WINDOW TYPE ROOM AIR CONDITIONER
User's Manual
EWM05B
EWR06BE
EWR08BE
EWR10BE
EWR12BE
EWR14B
IMPORTANT NOTE:
Before using your air conditioner, please read
•
this manual carefully and keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWM05B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Element EWM05B

Summary of Contents for Element EWM05B

  • Page 1 WINDOW TYPE ROOM AIR CONDITIONER User’s Manual EWM05B EWR06BE EWR08BE EWR10BE EWR12BE EWR14B IMPORTANT NOTE: Before using your air conditioner, please read • this manual carefully and keep it for future reference.

  • Page 2: Table Of Contents

    Table of Contents Important Safety Instructions ...........03 Installation Instructions..............13 Normal Sounds................27 Air Conditioner Features............28 Care and Cleaning...............33 Troubleshooting Tips..............34...

  • Page 3: Important Safety Instructions

    Important Safety Instructions READ THIS MANUAL Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner.
  • Page 4 CAUTION When the air filter is to be removed, do not touch the metal parts of the unit. It may cause an injury. Do not put a pet or house plant where it will be exposed to direct air flow. This could injure the pet or plant. Ventilate the room well when used together with a stove, etc.
  • Page 5 NOTE: The power supply cord with this air conditioner contains a current detection device designed to reduce the risk of fire. Please refer to the section Operation of Current Device for details.In the event that the power supply cord is damaged, it cannot be repaired-it must be replaced with acord from the Product Manufacturer.
  • Page 6 Operation of Current Device (Applicable to the unit adopts current detection device only ) The power supply cord contains a current device that senses damage to the power cord. To test your power supply cord do the following: 1. Plug in the Air Conditioner. 2.
  • Page 7 -Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. -DO NOT modify the length of the power cord or use an extension cord to power the unit. DO NOT share a single outlet with other electrical appliances.
  • Page 8 WARNINGS (for using R290/R32 refrigerant only) 1.Transport of equipment containing flammable refrigerants See transport regulations 2.Marking of equipment using signs See local regulations 3.Disposal of equipment using flammable refrigerants See national regulations. 4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions. 5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
  • Page 9 WARNINGS (for using R290/R32 refrigerant only) 7)ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
  • Page 10 WARNINGS (for using R290/R32 refrigerant only) Ensure that seals or sealing materials have not degraded such that they no longer serve the purpose of preventing the ingress of flammable atmospheres. Replacement parts shall be in accordance with the manufacturer's specifications. NOTE: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment.
  • Page 11 WARNINGS (for using R290/R32 refrigerant only) Open the circuit by cutting or brazing. The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be flushed with OFN to render the unit safe. This process may need to be repeated several times.
  • Page 12 WARNINGS (for using R290/R32 refrigerant only) j)When the cylinders have been filled correctly and the process completed, make sure that the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed off. k)Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked.

