Summary of Contents for Hydra-Flex REAPER REVALUTION
- Page 1 User Manual REV B 4000317 RevB Hydra-Flex, Inc 2023...
- Page 3 Nozzle Connection and Operation SPECIFICATIONS AND FLOW RATES REPAIR KITS AND PARTS TROUBLESHOOTING WARRANTY For additional tech support call your exclusive Revolution Dealer or contact Hydra-Flex at 952-808-3640 or hydraflexinc.com. For more info or for part info visit: hydraflexinc.com/jetting-nozzles/ View catalog: hydraflexinc.com/literature/...
- Page 4 All personnel who will operate and care for this equipment should be familiar with the information in this manual. To report a problem, ask questions, order repair kits and parts, or request additional repair instructions, contact your distributor, or contact Hydra-Flex at hello@hydraflexinc.com or 952-808-3640.
- Page 5 SPECIFICATIONS PIPE SIZE PRESSURE RANGE 6-36 in (152-914 mm) 1,000-2,500 PSI (69-172 Bar) OUTSIDE DIAMETER OUTSIDE DIAMETER WITH CENTRALIZER OVERALL LENGTH WEIGHT 3.5 in (89 mm) 5 in (127 mm) 9.25 in (234.95 mm) 15 lbs MAX. WATER TEMP. FLOW RANGE WEIGHT WITH CENTRALIZER 180ºF (82C) 40-80 GPM (152-303 LPM)
- Page 6 (2,500 PSI max or 172 bar). Check inlet screen for debris. Clean and/or replace. The nozzle does not have enough thrust. Install the front rotor block. Change nozzle to a larger size (higher flow rate). Check for desired result. 6 | Hydra-Flex, Inc. 2023...
- Page 7 Period of warranty shall be 90 days from the date product is shipped from Hydra-Flex, Inc.’s facility, a 1-year warranty will be offered on non-wear items.. Liability of manufacturer under the foregoing warranty is limited to repair or replacement of that product at the option of Hydra-Flex, Inc., which according to our investigation was deemed defective at time of shipment.
- Page 8 8401 Eagle Creek Parkway, Savage MN 55378 952.808.3640 | www.hydraflexinc.com...
