- Page 1 DMC5000-12 Series 3D High Precision Electronic Compass Technical Manual V4.0...
- Page 2 DMC5000-12 3D High Precision Electronic Compass 产 品 介 绍 Introduction The DMC5000 high-precision electronic compass is composed of an industrial-grade single-chip microcomputer with high reliability and strong anti-interference ability, and a high-precision magnetic sensor and drive chip. At the same time, it integrates the hard magnetic and soft magnetic calibration algorithms of BWSENSING patented technology, and uses a three-axis accelerometer to compensate for the tilt angle, so that accurate heading data can be provided in extremely harsh environments.
-
Page 3: Specifications
DMC5000-12 3D High Precision Electronic Compass Specifications Electrical Index Power supply 5V DC Operating current 34mA（40mA Max） Operating temperature -40℃~70℃ Power 150mW (200mW Max) Performance index Heading accuracy 0.3RMS（Horizontal） Compass heading ＜0.5 RMS（Pitch<20°） parameters Measuring range 0~360° Repeatability 0.05°（RMS） Pitch accuracy 0.2°... - Page 4 DMC5000-12 3D High Precision Electronic Compass Resolution: The smallest change value of the measured value that the sensor can detect and distinguish within the measurement range. Accuracy: The root mean square error of the actual angle and the sensor measuring angle for multiple ( ≥16 times) measurements.
-
Page 5: Installation Direction
DMC5000-12 3D High Precision Electronic Compass Installation direction The main sensitive components of DMC5000 sensor are magnetometer and accelerometer. The compass uses a magnetometer to sense the earth's magnetic field to calculate the sensor's pointing, uses an accelerometer tomeasure the angle between the compass and gravity, and provides inclination compensation when the compasscalculates the azimuth. - Page 6 DMC5000-12 3D High Precision Electronic Compass 4. Rotate the product 2-3 times in the horizontal plane (both pitch and roll angles are within ± 5°) around the z-axis (z-axis is the vertical direction). The rotation process should be as slow and nearly uniform as possible.
- Page 7 DMC5000-12 3D High Precision Electronic Compass rotation is about 10 to 15 seconds; 4. Starting from the 0 degree defined by yourself, send a collection command every 30 degrees, and wait for the return command to continue to rotate until the product rotates around the Z axis for a total of 13 points.
- Page 8 DMC5000-12 3D High Precision Electronic Compass Note: 1. When calibrating, please ensure that the electronic compass is tightly fixed on the device, if possible, please fix it with screws. 2. When calibrating, the electronic compass needs to be calibrated together with the device to obtain an accurate heading value instead of just calibrating the electronic compass 3.
-
Page 9: Electrical Interface
DMC5000-12 3D High Precision Electronic Compass Electrical Interface Electrical interfaces BLACK YELLOW GREEN Cable color & Function (A、D+) (B、D-) Bewis Sensing Technology LLC www.bwsensing.com.cn Tel： +86 18921292620... -
Page 10: Data Frame Format
DMC5000-12 3D High Precision Electronic Compass Protocol Data Frame Format： ： （8 data bits， 1 stop bit， No parity check， default baud rate 9600） Identifier Frame Address Command Data Checksum (1 byte) Length Code （1 byte) (N byte) (1 byte) (1 byte) (1 byte) 0×77... - Page 11 DMC5000-12 3D High Precision Electronic Compass Read angle of Y axis Command：77 04 00 02 06 Identifier Frame Address Command Data Checksum (1 byte) Length Code （1 byte) (0 byte) (1 byte) (1 byte) (1 byte) 0×77 0×04 0x02 Command response： Identifier Frame Address...
- Page 12 DMC5000-12 3D High Precision Electronic Compass Note: The data field contains 9 bytes which are pitch (Pitch), roll (Roll) and azimuth (Heading) angle values, which are compressed BCD codes,each of which is a group of three bytes, for example, the return command is 77 0D 00 84 10 26 80 00 33 65 03 13 71 66, where Pitch is 10 26 80, Roll is 00 33 65, and Heading is 03 13 71.
- Page 13 DMC5000-12 3D High Precision Electronic Compass Set magnetic declination Command： 77 06 00 06 02 08 16 Identifier Frame Address Command Data Checksum (1 byte) Length Code （1 byte) (2 byte) (1 byte) (1 byte) (1 byte) 0x77 0x06 0x06 SX XY Command response：...
- Page 14 DMC5000-12 3D High Precision Electronic Compass Set module address Command： 77 05 00 0F 01 15 Identifier Frame Address Command Data Checksum (1 byte) Length Code （1 byte) 1 byte) (1 byte) (1 byte) (1 byte) 0x77 0x05 0x0F Command response： Identifier Frame Address...
- Page 15 DMC5000-12 3D High Precision Electronic Compass Note: 5Hz Data Rate means automatically output data 5 times per second, and so on. When the product is set to automatic output mode, there will be no output within 10 seconds after the product is powered on.
- Page 16 DMC5000-12 3D High Precision Electronic Compass Executive standard Enterprise Quality System Standard: ISO9001:2008 Standard (Certificate No.10114Q16846ROS) CE certification (certificate number: 3854210814) RoHS (certificate number: G190930099) Bewis Sensing Technology LLC www.bwsensing.com.cn Tel：+86 18921292620...
- Page 17 DMC5000-12 Series 3D High Precision Electronic Compass Wuxi Bewis Sensing Technology LLC Add： Building 30, NO. 58, Xiuxi Road, Binhu District, Wuxi City, Jiangsu Province, China Tel： +86 18921292620 Mail ：sales@bwsensing.com Web：www.bwsensing.com...
