INSTRUCTIONS FOR OPERATION AND ASSEMBLY
Safety switch with separate actuator AZ201-I2-CC-T-1P2P

Table of Contents

1 About this document
1 About this document
1-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AZ201-I2-CC-T-1P2P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for schmersal AZ201-I2-CC-T-1P2P

Summary of Contents for schmersal AZ201-I2-CC-T-1P2P

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR OPERATION AND ASSEMBLY Safety switch with separate actuator AZ201-I2-CC-T-1P2P Table of Contents 1 About this document 1.1 Function 1.2 Target group of the operating instructions: authorised qualified personnel 1.3 Explanation of the symbols used 1.4 Appropriate use 1.5 General safety instructions 1.6 Warning about misuse...

  • Page 2: Function

    Warning:Failure to comply with this warning notice could lead to physical injury and/or damage to the machine. 1.4 Appropriate use The Schmersal range of products is not intended for private consumers. The products described in these operating instructions are developed to execute safety-related functions as part of an entire plant or machine.

  • Page 3: Warning About Misuse

    The user must observe the safety instructions in this operating instructions manual, the country specific installation standards as well as all prevailing safety regulations and accident prevention rules. Further technical information can be found in the Schmersal catalogues or in the online catalogue on the Internet: products.schmersal.com.

  • Page 4: Special Versions

    1P2P 1 serial diagnostic output and 2 p-type safety outputs SD2P serial diagnostic output and 2 p-type safety outputs Actuator suitable for AZ/AZM201-B1-... Sliding safety guards AZ/AZM201-B30-... Hinged safety guards AZ/AZM201-B40-... Hinged-doors with overlapping folds 2.2 Special versions For special versions, which are not listed in the ordering code, these specifications apply accordingly, provided that they correspond to the standard version.

  • Page 5: Technical Data

    2.4 Technical Data Approvals - Standards Certificates TÜV cULus General data Standards EN ISO 13849-1 EN ISO 14119 EN IEC 60947-5-3 EN IEC 61508 Coding Individual coding, multiple teaching Coding level according to EN ISO 14119 High Working principle RFID, 125 kHz Transmitter output RFID, maximum -6 dB/m Housing material...
  • Page 6 Performance Level, up to Category PFH value 1.90 x 10⁻⁹ /h PFD value 1.60 x 10⁻⁴ Safety Integrity Level (SIL), suitable for applications in Mission time 20 Year(s) Mechanical data Mechanical life, minimum 1,000,000 Operations Latching force 30 N Actuating speed, maximum 0.2 m/s Type of the fixing screws 2x M6...
  • Page 7 Wire cross-section 23 ... 15 AWG Allowed type of cable solid single-wire solid multi-wire flexible Mechanical data - Dimensions Length of sensor 50 mm Width of sensor 40 mm Height of sensor 220 mm Ambient conditions Degree of protection IP67 IP66 Ambient temperature -25 ...
  • Page 8 External wire and device fuse rating 4 A gG Time to readiness, maximum 4,000 ms Switching frequency, maximum 1 Hz Electrical data - Safety digital inputs Designation, Safety inputs X1 and X2 Switching thresholds −3 V … 5 V (Low) 15 V …...

  • Page 9: Mounting

    This device complies with the nerve stimulation limits (ISED CNR-102) when operated at a minimum distance of 100 In the event of changes or modifications that have not been expressly approved by K.A. Schmersal GmbH & Co. KG, the user's authorisation to use the device may become ineffective.

  • Page 10: Dimensions

    Please observe the relevant requirements of the standards ISO 12100, ISO 14119 and ISO 14120. For fitting the solenoid interlock, two mounting holes for M6 screws with washers (washers included in delivery) are provided. The solenoid interlock must not be used as an end stop. Any mounting position. The mounting position however must be chosen so that the ingress of dirt and soiling in the used opening is avoided.

  • Page 11: Electrical Connection

    Legende B: Aktiver RFID-Bereich Metal parts and magnetic fields in the lateral RFID area of the solenoid interlock and the actuator can influence the switching distance or lead to malfunctions. 4 Electrical connection 4.1 General information for electrical connection The electrical connection may only be carried out by authorised personnel in a de-energised condition. The power supply must have protection against permanent overvoltage.

