Audison LPX 4.5 Service Manual
  1. Manuals
  2. Brands
  3. Audison Manuals
  4. Amplifier
  5. LPX 4.5
  6. Service manual
Audison LPX 4.5 Service Manual

Audison LPX 4.5 Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
- SERVICE MANUAL -
Issued in July 2007
62018 Potenza Picena (MC) Italy • Tel. 0733.870870 • Fax. 0733.870880 • http://www.audison.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the LPX 4.5 and is the answer not in the manual?

Questions and answers

Related Manuals for Audison LPX 4.5

Summary of Contents for Audison LPX 4.5

  • Page 1 All manuals and user guides at all-guides.com - SERVICE MANUAL - Issued in July 2007 62018 Potenza Picena (MC) Italy • Tel. 0733.870870 • Fax. 0733.870880 • http://www.audison.com...
  • Page 2 All manuals and user guides at all-guides.com CONTENTS PART 1: ELECTRONIC PART and UPGRADING Section A: Identification system 1. Mainboard identification page from 1 to 1 2. Modules Identification and replacement page from 1 to 1 Section B: LRx4.5 Mainboard revisions LRx4.5-MB First Version Rk = 12 Ohm 1.
  • Page 3 All manuals and user guides at all-guides.com CONTENTS Section F: Modules Block Diagrams 1. ABLD.1/.1A/.1B - Block diagram sheet from 1 to 1 2. CPU.1/.1A - Block diagram sheet from 1 to 1 3. PSC.1 - Block diagram sheet from 1 to 1 Section G: LRx series components pin-out 1.
  • Page 4 All manuals and user guides at all-guides.com PART 1 ELECTRONIC PART...
  • Page 5 A different number indicates a non complatible VERSION. Please don’t use modules with a different VERSION NUMBER for replacement, unless it is indicates. Contact Audison for any necessary clarifications. REVISION LETTER A different letter indicates the module improved revision. Compatibility is not compromised. It is always suitable to replace a module with another one having the same letter or the successive one.
  • Page 6 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 1: ELECTRONIC PART Section B: Mainboard revisions First Version: Rk = 12 Ohm 1. Electrical diagrams - Rk = 12 Ohm sheet from 1 to 2 2.
  • Page 7 All manuals and user guides at all-guides.com...
  • Page 8 All manuals and user guides at all-guides.com...
  • Page 9 All manuals and user guides at all-guides.com...
  • Page 10 All manuals and user guides at all-guides.com...
  • Page 11 All manuals and user guides at all-guides.com LRx 4.5 PCB PARTS LIST Rk = 12 Ohm REF. NO PART NO DESCRIPTION Q.TY INSULATOR FOR INDUCTOR L40 ..... . . 10035010 ..DIAM. 35mm ADHESIVE MYLAR ......1 FOR TOROIDAL TRANSFORMER .
  • Page 12 All manuals and user guides at all-guides.com LRx 4.5 EXPLODED PCB PARTS LIST Rk = 12 Ohm REF. NO PART NO DESCRIPTION Q.TY 10071100 9.5x11mm ADHESIVE FELT 10090080 40x40x20mm FAN WITH CONNECTOR 10096010 LRx - 40mm FAN SUPPORT 10096020 LRx FAN SUPPORT - ANGLE CLIP 12420140 De 6.4 di 3.2 h.
  • Page 13 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 1: ELECTRONIC PART Section C: Power Side 2 Module Revision First Version: Rev. = .1 1. Electrical diagrams - Rev. = .1 sheet from 1 to 2 2.
  • Page 14 S. Regina Km. 3,500 - Marignano - 62018 Potenza Picena (MC) is not copied, printed or given to thirds without previous Tel. 0733.870870 Fax 0733.870880 written consent by Sheet description: Product: Type: Rev/Rk: audison LRx2-NEW POWER SIDE POSITIVE PCB code: Date: Sheet: BAF152B 16726910 B...
  • Page 15 S. Regina Km. 3,500 - Marignano - 62018 Potenza Picena (MC) is not copied, printed or given to thirds without previous Tel. 0733.870870 Fax 0733.870880 written consent by Sheet description: Product: Type: Rev/Rk: audison LRx2-NEW POWER SIDE NEGATIVE PCB code: Date: Sheet: BAF152B 16726910 B...
  • Page 16 S. Regina Km. 3,500 - Marignano - 62018 Potenza Picena (MC) is not copied, printed or given to thirds without previous Tel. 0733.870870 Fax 0733.870880 written consent by Sheet description: Product: Type: Rev/Rk: audison LRx2 PS2-P/N PCB code: Date: Sheet: COMPONENTS LAY-OUT BAC161C...
  • Page 17 All manuals and user guides at all-guides.com PS2-P/N.1 MODULE PCB PARTS LIST Revision .1 REF. NO PART NO DESCRIPTION Q.TY MECHANICAL PARTS DS101........14244000..TEMPERATURE SENSOR SUPPORT ....1 CONNECTION WIRE AND CONNECTORS J1 J2 J3 .
