- Page 1 SEC385M Serials Inclination Compensation 3D Electronic Compass Technical Manual...
- Page 2 40°. It has the advantages of small size and low power consumption, and is suitable for sensitive measurement systems with small size and high precision. The SEC385M integrates a three- axis magnetic sensor that compensates for the tilt angle with a three-axis accelerometer when the heading is solved in real time by the central processor, providing accurate heading data in very harsh environments.
-
Page 3: Electrical Specifications
SEC385M Inclination compensation 3D electronic compass MODBUS Specifications Electrical Specifications Power supply 9-36V DC Operating current 30mA（Max40mA） Operating temperature -40~85℃ Store temperature -55~100℃ Performance Specifications 0.5°（Pitch<40°）0.7°（Pitch<60°）1°（Pitch<80°） Heading accuracy Compass heading parameter 0.01° Resolution 0.1° Repeatability Pitch accuracy 0.1° Compass tilt 0.1°... -
Page 4: Mechanical Characteristic
SEC385M Inclination compensation 3D electronic compass MODBUS Resolution: The measured minimum change value that the sensor can detect and resolve within the measurement range. Accuracy: The error between the actual angle and the Root mean square(RMS) of the measured angle of the sensor (≥16 times). - Page 5 SEC385M can effectively eliminate the interference of the magnetic field. As long as the position of the compass and the surrounding magnetic field environment have not changed, it is no longer necessary to compensate the sensor.
-
Page 6: Signal Acquisition
SEC385M Inclination compensation 3D electronic compass MODBUS 6.The product is placed in a vertical state, the smooth side of the casing is facing downward (the pitch and the roll are both within ±5°), rotate one revolution at a constant speed approximately and use for more than 10 seconds. -
Page 7: Data Frame Format
SEC385M Inclination compensation 3D electronic compass MODBUS Communacation Protocol 1 Data frame format： （8data bits, 1 stop bit, no parity check , default baud rate 9600） Number of The first address of Address Code Function Code CRC check read registers the read register （1byte）... - Page 8 SEC385M Inclination compensation 3D electronic compass MODBUS 2.3 Read the HEADING angle Command： 01 03 00 03 00 01 74 0A Number of The first address of Address Code Function Code CRC check read registers the read register （1byte） （1byte）...
- Page 9 SEC385M Inclination compensation 3D electronic compass MODBUS 2.6 Quer y the relative /Absolute zero point Command： 01 03 00 05 00 01 94 0B Number of The first address of Address Code Function Code CRC check read registers the read register （1byte）...
- Page 10 SEC385M Inclination compensation 3D electronic compass MODBUS 2.9 Quer y address 2.9 Quer y address Command： 77 04 00 2F 33 Command： 77 04 00 2F 33 Function Function Function Function MODBUS MODBUS Product custom Product custom Checksum Checksum Identifier...
-
Page 11: Ordering Information
SEC385M Inclination compensation 3D electronic compass MODBUS Ordering Information Product No. Encapsulation Protocol SEC385M-232-Modbus RS 232 IP67 SEC385M-485-Modbus RS 485 IP67 SEC385M-TTL-Modbus IP67 Implementation Standards ● Enterprise Quality System Standard: ISO9001:2008 Standard (Certificate No.:23919Q1045IROS) ● ● CE certification (certificate number: M.2019.103.UY1151) ●... - Page 12 SEC385M Inclination compensation 3D electronic compass MODBUS Wuxi Bewis Sensing Technology LLC Address: Building 30, No. 58 Xiuxi Road, Binhu District, Wuxi City Tel: +86 18921292620 Email: sales@bwsensing.com Website: www.bwsensing.com...