  • Page 12: Anforderungen An Eine Nachgeschaltete Auswertung

    The safety-monitoring module does not need to have a cross-wire short monitoring function, if necessary, the cross-wire short monitoring function must be disabled. Information for the selection of suitable safety-monitoring modules can be found in the Schmersal catalogues or in the online catalogue on the Internet: products.schmersal.com.

  • Page 13: Wiring Examples For Series-Wiring

    Funktion Sicherheitsschaltgerät Pinbelegung Belegung der Farbcodes der Mögl. Farbcode abnehmbaren Schmersal- weiterer Einbausteckers Klemmleisten Steckverbinder handelsüblicher ST2, M12, 8- gemäß DIN Steckverbinder polig 47100 gemäß EN 60947-5-2   mit serieller konventionelle Diagnosefunkti Diagnoseausga Sicherheitseingang 1 Sicherheitsausgang 1 Diagnoseausgang SD-Ausgang Sicherheitseingang 2...

  • Page 14: Actuator Teaching / Actuator Detection

    Der Aufbau einer Reihenschaltung ist möglich. Bei einer Reihenschaltung bleibt die Risikozeit unverändert und die Reaktionszeit erhöht sich um die Summe der in den technischen Daten angegebenen Reaktionszeit der Eingänge pro zusätzlichem Gerät. Die Anzahl der Geräte ist lediglich durch die Leitungsverluste und die externe Leitungsabsicherung, gemäß...

  • Page 15: Active Principle And Diagnostic Functions

    Solenoid interlocks with standard coding are ready to use upon delivery. Individually coded solenoid interlocks and actuators will require the following "teach-in" procedure: 1. Switch the solenoid interlock's voltage supply off and back on. 2. Introduce the actuator in the detection range. The teach-in procedure is signalled at the solenoid interlock, green LED off, red LED on, yellow LED flashes (1 Hz).
  • Page 16 disabled within the duration of risk. After fault rectification, the error message is reset by opening and re-closing the corresponding safety guard. Automatic, electronic locking takes place if more than one fault is detected at the safety outputs or a cross circuit is detected between Y1 and Y2.

  • Page 17: Sicherheitsschalter Mit Serieller Diagnosefunktion Sd

    Diagnose-Interface wird als Slave in ein vorhandenes Feldbus-System eingebunden. Die Diagnosesignale können auf diese Weise mit einer SPS ausgewertet werden. The necessary software for the integration of the SD-Gateway is available for download at products.schmersal.com. Die Antwortdaten und die Diagnosedaten werden für jeden Sicherheitsschalter in der Reihenschaltungskette automatisch und kontinuierlich jeweils in ein Eingangsbyte der SPS geschrieben.

  • Page 18: Set-Up And Maintenance

    Automatic, electronic locking takes place if more than one fault is detected at the safety outputs or a cross circuit is detected between Y1 and Y2. This means that normal fault acknowledgement is no longer possible. To reset this type of interlock, the solenoid interlock must be isolated from the supply voltage after elimination of the error causes.

  • Page 19: Disassembly And Disposal

    5. Remove particles of dust and soiling. Adequate measures must be taken to ensure protection against tampering either to prevent tampering of the safety guard, for instance by means of replacement actuators. Damaged or defective components must be replaced. 8 Disassembly and disposal 8.1 Disassembly The safety switchgear must be disassembled in a de-energised condition only.
  • Page 20 Connecting cables with coupling (female) IP67, M23, 12 pole - 12 x 0.75 mm² Cable length Ordering code 5.0 m 101208520 10.0 m 103007354 20.0 m 101214418 Special version -2965-2 Connecting cables with coupling (female) IP67, M23, 8+1 pole - 9 x 0.75 mm² Cable length Ordering code 5.0 m...
  • Page 21 21-21 Schmersal Canada Ltd., 29 Centennial Road, Unit 1, Orangeville, Ontario L9W 1R1 Canada The details and data referred to have been carefully checked. Images may diverge from original. Further technical data can be found in the manual. Technical amendments and errors possible.
