Hydra-Flex RIPSAW Instructional Sheet

1. OVERVIEW

This manual is prepared to provide the operator with the basic information
needed to operate the Ripsaw™ Rotating Hydro-Excavation nozzle. The
operating recommendations in the manual will ensure that you receive
satisfactory nozzle performance. All operating personnel responsible for the
care of this equipment should be familiar with the information in this manual.
If you have any questions or problems with this equipment, please contact the
distributor you obtained the product from.

2. SAFETY WARNING!

Operations with this equipment can be potentially dangerous if caution is not exercised prior to and during tool use. Please read and
follow all of these instructions to ensure adequate safety.
• Always wear the proper PPE (Personal Protective Equipment) when using
these nozzles.
• Do not point nozzles at people or animals. Serious injury can result from
high-pressure water from these nozzles.
• Nozzles are recommended for use with high-pressure spray wand with
automatic shut off (Dead man's switch).
• Always observe proper grounding procedures when performing hydro-
excavation.
• Urethane coating on the nozzle tip is designed for safety. Replace nozzle
when urethane coating is worn.
• A distance of at least 8" must be maintained between the nozzle tip and
the underground facility and/or subsoil. The nozzle should never be
inserted into the soil.
• The wand/nozzle shall never remain motionless during excavation.
Aiming directly at the underground utilities should be avoided at all times.

3. FLOW RATES

RIPSAW HD
NOZZLE
NOZZLE PART
SIZE
NUMBER
3.0 1002719-030
4.0 1002719-040
5.0 1002719-050
6.0 1002719-060
8.0 1002719-080
10.0 1002719-100
12.0 1002719-120

4. SPECIFICATIONS

Minimum Inlet Pressure
Maximum Inlet Pressure
Housing Material

5. TROUBLE SHOOTING

My nozzle stream is failing to rotate
(Lasering).Water is going around the nozzle
and not through it (blow-by).
No flow, low flow, or not enough
impingement.
RIPSAW™ ROTATING HYDRO-EXCAVATION NOZZLE
REPAIR KIT PART
NUMBER
@ 1000 PSI
1001858-030 1.5 GPM
1001858-040 2.0 GPM
1001858-050 2.5 GPM
1001858-060 3.0 GPM
1001858-080 4.0 GPM
1001858-100 5.0 GPM
1001858-120 6.0 GPM
1,000 PSI Maximum Water Temperature
3,200 PSI Nozzle Tip & Seat Material
Stainless Steel Inlet Connection Thread
Check your pressure. Pressure for this nozzle should be set at a minimum of 1,000 PSI at nozzle. (3,200 PSI Max.)
Check inlet screen for debris. Clean and/or replace.
Nozzle may fail to rotate based on normal wear and tear, it may be time to rebuild. Refer to our repair kit.
Increase your pump pressure. (Pump must remain between 1,000 PSI (min) and 3,200 PSI (max). Check for
desired result.
Change nozzle to a larger nozzle size (higher flow rate). Check for desired result.
INSTRUCTIONAL SHEET
REV C
952-808-3640 • hello@hydraflexinc.com
• Observe the referenced industry best practices for recommended
maximum pressures for rotating nozzles within 18" of utilities. Within 18"
of utilities the operator should lower water inlet pressure from normal
operating pressure to a maximum of 1500PSI and use the nozzle to "wash
down" the utility, not to blast.
• Static nozzles are not to be used within 18" of utilities.
• Be sure pump is shut off and disconnected prior to performing
maintenance or replacing this nozzle.
• This nozzle is not intended for chemical application. Running chemicals
through the nozzle may reduce the life of the nozzle.
• Select the nozzle size based on intended application and performance.
• Follow all applicable national, state, and local safety regulations.
FLOW RATE CHART (GPM)
@ 1500 PSI @ 2000 PSI
1.8 GPM 2.1 GPM
2.4 GPM 2.8 GPM
3.1 GPM 3.5 GPM
3.7 GPM 4.2 GPM
4.9 GPM 5.7 GPM
6.1 GPM 7.1 GPM
7.3 GPM 8.5 GPM
180ºF (+82ºC)
Tungsten Carbide
1/2" FNPT
4000224_RevB0120
MANUFACTURER:
HYDRA-FLEX, INC.
www.hydraflexinc.com
@ 2500 PSI @ 3000 PSI
2.4 GPM 2.6 GPM
3.2 GPM 3.5 GPM
4.0 GPM 4.3 GPM
4.7 GPM 5.2 GPM
6.3 GPM 6.9 GPM
7.9 GPM 8.7 GPM
9.5 GPM 10.4 GPM
Coating Material
@ 3200 PSI
2.7 GPM
3.6 GPM
4.5 GPM
5.4 GPM
7.2 GPM
8.9 GPM
10.7 GPM
Hytrel
