- Page 1 25 gpm max. 3000 psi max WARNING DO NOT OPERATE MACHINERY BEFORE READING MANUAL FULLY INSTALLATION, OPERATION, AND MAINTENANCE MANUAL PRGMAN-09 Version C April, 2025 Copyright 2025 © Paragon Tank Truck Equipment LLC...
-
Page 2: Safety Instructions & Warning Tags
Warnings NOTICE WARNING: Warning Instructions listed on this page must be reviewed by ALL operators. Safety instruction tags were attached to your unit prior to shipment. DO NOT remove, paint over or obscure in any manner. Failure to heed these warnings could result in serious bodily injury to the personnel operating and maintaining this equipment. -
Page 3: Table Of Contents
Table of Contents Section Page Safety Instructions & Warning Tags Introduction Safety Precautions HydraFLOW Installation & Mounting Start-Up, Operation, & Maintenance Model Number Construction Outline Drawing Parts List & Filter Breakdown 9-14 Warranty Introduction CONGRATULATIONS on your purchase of a new HydraFlow. Please examine the unit for shipping damage, and if any damage is found, report it immediately to the carrier. -
Page 4: Safety Precautions
Safety Precautions For equipment covered specifically or indirectly in this instruction book, it is important that all personnel observe safety precautions to minimize the chances of injury. Among many considerations, the following should be particularly noted: • Rotating shafts can be dangerous. You can snag clothes, skin, hair, hands, etc. This can cause severe injury or death. •... -
Page 5: Hydraflow Installation & Mounting
PTO, hydraulic pump, and transmission manufacturers. C. Ensure ALL safety labels are installed per manufacturer guidelines. Note: The standard filter supplied in the HydraFLOW is a 10 micron nominal. Contact Paragon Tank Truck Equipment for other filtration media options. - Page 6 Preferred behind the cab mount (optimum suction conditions) BEST Suction Condition: Behind Cab Mount Suction (see Fig. 2) Low Pressure Return Motor to HydraFlow 1” High Pressure to Hydraulic Motor 3/4” High Pressure Pump to HydraFlow 3/4” Note: • Review Hose Chart (Fig. 2) to ensure the correct suction hose sizing. •...
-
Page 7: Operation Of System
2. Fill the HydraFLOW to the top of the lower sight glass with hydraulic lubricant. NOTE: Paragon recommends an (ISO) 32 non-foaming hydraulic oil. (Example: Mobil SHC 630 Hydraulic Oil) Use a paint filter as a strainer while filling to prevent foreign contaminants from entering the system. -
Page 8: Model Number Construction
Model Number Construction SL 300 T 9 X - HydraFlow HF Special SL Slim Line (25 GPM) (Leave blank if none) 001 - 16 Elbow HP, -16 Elbow LP Pressure 002 - 16 Tee HP, -16 Elbow LP 004 - 16 Elbow HP, -20 Tee LP 250 - 2500 psi 300 - 3000 psi Style... -
Page 9: Overall Dimensions
Overall Dimensions Oil Filler Tighten to 22 ft / lbs (30Nm) when replacing the filter element. Low Pressure Return Connection 1”JIC Male Elbow HP Connections 3/4” JIC Male Tee (In/Out) Suction Connection 1-1/2” Code 61 with 1-1/4” hose barb elbow (supplied loose) Note: To avoid premature failure, hydraulic hoses must be supported and not allowed to hang or pull-on cooler connections. -
Page 10: Parts List & Filter Breakdown
Parts List... - Page 11 Parts List Item Part Number Description QTY. STD QTY. SQ. 214-012 Capscrew Button Head 5/16 X 3/4" - S/S 228-010 Capscrew Hex HD Gr5 5/16" X 1" Pl 284-026 Nut Hex 5/16-18 Nyloc Pl 294-010 Washer Lock Gr5 1/2" Pl 300-007 Hyd Mtr Fan - HD/SL Hydraflow (New Style) 313-018...
- Page 12 Parts List (cont.) Item Part Number Description QTY. STD QTY. SQ. 313-021 Hyd "T" Clamp Heavy Duty -16 hose (HF/SL) 85234 Nut 5/16'' plated 85236 Hyd Hose Fan Motor Return 1/2''x4 3/4 OAL 85237 Clamp,HSE 1/2'' Heavy Duty 313-017 Hyd "T" Clamp Heavy Duty -8 hose 284-000 Nut Hex GR5 1/2'' Zinc Plated 85242-1...
- Page 13 Filter Breakdown Included with Diffuser Assy Filter Lid Assy Included with Filter Assy *Spring is optional Hold Down Spring Filter Assy Diffuser Assy: 352-003 / 352-008 (w/ lip) Filter Lid Assy: 351-006 Filter Element Filter Assy: 351-004 Filter Lid: 522-001 Hold Down Spring: 580-001 Filter Element: 350-001...
- Page 14 Filter Head Options Filter Head without Lip Part # 352-003 Filter Head with Lip Part # 352-008...
-
Page 16: Warranty
GENERAL PROVISIONS AND LIMITATIONS Paragon Tank Truck Equipment LLC (the “Company”) warrants to each original retail purchaser (“Purchaser”) of its products from the Company or its authorized distributor that such products are, at the time of delivery to the Purchaser, made with good material and workmanship. - Page 17 If a warrantable complaint occurs within 90 days from shipment: 1. Freight will be reimbursed for both the replacement item and the returned suspect part (if Requested by Paragon). This allowance will cover only transportation via Paragon selected most economical method within the continental United States, Canada and Mexico.
-
Page 18: Additional Notes
Additional Notes... - Page 19 Additional Notes...
- Page 20 Paragon Tank Truck Equipment www.paragondirect.com ©2025 Paragon Tank Truck Equipment, LLC Printed in U.S.A. PRGMAN-09_C 1st Ed. 04/25 Supersedes PRGMAN-09_B 1st Ed. 01/25 Please recycle after use.
