  • Page 1 QUICK GUIDE DIGITAL CONTROL 2024 v.1 DRUMFILTERS...
  • Page 2: Table Of Contents

    QUICKGUIDE Index BASIC REQUIREMENTS ....................3 1.1 Control unit ......................4 1.2 Configuration ......................5 1.3 Options WiFi module ....................6 A. GRAVITY-SYSTEM ....................7 2.1 Placing the filter system ..................7 2.2 Schematic setup ...................... 8 2.3 Set level control ....................... 8 B.
  • Page 3: Basic Requirements

    QUICKGUIDE 1 Basic requirements Basic requirements every filter system must meet: • The filter system should be placed on a ground surface with sufficient carrying capacity, for instance: ▪ a well-vibrated sand bed of 10 cm, possibly with concrete tiles ▪...
  • Page 4: Control Unit

    QUICKGUIDE 1.1 Control unit Controller is not waterproof, please keep it out of the water. Place it under cover from the rain! Power Switch Manual Cleaning Plug Plug Sensor Motor Drumfilter Plug Plug Cleaning Pump Circulation Pump...
  • Page 5: Configuration

    QUICKGUIDE 1.2 Configuration → DELAY TIME : Log in to the WiFi module: set time when pond pump switches off Look for new networks: DVS FILT (delay to power off) 2-25s Password: Welkom123# → DRY RUN TIME : set the time that the pond pump remains off (delay to power on) 10-70s Go to the internet browser, →...
  • Page 6: Options Wifi Module

    QUICKGUIDE 1.3 Options WiFi module The options below are only possible in combination with a WiFi module. Temperature sensor Sensor water refill Solenoid valve waste cleaning Solenoid valve refilling pond...
  • Page 7: Gravity-System

    • The filter should be placed the height of the installation height (pic. 2.1) above water level. (installation height is the distance from maximum water level to top of filter). Type filter Installation hight Type filter Installation hight [cm] [cm] ECO 20 ENTRY C25 ECO 22 ENTRY C25 low PP35 ENTRY M25 PP40 PP65...
  • Page 8: Schematic Setup

    QUICKGUIDE GRAVITY 2.2 Schematic setup • • To get the best out of the RDF, use all of the For Gravity, the water level of the pond must lined with the top of the water inlets at 4”. This result in good water turn RDF waste tray.
  • Page 9 QUICKGUIDE GRAVITY Pic. 2.4 Schematic setup of the combi filter...
  • Page 10: Pump Fed System

    QUICKGUIDE PUMP FED 3 B. Pump fed system Schematic setup Placing the filter system • • For Pump fed, you can use a water pump to push water from the Determine the maximum water level pond/skimmer into the RDF and from the RDF the water gravity flow back of the pond •...
  • Page 11 QUICKGUIDE PUMP FED Pic. 3.4 Schematic setup of the combi filter...
