- Page 1 LEC315M Angle Compensation 3D Electronic Compass with Modbus Technical Manual...
- Page 2 The LEC315M is a 3D Electronic Compass with high accuracy. It offers high accuracy heading information when tilt angle reaches 40° initially. LEC315M is a small size, low power consumption compass that is widely used in the antenna steadiness, vehicle navigation, system integration, etc.
-
Page 3: Electrical Specifications
LEC315M Angle Compensation 3D Electronic Compass with Modbus Specifications Electrical Specifications Power supply 5VDC Operating current 30mA（40 A max） Operating temperature -40~+85℃ Sore temperature -55~+100℃ Performance Specifications 2°（RMS） Heading Accuracy Compass Heading 0.1° Resolution Parameters Repeatibility 0.3° Pitch Accuracy 0.2º... -
Page 4: Mechanical Characteristics
LEC315M Angle Compensation 3D Electronic Compass with Modbus Resolution: the sensor is able to detect and distinguish the minimum the measured change within measuring range. Accuracy: error between actual angle and the root mean square of angle (≥16 times) multiply measured by the sensor. -
Page 5: Installation
Although the LEC315M can compensate for magnetic interference, users should choose a minimum magnetic interference environment to install and use it. Please make sure the LEC315M is away from the iron, nickel, magnets, engines and other magnetic substances as far as possible when place it. -
Page 6: Electrical Connections
LEC315M Angle Compensation 3D Electronic Compass with Modbus 6, place the product vertically with a smooth side of the shell down (The pitch is within 0±5 degrees and the roll is within 90±5 degrees).Rotate one round steadily over about 10... - Page 7 LEC315M Angle Compensation 3D Electronic Compass with Modbus Communacation Protocol 1 Data frame format： （8data bits, 1 stop bit, no parity check , default baud rate 9600） Number of The first address of Address Code Function Code CRC check read registers the read register （1byte）...
- Page 8 LEC315M Angle Compensation 3D Electronic Compass with Modbus 2.3 Read the HEADING angle Command： 01 03 00 03 00 01 74 0A Number of The first address of Address Code Function Code CRC check read registers the read register （1byte）...
- Page 9 LEC315M Angle Compensation 3D Electronic Compass with Modbus 2.6 Quer y the relative /Absolute zero point Command： 01 03 00 05 00 01 94 0B Number of The first address of Address Code Function Code CRC check read registers the read register （1byte）...
- Page 10 LEC315M Angle Compensation 3D Electronic Compass with Modbus 2.9 Quer y address 2.9 Quer y address Command： 77 04 00 2F 33 Command： 77 04 00 2F 33 Function Function Function Function MODBUS MODBUS Product custom Product custom Checksum Checksum...
- Page 11 LEC315M Angle Compensation 3D Electronic Compass with Modbus Test Standard Enterprise quality system standards: ISO9001: 20 standard (certificate number: CE certification (certificate number: RoHS (certificate number: Tel：+86 189 2129 2620 www.bwsensing.com Bewis Sensing Technology LLC...
- Page 12 LEC315M Angle Compensation 3D Electronic Compass with Modbus Wuxi Bewis Sensing Technology LLC Address: Building 30, No. 58 Xiuxi Road, Binhu District, Wuxi City, Jiangsu Province, China Tel/Whatsapp: +86 189 2129 2620 Email: sales@bwsensing.com Website: www.bwsensing.com...
