Page 1: Table Of Contents
INSTRUCTIONS FOR OPERATION AND ASSEMBLY Safety switch with separate actuator AZ201-I2-CC-T-1P2P Table of Contents 1 About this document 1.1 Function 1.2 Target group of the operating instructions: authorised qualified personnel 1.3 Explanation of the symbols used 1.4 Appropriate use 1.5 General safety instructions 1.6 Warning about misuse... -
Page 2: Function
Warning: Failure to comply with this warning notice could lead to physical injury and/or damage to the machine. 1.4 Appropriate use The Schmersal range of products is not intended for private consumers. The products described in these operating instructions are developed to execute safety-related functions as part of an entire plant or machine. -
Page 3: Warning About Misuse
Further technical information can be found in the Schmersal catalogues or in the online catalogue on the Internet: products.schmersal.com. The information contained in this operating instructions manual is provided without liability and is subject to technical modifications. There are no residual risks, provided that the safety instructions as well as the instructions regarding mounting, commissioning, operation and maintenance are observed. -
Page 4: Special Versions
SD2P serial diagnostic output and 2 p-type safety outputs Actuator suitable for AZ/AZM201-B1-... Sliding safety guards AZ/AZM201-B30-... Hinged safety guards AZ/AZM201-B40-... Hinged-doors with overlapping folds Only if the information described in this operating instructions manual are followed correctly, the safety function and therefore the compliance with the Machinery Directive is maintained. -
Page 5: Technical Data
2.4 Technical Data Approvals - Standards Certificates TÜV cULus ANATEL General data Standards EN ISO 13849-1 EN ISO 14119 EN IEC 60947-5-3 EN IEC 61508 Coding Individual coding, multiple teaching Coding level according to EN ISO 14119 High Working principle RFID, 125 kHz Transmitter output RFID, maximum -6 dB/m... - Page 6 Performance Level, up to Category PFH value 1.90 x 10⁻⁹ /h PFD value 1.60 x 10⁻⁴ Safety Integrity Level (SIL), suitable for applications in Mission time 20 Year(s) Mechanical data Mechanical life, minimum 1,000,000 Operations Latching force 30 N Actuating speed, maximum 0.2 m/s Type of the fixing screws 2x M6...
- Page 7 Wire cross-section 23 ... 15 AWG Allowed type of cable solid single-wire solid multi-wire flexible Mechanical data - Dimensions Length of sensor 50 mm Width of sensor 40 mm Height of sensor 220 mm Ambient conditions Degree of protection IP67 IP66 Ambient temperature -25 ...
- Page 8 Time to readiness, maximum 4,000 ms Switching frequency, maximum 1 Hz Electrical data - Safety digital inputs Designation, Safety inputs X1 and X2 Switching thresholds −3 V … 5 V (Low) 15 V … 30 V (High) Current consumption at 24 V 5 mA Test pulse duration, maximum 1 ms...
-
Page 9: Mounting
This device complies with the nerve stimulation limits (ISED CNR-102) when operated at a minimum distance of 100 In the event of changes or modifications that have not been expressly approved by K.A. Schmersal GmbH & Co. KG, the user's authorisation to use the device may become ineffective. -
Page 10: Dimensions
For fitting the safety switch and the actuator, two mounting holes for M6 screws with washers (washers included in delivery) are provided. The safety switch must not be used as end stop. Any position is possible. The mounting position however must be chosen so that the ingress of dirt and soiling in the used opening is avoided. The unused actuator opening must be sealed by means of the dust-proof flap (included in delivery). -
Page 11: Electrical Connection
Legend B: Active RFID area Metal parts and magnetic fields in the lateral RFID area of the safety switchgear and the actuator can influence the switching distance or lead to malfunctions. 4 Electrical connection 4.1 General information for electrical connection The electrical connection may only be carried out by authorised personnel in a de-energised condition. -
Page 12: Requirements For The Connected Safety-Monitoring Module
The safety-monitoring module does not need to have a cross-wire short monitoring function, if necessary, the cross-wire short monitoring function must be disabled. Information for the selection of suitable safety-monitoring modules can be found in the Schmersal catalogues or in the online catalogue on the Internet: products.schmersal.com 4.3 Serial diagnostic -SD... -
Page 13: Wiring Configuration And Connector Accessories
On wiring SD devices, please pay attention to the voltage drop on the cables and the current carrying capacity of the individual components. 4.4 Wiring configuration and connector accessories Function safety switchgear Configuration Colour codes of Poss. colour configuration of of the the Schmersal code of other the connector removable connector plugs commercially ST2, M12, 8- terminal blocks to DIN 47100... -
Page 14: Wiring Examples For Series-Wiring
4.5 Wiring examples for series-wiring Series-wiring can be set up. In the case of a series connection, the risk time remains unchanged and the reaction time increases by the sum of the reaction time of the inputs per additional unit specified in the technical data. The quantity of devices is only limited by the cable drops and the external cable fuse protection, according to the technical data. -
Page 15: Actuator Teaching / Actuator Detection
Y1 and Y2 = Safety outputs → Safety monitoring module SD-IN → Gateway → Field bus 5 Actuator teaching / actuator detection Safety switches with standard coding are ready to use upon delivery. Individually coded safety switches and actuators will require the following "teach-in" procedure: 1. -
Page 16: Active Principle And Diagnostic Functions
6 Active principle and diagnostic functions 6.1 Mode of operation of the safety outputs The opening of the safety guard causes the safety outputs to be disabled within the risk time. 6.2 Diagnostic-LEDs The safety switchgear signals the operational state as well as errors through three coloured LEDs installed on the front side of the device. - Page 17 Table 1: Diagnostic information of the safety switchgear System condition Safety outputs Diagnostic output Y1, Y2 -1P2P green yellow Door open Door closed, actuator not inserted Door closed, 24 V 24 V actuator inserted Error warning Flashes 24 V actuator inserted, shutdown approaching Error...
-
Page 18: Safety Switch With Serial Diagnostic Function Sd
In this way, the diagnostic signals can be evaluated by means of a PLC. The necessary software for the integration of the SD-Gateway is available for download at products.schmersal.com. The response data and the diagnostic data are automatically and permanently written in an input byte of the PLC for each safety switch in the series-wired chain. -
Page 19: Set-Up And Maintenance
Automatic, electronic locking takes place if more than one fault is detected at the safety outputs or a cross circuit is detected between Y1 and Y2. This means that normal fault acknowledgement is no longer possible. To reset this type of interlocking, the safety switch must be isolated from the power supply after elimination of the error causes. -
Page 20: Disassembly And Disposal
Adequate measures must be taken to ensure protection against tampering either to prevent tampering of the safety guard, for instance by means of replacement actuators. Damaged or defective components must be replaced. 8 Disassembly and disposal 8.1 Disassembly The safety switchgear must be disassembled in a de-energised condition only. 8.2 Disposal £... - Page 21 Connecting cables with coupling (female) IP67, M23, 12 pole - 12 x 0.75 mm² Cable length Ordering code 5.0 m 101208520 10.0 m 103007354 20.0 m 101214418 Special version -2965-2 Connecting cables with coupling (female) IP67, M23, 8+1 pole - 9 x 0.75 mm² Cable length Ordering code 5.0 m...
- Page 22 103007359 22-22 Schmersal, Inc., 115 E Stevens Ave, Suite 208, Valhalla, NY 10595 The details and data referred to have been carefully checked. Images may diverge from original. Further technical data can be found in the manual. Technical amendments and errors possible.
