255 96.1%-100% Shutter Open Macro 0-255 0-100% 0-100%Intensity Macro Speed 0-255 0-100% 0-100%Intensity Macro Color 0-255 0-100% 0-100%Intensity Red1 0-255 0-100% 0-100% R Green1 0-255 0-100% 0-100% G Blue1 0-255 0-100% 0-100% B White1 0-255 0-100% 0-100% W ..

  • Page 12: Trouble Shooting

    To ensure the reliability of the projector it should be kept clean. It is recommended that the fans should be cleaned every 15 days. The lens and dichroic color filters should also be regularly cleaned to maintain an optimum light output. Do NOT use any type of solvent on dichroic color filters.
  • Page 13 Input voltage： AC 100V/120V/200V/220V /230V/240V 50/60Hz Power ： 600W@220V LED light source： 40PCS 25W RGBW Working lifetime 50000h Dimmer ： 0-100% linear dimming Strobe ： Max 20 Hz Electric strobe，0.3-20pcs/sec Control mode： International standard DMX 512signal，3 Pin (5 Pin) DMX512 interface RDM Wireless ：2.4 GHz W-DMX™...
  • Page 14 14/14...
