30 gpm max.
3000 psi max
Part Number HF 300 Series
Part Number 86000 Series
WARNING
DO NOT OPERATE BEFORE
READING MANUAL.
INSTALLATION, OPERATION AND
MAINTENANCE
Bulk Feed Manual
PRGMAN-13
Version: A
January 31, 2024
Copyright © Paragon Tank Truck Equipment LLC
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Paragon HydraFLOW HF 300 Series
- Page 1 30 gpm max. 3000 psi max Part Number HF 300 Series Part Number 86000 Series WARNING DO NOT OPERATE BEFORE READING MANUAL. INSTALLATION, OPERATION AND MAINTENANCE Bulk Feed Manual PRGMAN-13 Version: A January 31, 2024 Copyright © Paragon Tank Truck Equipment LLC...
- Page 2 DANGER SAFETY INSTRUCTIONS 1. Do not operate before reading the enclosed instruction manual. 2. Use adequate protection, warning and safety equipment necessary to protect against hazards Keep body and clothing away involved in installation and WARNING CAUTION WARNING Keep body and Hearing Do not touch clothing away...
- Page 3 TABLE OF CONTENTS PAGE SECTION SAFETY INSTRUCTIONS & WARNING TAGS SAFETY PRECAUTIONS INTRODUCTION START-UP, OPERATION & MAINTENANCE OUTLINE DRAWING ITEMIZED ASSEMBLY DRAWING PARTS LIST 8 – 9 WARRANTY SAFETY PRECAUTIONS For equipment covered specifically or indirectly in this instruction book, it is important that all personnel observe safety precautions to minimize the chances of injury.
- Page 4 INTRODUCTION CONGRATULATIONS on your purchase of a new Hydraflow. Please examine the unit for shipping damage, and if any damage is found, report it immediately to the carrier. If unit is to be installed at a later date make sure it is stored in a clean, dry location. Warning: Serious injury can result from operating or repairing the unit without reading the service manual and taking adequate safety precautions.
- Page 5 Preferred behind the cab mount (optimum suction conditions) Behind Cap Mount BEST Suction Condition: Behind cab mount Suction Case drain Low Pressure High Pressure to High Pressure Pump to Hydraflow 3/4” Note: • Review Hose Chart on page 4 to insure the correct suction hose sizing. •...
- Page 6 1. Remove red filler cap. 2. Fill Hydraflow 1/2 full with hydraulic fluid. Note: a. Paragon recommends an (ISO) 32 no-foaming hydraulic oil such as Shell Tellus T32 Hydraulic Oil. b. Use a paint filter as a strainer while filling.
- Page 7 Overall Dimensions 86000 Series 14.34" 14.34” 5.5" 5.50” 20.936" 20.94” 12.7" 16.200" 12.70” 16.20” HF 300 Series 14.34” 5.50” 19.41” 16.20” 12.70”...
- Page 8 Parts List...
- Page 9 Part Number HF 300 and 86000 Series PARTS LIST ITEM PART NUMBER DESCRIPTION 86000 HF 300 500-012 Body Mainframe HF - CD61 500-013 Body Mainframe HF - 2" NPT 500-016 Body Mainframe - 1-1/2" CD61 500-017 Body Mainframe - 2” NPT 85209-1 Hyd Control Block 85202...
- Page 10 Part Number HF 300 and 86000 Series PARTS LIST – (CONT.) ITEM PART NUMBER DESCRIPTION 86000 HF 300 85258 Retaining ring 1/2'' - Fan Motor 85201 Fan - Hydraflow Std 85230 Capscrew Skt Hd 1/4-20 x 3/4” S/S 85213 Flange Split Half 24CD61 294-010 Washer Lock GR5 1/2”...
- Page 11 Recommended Bracket for HF 300 Series PART NUMBER DESCRIPTION 508-042 Bracket Extension - HF Hydraflow...
- Page 12 Dust Cap (not shown) # 320-000 # 321-016 3/4” HP # 321-016 3/4” HP Paragon Tank Truck Equipment www.paragondirect.com Tandem Pump (optional) Note High pressure hose must have a working pressure rating equal Hydraulic Drive Systems System : 408-000 of higher than the hydraulic system relief valve.
- Page 13 WARRANTY – HYDRAFLOW Subject to the terms and conditions hereinafter set forth and set forth in General Terms of Sale, Paragon Tank Truck Equipment LLC (the seller) warrants products and parts of its manufacture, when shipped, will be of good quality and will be free from defects in material and workmanship.
