SHORTCUT KEY FUNCTION
| Spacebar (Double click) | Wake the keyboard |
| Fn+F1 (Hold for 5s) | Wired Mode |
| Fn+F2 (Hold for 5s) | Bluetooth A |
| Fn+F3 (Hold for 5s) | Bluetooth B |
| Fn+F4 (Hold for 5s) | Bluetooth C |
| Fn+F5 (Hold for 5s) | Switching Wireless Mode |
| Fn+F9 (Hold for 5s) | Layer 1 |
| Fn+F10 (Hold for 5s) | Layer 2 |
| Fn+F11 (Hold for 5s) | Standard Layer |
| Fn+F12 (Hold for 5s) | Mac Mode |
| Fn+Backspace | Calculator |
| Fn+ - (numpad) | Volume - |
| Fn+ + (numpad) | Volume + |
| Fn+Enter (numpad) | Mute |
| Fn+Enter (mainboard) | Bluetooth Pairing |
| Fn+0 (numpad, hold for 5s) | Backlight on/off Under the Wireless Mode |
| Fn+.Del | Sleep Mode |
| Fn+Tab | Toggle Underglow Lights |
| Fn+ ~ | Toggle Backlight Effects |
| Fn+↑ | Backlight Brightness + |
| Fn+↓ | Backlight Brightness - |
| Fn+← | Previous Track |
| Fn+→ | Next Track |
| Fn+Win-L | Win lock |
| Fn+Esc (Hold for 5s) | Reset the keyboard |
CHANGE RGB EFFECTS
Pressing Fn+ ~ to switch the RGB effect of your Everglide SK98 keyboard kit.
PAIRING BLUETOOTH
Hold Fn+F2 / Fn+F3 / Fn+F4 for 5 seconds to choose one Bluetooth device.
Hold Fn+Enter (Mainboard) for 5 seconds to start the pairing mode. Turn on the Bluetooth setting and search for 'SK98', then pair.
After the hold Fn+F2/F3/F4 to toggle between the Bluetooth devices A/B/C.
WIRED MODE
Holding Fn+F1 for 5 seconds to switch to the wired mode.
DRIVING OPERATING ENVIRONMENT
Windows 7 or later, Windows 10 is recommended.
SPECIFICATION PARAMETER
| KEYS AMOUNT: | 98 Keys |
| STRUCTURE: | Gasket-mounted |
| STABILIZER TYPE: | Screw-in |
| PCB TYPE: | Hotswap PCB |
| PLATE MATERIAL: | PC/Carbon |
| BATTERY CAPACITY: | 10000mAh |
| CONNECTIVITY: | Type-C Wired & Bluetooth Wireless |
| ANTI-GHOST KEY: | NKRO in all modes |
| COMPATIBILITY: | WINDOWS/MAC |
| DIMENSION: | 387 x 143 x 33 mm |
| WEIGHT: | Around 1.65kg |
REPLACING KEYCAPS AND SWITCHES
For a full guide on how to remove keycaps and switches scan the QR Code or type in your browser: https://epomaker.com/blogs/guides/diy-guide-how-to-remove-and-replace-your-mechanical-keyboard-switches
Remove Switches
- Grab your Switch Removal Tool and align the gripping teeth vertically (on the Y-Axis) at the center of the switch, as shown in the example graphic above.
- Grab the switch with the Switch Puller and apply pressure until the switch releases itself from the plate.
- Using firm but gentle force pull the switch away from the keyboard using a vertical motion.
Install Switches
- Check that all the switch metallic pins are perfectly straight and clean.
- Align the switch vertically to have the Gateron logo facing north. The pins should align themselves to the keyboard PBC.
- Press the switch down until you hear a click. This means your switch clips have attached themselves to the keyboard plate.
- Inspect the switch to ensure it's properly attached to your keyboard, and test it.
Note: If the key doesn't work its possible you may have bent one of the switches while installing it. Pull the switch out and repeat the process.
Pins may be damaged beyond repair and need replacement if this process is not done correctly. Never apply excessive force when replacing keycaps or switches. If you cannot remove or install keycaps or switches please contact customer service as soon as possible to avoid damage to the keyboard due to operating errors.
TECHNICAL ASSISTANCE
For technical assistance, please email to support@epomaker.com with your purchase order number and a detailed description of your issue.
We normally respond to enquiries within 24 hours. If you purchased your keyboard from a distributor or not from any official store of Epomaker, please contact them directly for any additional help.
COMMUNITY FORUMS
Join our community and learn together with other keyboard enthusiasts.
https://www.reddit.com/r/Epomaker/
Should you require more assistance please email us at support@epomaker.com
Manufacturer: Shenzhen Changyun Technology Co., Ltd.
Address: Seventh Floor, Kai Daer Building, No.168 Tongsha Road, Xili Street, Nanshan Disctrict, Shenzhen, Guangdong, CN
Email: support@epomaker.com
Web: www.epomaker.com
APEX CE SPECIALISTS LIMITED
Address: UNIT 3D NORTH POINT HOUSE, NORTH POINT BUSINESS PARK, NEW MALLOW ROAD CORK, T23 AT2P, IRELAND
Contact: Wells
Tel: +353212066339
Email: info@apex-ce.com