  • Page 18 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - Upgrading Version PART 1: ELECTRONIC PART Section C : Power Side 2 Module Revision Upgrading Version: Rev. = .1A 1. Electrical diagrams - Rev. = .1A sheet from 1 to 2 2.
  • Page 19 All manuals and user guides at all-guides.com...
  • Page 20 All manuals and user guides at all-guides.com...
  • Page 21 All manuals and user guides at all-guides.com...
  • Page 22 All manuals and user guides at all-guides.com PS2-P/N.1A MODULE PCB PARTS LIST Revision .1A REF. NO PART NO DESCRIPTION Q.TY MECHANICAL PARTS DS101........14244000... TEMPERATURE SENSOR SUPPORT ....1 CONNECTION WIRE AND CONNECTORS J1 J2 J3 .
  • Page 23 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 1: ELECTRONIC PART Section D : Class AB Final Modules First Version: Rev. = .1 1. AB7-2.1 Electrical diagrams - Rev. = .1 sheet from 1 to 1 2.
  • Page 24 S. Regina Km. 3,500 - Marignano - 62018 Potenza Picena (MC) is not copied, printed or given to thirds without previous Tel. 0733.870870 Fax 0733.870880 written consent by Sheet description: Product: Type: Rev/Rk: audison AB7-2 LRx.1 Modul POWER AMPLIFIER 2xTO247 PCB code: Date: Sheet: BAF149B...
  • Page 25 S. Regina Km. 3,500 - Marignano - 62018 Potenza Picena (MC) is not copied, printed or given to thirds without previous Tel. 0733.870870 Fax 0733.870880 written consent by Sheet description: Product: Type: Rev/Rk: audison AB7-2 LRx2 COMPONENTS LAY-OUT PCB code: Date: Sheet: BAC158C...
  • Page 26 All manuals and user guides at all-guides.com AB7- 2.1 MODULE PCB PARTS LIST Revision .1 REF. NO PART NO DESCRIPTION Q.TY CONNECTION WIRE AND CONNECTORS J1 ........15232730... 2mm RIGHT ANGLE PIN HEADER 10+10 CONTACT ..1 RESISTORS R1 R6 .
  • Page 27 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 1: ELECTRONIC PART Section E : Controls Modules First Version: Rev. = .1 1. LRx 4.5 - C Electrical diagrams - Rev. = .1 sheet from 1 to 8 2.
  • Page 28 All manuals and user guides at all-guides.com...
  • Page 29 All manuals and user guides at all-guides.com...
  • Page 30 All manuals and user guides at all-guides.com...
  • Page 31 All manuals and user guides at all-guides.com...
  • Page 32 All manuals and user guides at all-guides.com...
  • Page 33 All manuals and user guides at all-guides.com...
  • Page 34 All manuals and user guides at all-guides.com...
  • Page 35 All manuals and user guides at all-guides.com...
  • Page 36 All manuals and user guides at all-guides.com...
  • Page 37 All manuals and user guides at all-guides.com LRx 4.5 - C.1 PCB PARTS LIST Revision .1 REF. NO PART NO DESCRIPTION Q.TY MECHANICAL PARTS ......... 10023520..LRx SPACERS for 4 LED ......1 CONNECTION WIRE AND CONNECTORS J1 J2 .
  • Page 38 All manuals and user guides at all-guides.com LRx 4.5 - C.1 PCB PARTS LIST Revision .1 REF. NO PART NO DESCRIPTION Q.TY DIODES D3 ........16635401..DIFFUSED RED LED 3mm 12.6 mcd.....1 D2 .
  • Page 39 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - Upgrading Version PART 1: ELECTRONIC PART Section E : Controls Modules Upgrading Version: Rev. = .1A 1. LRx 4.5 - C Electrical diagrams - Rev. = .1A sheet from 1 to 8 2.
  • Page 40 All manuals and user guides at all-guides.com...
  • Page 41 All manuals and user guides at all-guides.com...
  • Page 42 All manuals and user guides at all-guides.com...
  • Page 43 All manuals and user guides at all-guides.com...
  • Page 44 All manuals and user guides at all-guides.com...
  • Page 45 All manuals and user guides at all-guides.com...
  • Page 46 All manuals and user guides at all-guides.com...
  • Page 47 All manuals and user guides at all-guides.com...
  • Page 48 All manuals and user guides at all-guides.com...
  • Page 49 All manuals and user guides at all-guides.com LRx 4.5 - C.1A PCB PARTS LIST Revision .1A REF. NO PART NO DESCRIPTION Q.TY MECHANICAL PARTS ......... . 10023520..LRx SPACERS for 4 LED ......1 CONNECTION WIRE AND CONNECTORS J1 J2 .
  • Page 50 All manuals and user guides at all-guides.com LRx 4.5 - C.1A PCB PARTS LIST Revision .1A REF. NO PART NO DESCRIPTION Q.TY DIODES D3 ........16635401..DIFFUSED RED LED 3mm 12.6 mcd.....1 D2 .
  • Page 51 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual PART 1: ELECTRONIC PART Section F : Modules Block Diagrams 1. ABLD Block diagrams - Rev. = .1 / .1A / .1B sheet from 1 to 1 2. CPU Block diagrams - Rev. = .1 / .1A sheet from 1 to 1 3.

