- Page 1 30 gpm max. 3000 psi max Part Number HF 300 Series Part Number 86000 Series WARNING DO NOT OPERATE BEFORE READING MANUAL. INSTALLATION, OPERATION AND MAINTENANCE Bulk Feed Manual PRGMAN-13 Version: C April, 2025 Copyright 2025 © Paragon Tank Truck Equipment LLC...
- Page 2 DANGER SAFETY INSTRUCTIONS 1. Do not operate before reading the enclosed instruction manual. 2. Use adequate protection, warning and safety equipment necessary to protect against hazards Keep body and clothing away involved in installation and WARNING CAUTION WARNING Hearing Keep body and Do not touch clothing away Protection...
- Page 3 TABLE OF CONTENTS PAGE SECTION SAFETY INSTRUCTIONS & WARNING TAGS SAFETY PRECAUTIONS INTRODUCTION START-UP, OPERATION & MAINTENANCE OUTLINE DRAWING ITEMIZED ASSEMBLY DRAWING PARTS LIST 8 – 9 WARRANTY SAFETY PRECAUTIONS For equipment covered specifically or indirectly in this instruction book, it is important that all personnel observe safety precautions to minimize the chances of injury.
-
Page 4: Installation
INTRODUCTION CONGRATULATIONS on your purchase of a new Hydraflow. Please examine the unit for shipping damage, and if any damage is found, report it immediately to the carrier. If the unit is to be installed at a later date make sure it is stored in a clean, dry location. Warning: Serious injury can result from operating or repairing the unit without reading the service manual and taking adequate safety precautions. - Page 5 Preferred behind the cab mount (optimum suction conditions) Behind Cap Mount BEST Suction Condition: Suction Case drain Low Pressure High Pressure to High Pressure Pump to Hydraflow 3/4” Note: Review Hose Chart on page 4 to ensure the correct suction hose sizing. •...
-
Page 6: Initial Start-Up
1. Remove red filler cap. 2. Fill Hydraflow 1/2 full with hydraulic fluid. Note: a. Paragon recommends an (ISO) 32 no-foaming hydraulic oil such as Shell Tellus T32 Hydraulic Oil. b. Use a paint filter as a strainer while filling. -
Page 7: Overall Dimensions
Overall Dimensions 86000 Series 14.34" 14.34” 5.5" 5.50” 20.936" 20.94” 12.7" 16.200" 12.70” 16.20” HF 300 Series 14.34” 5.50” 19.41” 16.20” 12.70”... -
Page 8: Parts List
Parts List... - Page 9 Part Number HF 300 and 86000 Series PARTS LIST ITEM PART NUMBER DESCRIPTION 86000 HF 300 500-012 Body Mainframe HF - CD61 500-013 Body Mainframe HF - 2" NPT 500-016 Body Mainframe - 1-1/2" CD61 500-017 Body Mainframe - 2” NPT 85209-1 Hyd Control Block 85202...
- Page 10 Part Number HF 300 and 86000 Series PARTS LIST – (CONT.) ITEM PART NUMBER DESCRIPTION 86000 HF 300 85258 Retaining ring 1/2'' - Fan Motor 85201 Fan - Hydraflow Std 85230 Capscrew Skt Hd 1/4-20 x 3/4” S/S 85213 Flange Split Half 24CD61 294-010 Washer Lock GR5 1/2”...
- Page 11 Recommended Bracket for HF 300 Series PART NUMBER DESCRIPTION 508-042 Bracket Extension - HF Hydraflow...
- Page 12 Dust Cap (not shown) # 320-000 # 321-016 3/4” HP # 321-016 3/4” HP Paragon Tank Truck Equipment www.paragondirect.com Tandem Pump (optional) Note High pressure hose must have a working pressure rating equal Hydraulic Drive Systems System : 408-000 of higher than the hydraulic system relief valve.
-
Page 13: Warranty Statement
Date Issued: 05/01/2025 GENERAL PROVISIONS AND LIMITATIONS Paragon Tank Truck Equipment LLC (the “Company”) warrants to each original retail purchaser (“Purchaser”) of its products from the Company or its authorized distributor that such products are, at the time of delivery to the Purchaser, made with good material and workmanship. - Page 14 1. Freight will be reimbursed for both the replacement item and the returned suspect part (if Requested by Paragon). This allowance will cover only transportation via Paragon selected most economical method within the continental United States, Canada and Mexico. Premium transportation and/or handling charges will not be covered or pro-rated.
-
Page 15: Additional Notes
Additional Notes... - Page 16 Paragon Tank Truck Equipment www.paragondirect.com ©2025 Paragon Tank Truck Equipment, LLC Printed in U.S.A. PRGMAN-13_C 1st Ed. 04/25 Supersedes PRGMAN-13_B 1st Ed. 01/25 Please recycle after use.
