- Page 1 TO LEAD A NEW COOL FED-1000 INSTRUCTION MANUAL Electric Drum To connect directly with our support team, please email support@fesleymusic.com...
-
Page 2: Function Introduction
FUNCTION INTRODUCTION Thank you for choosing the Fesley electronic drum. The elegant and delicate Fesley electronic drum is the perfect combination of modern and new electronic technology. It is strongly recommended that you read this instruction before using it. ◆ Please store this instruction in a safe place for future reference. -
Page 3: Table Of Contents
CONTENTS FUNCTION INTRODUCTION ------------------------------------------------------ CONTENTS --------------------------------------------------------------------------- INSTALLATION GUIDE -------------------------------------------------------------- Check the attached items -------------------------------------------------------------------- Install the kick drum---------------------------------------------------------------------------- Install the hammer ----------------------------------------------------------------------------- Fix kick drum and kick drum pedal ------------------------------------------------------------ Install the module bracket---------------------------------------------------------------------- ASSEMBLY DRAWING------------------------------------------------------------------------- Pipe fitting -------------------------------------------------------------------------------------- Drum pan intubation --------------------------------------------------------------------------- Mounting stand--------------------------------------------------------------------------------- Install the support arm-------------------------------------------------------------------------- Install striking parts and sound module--------------------------------------------------------... -
Page 4: Installation Guide
INSTALLATION GUIDE REMARK！ ● Please follow the instructions and read the "safety precautions" in the instruction manual carefully before using. ● This product must be installed by an adult, please do not install by the minor independently, don't let the minor install it independently. Check the attached items ●... -
Page 5: Install The Kick Drum
INSTALLATION GUIDE Install the kick drum ● when installing, please tighten the screws and be careful to pinch your fingers. Use a screwdriver to lock the kit drum, fastener, and support with small screws as shown in the figure. Then insert 2 springs into 2 anti-slip screws respectively and lock them into the... -
Page 6: Assembly Drawing
ASSEMBLY DRAWING Pipe fitting The pipe fittings are located in a separate small package in the packing box. Drum pan intubation Install the drumson the middle horizontal pipe. Installation sequence: first install the drum plate, and then install the stand... -
Page 7: Mounting Stand
INSTALLATION GUIDE Mounting Stand During installation, tighten the screws and be careful to pinch your fingers. Assemble the stand in the specified direction Install the support arm ● The support arm must to be inserted in place, and the plastic head screw should be tightened to avoid falling. -
Page 8: Install Striking Parts And Sound Module
INSTALLATION GUIDE Install striking parts and sound module ● Tighten the screws after the drum is inserted to avoid loosening. ● Don't screw the cymbale tightly, leave some space for them to shake up and down. Withdraw the nuts and circle cushions of arm the three cymbals' support arm, put the three cymbals into the corresponding support arm, and screw on the nuts. -
Page 9: Hi-Hat Stand
HI-HAT STAND Hi-hat parts introduction Hi-hat arm Clutch nut Hi-hat controller Wing screw Cymbal support base felt Clutch bolt Cymbal support base Lock nut Locating clip Large felt Regulating screw Hi-Hat Pedal Small felt U-shaped support arm Detailed introduction of important parts Cymbal support base When installing the bottom step, the step clutch assembly should be removed and the step controller should be placed on the felt ring of the step support base. -
Page 10: Illustration Of Module Socket
ILLUSTRATION OF MODULE SOCKET SONG MANU In front of the module Power cord connection 1. Access the power cord as shown in the diagram, plug one end into the power port of the sound module. Plug the other end into a 100-240V household power outlet (Figure 1) 2. -
Page 11: Operation Guide
OPERATION GUIDE CRASH2 Electronic drum control box R.PLAY PLAY MENU TONE Recording system VOLUME DOWN SAVE. METRO SONG RESET Metronome and music POWER DC9V AUDIO IN AUDIO OUT Power on 1. Press the "power" switch to enter the playing state. (Figure 1) 2. -
Page 12: Drum Kit Timbre Selection
OPERATION GUIDE Drum kit timbre selection 1. Press the "voice" button, the display will display (voice), and enter the drum kit adjustment mode. (Figure 3) 2. Use the "v" key to select the following options as adjustments. (Figure 4) The display shows: ●... -
Page 13: Metronome
OPERATION GUIDE CRASH2 Electronic drum control box R.PLAY PLAY MENU TONE Recording system VOLUME DOWN Metronome and music SAVE. METRO SONG RESET POWER DC9V AUDIO IN AUDIO OUT Metronome 1. Press the "metronome" button, the display will display (Metro), and enter the metro- nome mode. -
Page 14: Playback Speed
OPERATION GUIDE Playback speed In the demonstration song or metronome playing mode, adjusting the speed can control the speed of demonstration song and metronome playing. 1. Press the "menu" button repeatedly until the display shows (tempo), and enter the sub option p layback speed mode. -
Page 15: Appendix
APPENDIX Drum timbre KICK TOM 1 CRASH 1 CRASH 2 RIM HI-HAT OPEN 01 Acoustic Kick 01 Acoustic Tom1 01 Acoustic Crash1 01 Acoustic Crash2Rim 01 Acoustic Hi-hat Open 02 Military Kick 02 Military Tom1 02 Military Crash1 02 Military Crash2 Rim 02 Military Hi-hat Open 03 Original Kick 03 Original Tom1... -
Page 16: Product Maintenance
PRODUCT MAINTE NA NCE Careful maintenance and protection of this product plays an important role in prolonging the service life of the product and reducing the failure. AVOID HEATING, DAMPNE SS OR DIRE CT SUNL IGHT Do not over expose the product to direct sunlight, or place it near air conditioning or extremely hot place. -
Page 17: Safety Precautions
SAFETY PRECA UTIONS POWER SUPPLY This product can be powered by standard indoor wall sockets. Please only use the power cord specified in this product. When not in use, please turn off the power supply. When not in use for a long time, pull out the power cord and keep it properly. - Page 18 SA FETY PRECAUTIONS WARNING BE CAREFUL Smoke, odor, overheating The improper use of power cord may cause When the product smokes, smells or fire and electric shock. The following overheats, there is a danger of fire and precautions must be observed: electric shock when it is used continually.
- Page 19 SAFE TY PRECAUTIONS Falling or colliding Location selection If the product falls or is damaged by strong It should be avoided to place the product impact, it will be in danger of causing fire in the following places, otherwise there is and electric shock.
-
Page 20: Warranty Card
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items returned are not considered undamaged until they are received by Fesley and verified as such. All damages to items are the customer’s responsibility until the item has been received by and acknowledged by Fesley as undamaged.