  • Page 52: Block Diagram

    LIMIT MUTE LIMIT "A" class VOLTAGE Differential AMPLIFIER Amplifier G-OUT -RAMP +RAMP SENS-H OVERLOAD CASCODE_L R-SENS SENS-L G-IN audison Sheet desription: Product: Type: Rev/Rk: ABLD .1/.1A/.1B BLOCK DIAGRAM code: Date: Sheet: 36780740 / 41 / 42 28/oct/06 1 OF 1...

  • Page 53: Power Limit

    LED_OVL DC SENSE 8 [J2] VEL1 +15V 9 [J2] VEL2 IN_DC RAMP [J1] [J2] [J2] [J2] [J1] -RAMP +RAMP AGND PWRGND audison Sheet desription: Product: Type: Rev/Rk: .1/.1A BLOCK DIAGRAM code: Date: Sheet: 36780750 / 51 12/sep/06 1 OF 1...
  • Page 54 2 [J1] THERMAL FEEDBACK REMOTE 10 [J2] LIMIT_TH 11 [J1] 12 [J1] 3 [J2] 3 [J1] 5 [J1] REMOTE_OUT TEMP1 TEMP2 audison Sheet desription: Product: Type: Rev/Rk: .2/.2A BLOCK DIAGRAM code: Date: Sheet: 36780761 / 62 28/oct/06 1 OF 1...
  • Page 55 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 1: ELECTRONIC PART Section G: LRx Series components pin-out First Version: Rev. A 1. Leaded components page from 1 to 3 2. SMT components page from 4 to 7 Table of the last upgrading revisions UPGRADING REVISIONS...
  • Page 56 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: Leaded components Rev. A Case TO220 NPN bipolar transistor PIN OUT Ref. Type Product name Marking code Audio driver 2SD2400A Darlington BDW93C BDW93 PNP bipolar transistor PIN OUT Ref. Type Product name Marking code...
  • Page 57 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: Leaded components Rev. A Case TO3P NPN bipolar transistor PIN OUT Ref. Type Product name Marking code Audio power FJA4310-O J4310-O PNP bipolar transistor PIN OUT Ref. Type Product name Marking code B: Base Audio power...
  • Page 58 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: Leaded components Rev. A Case ATV- TV2 NPN bipolar transistor PIN OUT Type Product name Marking code Ref. Audio driver 2SD1857A-Q D1857A PNP bipolar transistor PIN OUT Ref. Type Product name Marking code B: Base...
  • Page 59 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: SMT components Rev. A Case SOD-80 / MiniMELF Diodes PIN OUT Ref. Type Product name Marking code General purpose LL4148 150mA 75V General Purpose BAV102 200mA 150V RLS245 FDLL 459/A A: Anode Zener BZV55C6V8...
  • Page 60 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: SMT components Rev. A Case SOT323 Switching dual diodes PIN OUT Ref. Application Product name Marking code Signal BAV70W A: Anode K: Cathode Case SMT6 NPN bipolar dual transistor (5) (6) (5) (6) Ref.
  • Page 61 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: SMT components Rev. A Case SO14 Pin configuration Ref. Type Product name Marking code OUT1 OUT4 Quad op amps LM324 -IN1 -IN4 +IN1 +IN4 +IN2 +IN3 -IN2 -IN3 OUT2 OUT3 Case SO16 TL494ID Pin configuration...
  • Page 62 All manuals and user guides at all-guides.com LRx SERIES COMPONENTS PIN-OUT: SMT components Rev. A Case D PACK NPN transistor PIN OUT Ref. Type Product name Marking code Epitaxial planar KTC2983D C2983 transistor PNP transistor PIN OUT Ref. Type Product name Marking code B: Base A1225...

