- Page 1 TO LEAD A NEW COOL Asteroid Series FED150W TRIGGER VOICE SONG FED150W Electronic Drum Set To connect directly with our Support team 1-877-748-4799 support@fesleymusic.com www.fesleymusic.com...
- Page 2 Thank you for choosing our this type electronic drum, this type electronic drum has exquisite process and advanced technology, this is the best companion for start your music journey ◆Before using this musical instrument, please must read this manual in details. Asteroid Series FED150W TRIGGER VOICE SONG ●...
-
Page 3: Table Of Contents
C A T A LOG E Function introduction ---------------------------------------------------------------- Catalogue ----------------------------------------------------------------------------- Installation guide --------------------------------------------------------------------- Check the attached items ---------------------------------------------------------------------- Pipe parts --------------------------------------------------------------------------------------- Stand installation ------------------------------------------------------------------------------- Drum pan installation --------------------------------------------------------------------------- Install cymbals, host box, place pedals -------------------------------------------------------- Plug in the striking part connection cable ----------------------------------------------------- Host box socket diagram------------------------------------------------------------- Power cord connection ------------------------------------------------------------------------- USB MIDI socket --------------------------------------------------------------------------------... -
Page 4: Installation Guide
IN STA LLA TI ON GU I DE Check the attached items After unpack the packages, please check whether it contains all the items immediately. If there are any omissions, please contact your dealers. Asteroid Series FED150W TRIGGER VOICE SONG Control box... -
Page 5: Pipe Parts
IN STA LLA TI ON GU I DE Pipe parts The pipe parts are located in a small individual package inside the box. Bracket installation Insert the bracket and drum tray into Please insert the pipe into the plastic the corresponding positi ons, and then part of the same number and secure it. - Page 6 IN STA LLA T ION GU I DE Drum tray insert pipe Please operating carefully when installing, be careful that don't clip fingers Insert 3 pieces Tom-tom and 1 piece snare into the pipes according to the diagram, and tightly lock the plastic tighten screws.
- Page 7 IN STA LLA T ION GU I DE Install Hi-hat, Control box and place pedal Please operating carefully when installing, be careful that don't clip fingers...
- Page 8 English label at the hea d of the connection line. crash ride control box tom1 tom2 Asteroid Series hi-hat FED150W TRIGGER VOICE SONG tom3 snare hi-hat control kick drum pedal...
-
Page 9: 3 Usb Mi Di So Cke T
SO UN D M ODULE DI A GR A M Sound Module Diagram AUX IIN PHONE UOIPUT POWER CRASH2 SONG MANU Au d io f r equ e n cy in pu t s ock et Audio frequency input socket able to connect the extemal audio source to drum host box to play (example MP3, mobile phone and other linearaudio frequency signal input). -
Page 10: Operation Guide
Sensitivity display "Sxx", range are 1~15 digit wheel ｝ Series disturb control display "Cxx", range are 0~9 Asteroid Series FED150W P lu s -r e du ce k e y TRIGGER VOICE SONG User self select the drum group and return to KIT page, at the same time, press plus-reduce key 3s to recover to leave factory setting. -
Page 11: Appendix
A PPEN DI X Timbre KICK RIDEBELL3 E_CYMBAL1 E_CYMBAL2 E_CYMBAL3 E_CYMBAL4 E_CYMBAL5 E_CYMBAL6 PERCUSSION Drum combination timbre 01 Funk 04 Pop Rock 07 Standard 10 SpeedMetal 13 Modern 02 Original 05 Rock 08 Dancehall 11 Metal 14 Jazz 03 Metal 06 Songo 09 Seesion 12 ClassicDry... - Page 12 AUX IIN PHONE UOIPUT...
-
Page 13: Safety Precautions
SAFETY PRECAUTIONS... - Page 14 SAFETY PRECAUTIONS...
- Page 15 To connect directly with our Support team 1-877-748-4799 support@fesleymusic.com www.fesleymusic.com...
