Installation - Home Decorators Collection 28616-HBBS Use And Care Manual

Installation

1
Installing the bubble glass
□ Carefully unpack the xture. Lay out all the parts on a clean
surface.
□ Attach the bubble glass (B) to the xture body (A). Then
tighten the hexagon socket screws (FF) by using a
hexagon screwdriver (HH).
HH
3
Making the electrical connections
□
Connect the red wire of the driver to the red wire of the
xture and connect the blue wire of the driver to the
blue wire of the xture.
AC INPUT
Black
White
B
FF
A
B
DC OUTPUT
Red
Blue
5
2
Installing the canopy
□ Attach the xture body (A) to the canopy (C). Then tighten
the xing screws (GG) by using a Phillips screwdriver (not
included).
In order to KD the package
The wire connection will
be connected by the user
RED WIRE
FROM DRIVER
BLUE WIRE
FROM DRIVER
Please contact 1-800-986-3460 for further assistance.
A
GG
C
RED WIRE
FROM FIXTURE
BLUE WIRE
FROM FIXTURE
WWW.HOMEDEPOT.CA
