  • Page 1 R2DSPOT60 60W Mini Moving Head Spot User Manual...
  • Page 2 Unpacking The following items are included in the box: ■ 1 x R2DSPOT60 ■ 1 x Power Cord ■ 1 x User Manual Carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition.
  • Page 3 1.3 Features ▪ LED Spot moving head ▪ 1 color wheel: 7 colors + white, rainbow ▪ 1 Gobo wheel: 5 gobos + open, shaking ▪ 1 3-facet prism ▪ Motorized focus ▪ 4 working modes: DMX, Auto, Sound, Master/Slave ▪...
  • Page 4 3. OPERATION INSTRUCTIONS 3.1 Menu Map MENU Scroll through the main menu or exit from the current sub-menu the currently selected menu or confirm the current DOWN function value Scroll through the menu list or decrease the value of the current function value Scroll through the menu list or increase the value of the ENTER...
  • Page 5 3.2 DMX Channels 15Ch DMX Value Func on 000 - 255 000-255 Pan Fine 000 - 255 Tilt 000-255 Tilt Fine 000 - 255 XY Speed from fast to slow 000-255 Dimmer 0-100% 000-004 Strobe closed 005-250 Strobe from slow to fast 251-255 Strobe open 000-013...
  • Page 6 000-009 No func on 010-129 Forward Gobo rota on from fast to slow 130-134 No rota on 135-255 Backward Gobo rota on from slow to fast 000-255 Focus 0 - 100% 000-007 No func on 008-127 Prism on 128-192 Gobo rota ng CW from fast to slow 193-255 Gobo rota ng CCW from slow to fast 000-007...
  • Page 7 4. Specifications Source: 1 x 60W white LED Beam angle: 13° Power consumption: 80W Max. Power supply: 100~240V, 50-60Hz Dimensions: 195 x 145 x 280 mm Weight: 4.5 kg MPORTANT INFORMATION! In order to optimize the recovery and recycling of the materials that old appliances contain and reduce the impact on human health and the environment, ensure that this product is recycled at the end of its life.