  • Page 13: Installation Instructions

    Installation Instructions The unit you purchased may be look like one of the followings: NOTE: NOTE: All the illustrations in this manual are for explanation purpose only. The air conditioner you have may be slightly different. The actual shape shall prevail. ...
  • Page 14 Installation Instructions (for 5000 to 14500Btu/h) BEFORE YOU BEGIN Read these instructions completely and carefully. 6000~8000Btu/h 10000~14500Btu/h 5000~6000Btu/h Model MPORTANT-Save these instructions for local inspector’s use. 14 (356mm) 15-1/2 (394mm) 13 (330mm) IMPORTANT-Observe all governing codes Ta b le 1 and ordianaces.
  • Page 15 C: Align the hole in the top rail with those in the PREPARE THE WINDOW top of the unit as shown in Fig.B Lower sash must open sufficiently to allow a clear Fig.B vertical opening. The window opening height shall be based on the different Models: 13inches/330mm(5k~6k units), 14inches/356mm (6k~8k units), 15-1/2inches/394mm(10k~12k units).
  • Page 16 B. Slide the free end " I" section of the panel SECURE THE ACCORDION PANELS directly into the cabinet as shown in Fig. 2. Slide the panel down. Be sure to leave enough A. Keep a firm grip on the air conditioner, space to slip the top and bottom of the frame carefully place the unit into the window into the rails on the cabinet.
  • Page 17 INSTALL R1 HARDWARE (only applicable to ≥15000Btu/h Energy star models ) In order to minimize air leaks and ensure optimal insulation, it is necessary to install the included Fig.7A Fig.7B R1 hardware to the side curtain. Follow the instructions below. DRIVE LOCKING SCREWS Step 1.
  • Page 18 Step 3. Slide the R1 insulation panel into the side If AC is Blocked by Storm Window curtain, the side with pattern should facing the indoor side.(Fig.13) Add wood as shown in Fig.15, or remove storm window before air conditioner is installed.
  • Page 19 Preliminary Instructions Installation Instructions (for 15000 to 28500Btu/h) Window Sash Seal Safety Lock and 3 /4 (or1/2 ) Long Hex Head Screw BEFORE YOU BEGIN Top Angle Foam Gasket Read these instructions completely and Washer Head Locking screw carefully. IMPORTANT-Save these instructions for Frame Assembly (Left)
  • Page 20 windows-- if your Check your storm A. Window Mounting storm window frame does not allow the clea- rance required, correct by adding a piece of Remove Air Conditioner from Cabinet wood as shown in Fig.E,or by removing storm NOTE: Remove any packaging material from window while room air conditioner is being cabinet exterior.
  • Page 21 10. Your unit may come with internal packaging. Air Conditioner Plastic Cabinet This packaging must be removed prior to installing Frame View the air conditioner back into the cabinet.(see Fig .7). Locking Screw "Ⅰ" Section Shipping Packaging Hole Window Filler Panel Fig.10 Plastic tie...
  • Page 22 1 2 Long Screws Left And Locknuts 3 4 (or1 )Long Hex-head Screw Locknut Sill Angle Right Bracket Flat Head Bolt Fig.13 Fig.13B 2 Each Required For Each Support Bracket Install Support Bracket Fig.15B 1. Hold each support bracket flush against outside 3.
  • Page 23 4. Attach the top angle to window frame: Use a 3. Attach the Lock Frames to the winow sill 3/32" drill bit to drill one hole through the hole using two 3/ 4 " (19mm) screws(Fig.18C) in the middle of top angle into the window frame, (on some models) and drive one 3/ 4 "...
  • Page 24 Install Chassis into Cabinet and Install Front to Unit 1. Lift air conditioner and carefully slide into cabinet leaving 6 inches protruding. 2. DO NOT push on controls or finned coils. 3. Be sure chassis is firmly seated towards rear of cabinet.
  • Page 25 WIDTH " X"= inside model width plus twice the B. Thru-The-Wall Installation thickness of framing material used. HEIGHT '' Y " = inside model height plus twice NOTE: Consult local building codes prior to the thickness of framing material used. installation or a qualified carpenter.
  • Page 26 5. Screw or nail cabinet wooden frame using shims Prepare and Install Cabinet if frame is oversized to eliminate distortion. See 1. Slide chass is from cabinet. Refer back to Fig.8.Remember to maintain proper slope as Step one of Window Mounting. described in Step 3.

  • Page 27: Normal Sounds

    Normal Sounds Pinging or Switching Vibration Droplets of water hitting condenser during High Pitched Chatter Unit may vibrate and make noise normal operation may cause “pinging or swishing” sounds. This noise can be reduce by because of poor wall or window High efficiency compressors removing the water plug at the bottom of unit's “construction or incorrect ”installation.

  • Page 28: Air Conditioner Features

    Air Conditioner Features To begin operating the air conditioner, WARNING follow these steps: 1. Set the thermostat to the highest number To reduce the risk of fire, electric shock, or (coldest or cooler setting). injury to persons, read the IMPORTANT 2.
  • Page 29 Fresh Air Vent Control (on 15~28.5K models): Fig. A (VENT CLOSED) Fig. B Fig. C (VENT OPEN) (VENT & EXHAUST OPEN) The Fresh Air Vent allows the air conditioner to: 1. Recirculate inside air - Vent Closed (See Fig.A) 2. Draw fresh air into the room- Vent Open (see Fig.B) 3.
  • Page 30 ELECTRONIC CONTROL OPERATING INSTRUCTIONS Different models have different control buttons and indicator lights. Not all the control buttons NOTE: and indicator lights describing below are available for the unit you purchased. Please check the control panel of the unit you purchased. The unit can be controlled by the unit control alone or with the remote. TEMP/TIMER Auto Auto...
  • Page 31 FOLLOW ME FEATURE: SLEEP FEATURE: (on some models) Press Sleep button to initiate the sleep mode. Light flashes or In this mode the selected temperature will illuminates Follow ° increase (cooling) or decrease (heating) by 2 ° (or 2) C 30 minutes after the mode is selected. This feature can be activated from the remote The temperature will then increase (cooling) or control ONLY.
  • Page 32 • Turning the unit ON or OFF at any time or a To operate on Auto feature: djusting the timer setting to 0.0 will cancel the • When you set the air conditioner in AUTO mode, Auto Start/Stop timed program. it will automatically select cooling, heating(cooling only models without), or fan only operation DISPLAYS:...

  • Page 33: Care And Cleaning

    Care and Cleaning The air filter should be checked at least once a CAUTION month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an Clean your air conditioner occasionally to accumulation of frost on the cooling coils. keep it looking new.

