Summary of Contents for EvaKool DOWN UNDER DZ
-
Page 3: Table Of Contents
DOWN UNDER SERIES II Please read operating manual carefully before using your unit. Please keep manual in a safe place. If lost you can find a digital copy at Evakool.com.au or contact Evakool on 1300 385 665 (1300 EVKOOL). Contents Safety Instructions . -
Page 4: Safety Instructions
DOWN UNDER SERIES II 1 Safety Instructions • Warning: Do not touch exposed cables. • Warning: Do not use fridge if you suspect any connections could be wet. • When using the fridge in a vehicle, please ensure the circuit being used is fused at the battery or power source at the recommended size. -
Page 5: Operation
DOWN UNDER SERIES II 3. Operation • Power: The refrigerator can be powered by a multi-voltage system utilising either 12/24 Volts or with the included 240V adaptor. The electronic module controls the compressor and has the added function of a three stage battery protection. When the input voltage drops below the minimum, the compressor will cut out;... -
Page 6: Led Control Panel
DOWN UNDER SERIES II 4. LED Control Panel LED Control Panel On/Off Increase Cooling Light Button Button Large Bin Small Bin Settings LED Decrease Display Button Button Display Battery Protection Max & Eco Temperature Mode Bluetooth Celsius Mode Battery Charge Voltage Indicator Large Bin... - Page 7 DOWN UNDER SERIES II AMB/Ambient Temperature: This indicates the ambient temperature inside the motor compartment of the fridge. Bluetooth: The bluetooth symbol will turn on and make an audible beep when you have successfully connected to the app. This symbol will not be illuminated unless you have successfully connected.
- Page 8 DOWN UNDER SERIES II Did you know? Just like your fridge at home, all EvaKool fridge freezers will cycle on and off. This means you will hear the fridge turn on (cycle on) and commence cooling, then once it gets down to the set temperature, it will cycle off again. Subsequently, the temperature displayed on the fridge will fluctuate by a couple of degrees from the set temperature.
-
Page 9: Refrigerator Settings Recommendations
DOWN UNDER SERIES II 5. Refrigerator Setting Recommendations To ensure maximum performance from your Down Under Series II Fridge/Freezer please follow these recommendations. Temperature Settings This fridge can be run as a fridge/fridge, fridge/freezer or freezer/freezer, meaning either compartment can be run as a fridge or freezer. See recommendations below: Fridge: 2°C Freezer: -16°C Down Under II 65L - Single or Dual Zone Settings... - Page 10 When the power to the refrigerator is supplied by the starter battery of a car, select battery mode “H”. In every other instance, EvaKool recommends using the “L” / low setting. This is safe for your auxiliary battery and will maximise how long your fridge can run off your battery on a single charge.
-
Page 11: Lid Configuration
DOWN UNDER SERIES II 6. Lid Configuration This series features a bi-directional and completely removable lid for ease of access. Please follow these steps to change the lid configuration. 1. To open left or right, press the latch inwards to release the lid. 2. -
Page 12: Error Codes
(page 5). • Try on a different power source. Fan Issue • Fan is drawing too many Amps (Over 1 Amp). - Contact EvaKool Compressor Start Issues • Unplug for 10 minutes. • Try on a different power source. -
Page 13: Troubleshooting
DOWN UNDER SERIES II 8. Troubleshooting The appliance is not turning on • Check the power supply. • Check whether the plug and the socket have a good connection. • If you have purchased an additional 12V adaptor with a cigarette end, check whether the fuse requires replacing. - Page 14 • Press the transparent part of the lamp back into the housing. • Connect the power supply to the fridge. If none of the above solves your issue please contact Evakool on 1300 385 665 or warranty@evakool.com.au for details of your closest Evakool service centre.
-
Page 15: Preventative Maintenance & Care
Refrigerator Maintenance • As your EvaKool fridge is a portable appliance it is subjected to a variety of different operating conditions. Every 12 months of use, a general inspection and maintenance should be carried out. We recommend the inspection to be carried out by an approved EvaKool agent. -
Page 16: App Instructions
DOWN UNDER SERIES II 10. App Instructions The following instructions will assist you with downloading and using the EvaKool Down Under Series II App. This app is suitable for Down Under Series II 95L, 80L & 65L only. Please note that the app is a bonus feature and is not needed for the fridge to function. - Page 17 DOWN UNDER SERIES II Step 3: Once the app has found the fridge, click ‘Connect’ to connect to the fridge. Once you have successfully connected, you will hear an audible beep from the fridge, the bluetooth light on the fridge will turn on, and the app will say ‘Pairing Successful’ . When you are ready to proceed click ‘Okay’...
- Page 18 DOWN UNDER SERIES II Step 5: To edit the fridge settings press ‘Edit Settings’ . There are three fridge settings that you can changed; On/Off, Temperature & Battery Protection Mode. Once you have chosen the desired settings press ‘Save Settings’ . Step 6: If you experience a fault code, simply press the red button next to ‘Fault Codes’...
- Page 19 DOWN UNDER SERIES II Step 7: If you are using more than one Down Under Series II fridge and you are currently in the settings for Fridge 1 but want to change the settings of Fridge 2, simply exit and restart the app.
-
Page 20: Product Data
DOWN UNDER SERIES II 11. Product Data SPECIFICATIONS DU265-DZ DU280-DZ DU295-DZ Model No. Basic Data Ambient Temperature Rating 43°C Temperature Range +10°C to -18°C Gross Capacity Power Supply DC 12/24V Insulation Thickness 50mm Refrigerating System SECOP PCB 2.5 Compressor R134a Refrigerant Type Refrigerant Charge Packing Information... -
Page 21: Down Under Ii Accessories
80L & 95L Range Water Bottle, Tumbler, Small Heavy Duty Fridge Slide Can Cooler to suit 65L EvaPower Heavy Duty EvaPower Watt Meter Shop via our website Tie Down Straps by scanning the QR code or by visiting www.evakool.com.au... -
Page 22: Product Drawings
DOWN UNDER SERIES II 13. Product Drawings DU265 DU280... - Page 23 DOWN UNDER SERIES II DU295...
-
Page 24: Warranty Statement
• Service agents may charge a fee for viewing or testing the unit. This is not covered by EvaKool or this warranty and is payable at the service point unless authorised by EvaKool. - Page 25 For your nearest stockist contact Evakool T: 1300 385 665 (1300 EVKOOL) E: sales@evakool.com evakool.com.au For Service and Warranty support contact Evakool T: 1300 385 665 (EVKOOL) E: warranty@evakool.com...
