B A S I C O P E R A T I O N
TOP/BOTTOM
TOP + BOTTOM
Short-press to increase or decrease
Press and hold the Up/Down
voltage in 0.1V.
buttons together for 2 seconds to
switch the timing/charging mode.
LEFT
RIGHT
Press and hold for 2s to enter sleep
Press and hold for 2s to switch the
display mode. Short-press to get
mode. Short-press to get 1/2/3
worked voltage memory.
1/2/3 worked voltage memory.
CENTER
LEFT + RIGHT
Short-press the middle button to
Press and hold for 2s to access the
start/pause timer. Press and hold for
SETTINGS menu.
2s to reset. Short-press to exit in
menu mode.
MACHINE 1
MACHINE 2
Short-press to choose Machine 1
Short-press to choose Machine 2
output. Press and hold for 2s until a
PEDAL
output. Press and hold for 2s until a
golden lightning bolt appears to turn
golden lightning bolt appears to turn
on/off the jump start function.
Short-press to go into pedal-free mode.
on/off the jump start function.
Press and hold for 2s until "Toggle" appears
or disappears to switch momentary or
continuous mode.
TOGGLE
Continuous mode icon
Pedal on working icon
Pedal-free mode icon
Pedal without working icon
C O N N E C T I O N S & M O U N T I N G
MACHINE 1
PEDAL
POWER CABLE
MACHINE 2
MAGNETIC MOUNT
Your VEGA requires the use of the included magnetic mount for best defense against cross
contamination. The preferred configuration is on the side of your cabinet or toolbox to free up your
sterile work surface and allow for free motion of cords. The magnetic mounting can be adjusted 360°.