  • Page 63: Mechanical Part

    All manuals and user guides at all-guides.com PART 2 MECHANICAL PART...

  • Page 64: Section A : Exploded Views And Parts List

    All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 2: MECHANICAL PART Section A : Exploded views and parts list First Version - Rev. A 1. Mechanical exploded view sheet from 1 to 1 2.
  • Page 65 All manuals and user guides at all-guides.com 1. Mechanical Exploded View...
  • Page 66 All manuals and user guides at all-guides.com 2. Package Exploded View...
  • Page 67 LRx 4.5 / LRx 4.1k OWNER’S MANUAL 10125260 LRx FIXING TEMPLATE 10125270 LRx 4.5 CONFIGURATION TEMPLATE 90200020 AW STICKER S - AUDISON Transfer Sticker 19x7 10045000 10x16 AUDISON BAG 10081221 LRx PLAST SNAP-IN CABLE FIX ACCESSORY KIT 12150520 3.9x25 SCREW (AFcp TC C ZN)
  • Page 68 All manuals and user guides at all-guides.com LRx 4.5 EXPENDABLE MATERIALS Rev. A PART NO DESCRIPTION Q.TY 07000400 THERMO COND. GREASE 50g. 07000600 1-2577 SILICONE RESIN Part 2A page 2 of 2...
  • Page 69 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - Upgrading Version PART 2: MECHANICAL PART Section A : Exploded views and parts list Upgrading Version - Rev. B 1. Mechanical exploded view sheet from 1 to 1 2.
  • Page 70 All manuals and user guides at all-guides.com 1. Mechanical Exploded View...
  • Page 71 All manuals and user guides at all-guides.com 2. Package Exploded View...
  • Page 72 LRx 4.5 / LRx 4.1k OWNER’S MANUAL 10125260 LRx FIXING TEMPLATE 10125270 LRx 4.5 CONFIGURATION TEMPLATE 90200020 AW STICKER S - AUDISON Transfer Sticker 19x7 10045000 10x16 AUDISON BAG 10081221 LRx PLAST SNAP-IN CABLE FIX ACCESSORY KIT 12150520 3.9x25 SCREW (AFcp TC C ZN)
  • Page 73 All manuals and user guides at all-guides.com LRx 4.5 EXPENDABLE MATERIALS Rev. B PART NO DESCRIPTION Q.TY 07000400 THERMO COND. GREASE 50g. 07000600 1-2577 SILICONE RESIN Part 2A page 2 of 2...

  • Page 74: Technical Notes

    All manuals and user guides at all-guides.com PART 3 TECHNICAL NOTES...
  • Page 75 All manuals and user guides at all-guides.com LRx 4.5 - Service Manual - First Version PART 3: TECHNICAL NOTES First Version: Rev. A 1. Springs Replacing 2. 40x40x20 mm Fan Replacing 3. Idling Current Adjustment Table of the last upgrading revisions UPGRADING REVISIONS PART 1 PART 2...
  • Page 76 All manuals and user guides at all-guides.com TECHNICAL NOTES Rev. A 1. Springs Replacing REMOVING 1- Insert the blade of the screwdriver in the center of the spring as shown in figure n°1. 2- Using the aluminium heatsink of the amplifier as leverage, slowly extract the spring as shown in figure n°2, being careful to not use too much force.
  • Page 77 All manuals and user guides at all-guides.com TECHNICAL NOTES Rev. A 2. 40x40x20 mm Fan Replacing In the case you need to replace the fan, please proceed as per the following steps. A. Fan rigid fixing with rivets (first batch of pro- ducts) 1- Remove the bottom of the product.
  • Page 78 All manuals and user guides at all-guides.com TECHNICAL NOTES Rev. A 3. Idling Current Adjustment 1. Before adjusting the idling current, turn the amplifier on and let it play for several minutes. When the heat sink DIGITAL DIGITAL temperature reaches a range between 30 and 45°C (86 ÷ 113°F) that is the optimal condition to perform the adjustment. MULTIMETER MULTIMETER 2.
