INSTALLATION
MANUAL
Manual Brel Bi-Directional Rollerblind motor
BLE45-20
Read the manual before you begin the
installation. If these instructions are not
followed, this may lead to defects and
injury in which warranty can't be claimed.
www.brel-home.com
Visit our website for more manuals and information
BLE45-20
Scan the QR code here for the manual to
download & view instructional videos
M O T O R S
EN NL DE FR
Advertisement
Table of Contents
Related Manuals for BREL BLE45-20
Summary of Contents for BREL BLE45-20
- Page 1 EN NL DE FR M O T O R S INSTALLATION MANUAL Manual Brel Bi-Directional Rollerblind motor BLE45-20 Read the manual before you begin the installation. If these instructions are not followed, this may lead to defects and injury in which warranty can’t be claimed.
- Page 2 Page 2 Table of Content Warning Wiring/Installing the motor/Works with BREL HOME Technical data of the motor/Reach/Charging the motor Functions remote control Settings Warning Do not operate the motor BREL-Motors declares that this in humid surroundings. motor has been manufactured...
-
Page 3: Installing The Motor
Place the motor in the tube of the roller/shutter. Works with BREL HOME Brel-Home-USB With the Brel-Home-USB you can control your motor with your Phone. You can make a time schedule and make scenario's. The Brel-Home-USB can be connected to Siri, Google Home and Alexa. - Page 4 Page 4 Technical data of the motor BLE45-20 Motor Voltage DC 12V Charge Voltage DC 12V Maximum Ampere Charger 1.75 A Power 21 W Torque 20 Nm Speed 10 rpm Amperage 4.1 A Moisture and Dust IP 44 Storage capacity is up to 20 channels...
- Page 5 There are 2x P2 buttons, no matter which one you press. Scan the QR code here for the manual to download & view instructional videos BLE45-20 Step 1 Setting up the first remote/channel The remote control can transmit 15 channels and therefore control multiple blinds.
- Page 6 Page 6 Step 3 Adjusting the direction of rotation (Only if the direction of rotation is not correct) Only possible if no end positions are set. until Press UP and DOWN button The direction of rotation of simultaneously, until the product moves. the motor is OK.
-
Page 7: Additional Settings
Page 7 Additional settings Adjusting the top position Option A If adjustment is not possible, go to Resetting factory settings. STOP until STOP until Press at the same time STOP Go to the new Press at the same time top position. STOP and UP button, and UP until the motor moves. - Page 8 Page 8 Option D Sun- and windmeter (DD-116 and DD-118) Add / remove 1x p2a 1x p2a 1x p2b The sun and wind meter has been added. Press P2 of a. The product Press P2 of a. The product Press P2 of b. The product moves 1x up and down and moves 1x up and down and moves 2x up and down and...
-
Page 9: Changing The Direction Of Rotation
BREL Brel Netherlands B.V. is registered according to the transposition of Directive 2012/19EU (the WEEE Directive) and to the transposition of Directive 2006/66EC (the Battery Directive) at the Irish registry The Producer Register with the registration number 3408WB.