  • Page 34: Troubleshooting Tips

    Room temperature below 62°F(17°C). Cooling may not occur until room temperature rises above 62°F(17°C). Air from unit does Temperature sensing behind air filter element touching cold coil. Keep it from the cold coil. not feel cold Set to a Lower temperature.
  • Page 35 Problem Solution Water dripping Improper installation. Tilt air conditioner slightly to the outside to allow water drainage. INSIDE when unit Refer to installation instructions - check with installer. is cooling. Unit removing large quantity of moisture from humid room. This is normal during Water dripping excessively humid days.
  • Page 36 (“Warranty”) as follows: * PLEASE NOTE – Proof of purchase evidencing the date of purchase by the Original Purchaser from an authorized Element retailer (“Valid Proof of Purchase”) is required for all Warranty service. The express Warranty set forth herein is subject to all terms and conditions set forth below.
  • Page 37 United States, and only applies to Product if it was purchased and serviced in the United States. The addition of equipment or features to the Product that are not manufactured or recommended by Element could affect the intended function of the Product, and therefore may void the Warranty.
  • Page 38 Element, the Element Logo, and Bring it home are trademarks of Element Brand Holding, LLC. All other trademarks are the property of their respective owner, who has not sponsored, endorsed, or approved this product. © 2023 Element Appliance Company, LLC. All rights reserved.
  • Page 39 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. CWS002IU-TYN8(GF) COMPⅡ...
  • Page 40 REMOTE CONTROL OWNER’S MANUAL EWR06BE EWR08BE EWR10BE EWR12BE EWR14B EWR18BE EWR25BE IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference.
  • Page 41 Table of Contents Remote Control Specifications ..........02 Handling the Remote Control ..........03 Buttons and Functions ..............04 Remote Screen Indicators ............08 How to Use Basic Functions ............09 How to Use Advanced Functions ..........12...

  • Page 42: Remote Control Specifications

    Remote Control Specifications RG51G(1)/CEFU1,RG51G(1)/EFU1,RG51G1(1)/EFU1, Model RG51G4(1)/EU1,RG51G5(1)/EU1, RG51G4(1)/CEU1 RG51G5(1)/CEU1 3.0V( Dry batteries R03/LR03×2) Rated Voltage Signal Receiving Range 23°F~140°F (-5°C~60°C) Environment Quick Start Guide AUTO COOL HEAT FIT BATTERIES SELECT MODE SELECT TEMPERATURE AUTO HIGH SELECT FAN SPEED POINT REMOTE TOWARD UNIT PRESS POWER BUTTON NOT SURE WHAT A FUNCTION DOES? Refer to the How to Use Basic Functions and How to Use Advanced Functions sections...

  • Page 43: Handling The Remote Control

    Handling the Remote Control Inserting and Replacing Batteries NOTES FOR USING REMOTE CONTROL The device could comply with the local national Your air conditioning unit may come with two regulations. batteries(some units). Put the batteries in the • In Canada, it should comply with remote control before use.

  • Page 44: Buttons And Functions

    Buttons and Functions Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air conditioner, refer to the How to Use Basic Functions section of this manual.
  • Page 45 TEMP  Decreases temperate in 1°F (1°C) increments. Min. temperature is TEMP  62°F(17°C). Increases temperate in 1°F (1°C) increments. ON/OFF Turns the unit on or Max. temperature is off. 86°F(30°C). MODE FAN SPEED Scrolls through Selects fan speeds in operation modes the following order: as follows:...
  • Page 46 TEMP  Increases temperate in1°F (1°C) increments. TEMP  Max. temperature is Decreases temperate 86°F(30°C). in1°F (1°C) increments. Press together Min. temperature is NOTE: & buttons at the 62°F(17°C).   same time for 3 seconds will alternatethe ON/OFF Turns the unit on or temperature display off.
  • Page 47 TEMP  Decreases temperate TEMP  in1°F (1°C) increments. Increases temperate Min. temperature is in1°F (1°C) increments. 62°F(17°C). Max. temperature is 86°F(30°C). ON/OFF Turns the unit on or off. MODE Scrolls through operation modes as follows: FAN SPEED AUTO  COOL ...

  • Page 48: Remote Screen Indicators

    Remote Screen Indicators Information are displayed when the remote control is power up. Mode display COOL AUTO AUTO HEAT COOL HIGH Displayed when data transmitted. Displayed when remote controller is ON. HEAT Displayed when TIMER ON time is set Displayed when TIMER OFF time is set Shows set temperature or room temperature, or time under TIMER setting...

  • Page 49: How To Use Basic Functions

    How to Use Basic Functions Basic operation AUTO Mode ATTENTION! Before operation, please ensure the unit is plugged in and power is available. COOL Mode In AUTO mode, the unit will automatically select the COOL, FAN, or HEAT operation based on the set temperature. 1.
  • Page 50 1. Press the MODE button to select DRY. FAN Mode 2. Set your desired temperature using the button. TEMP TEMP   3. Press the button to start the unit. ON/OFF FAN SPEED cannot be changed NOTE: in DRY mode. ...
  • Page 51 Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER ON button to Press Temp. up or down button for Point remote to unit and wait initiate the ON time sequence.

  • Page 52: How To Use Advanced Functions

    How to Use Advanced Functions FOLLOW ME (some models) °C/°F (some models) Press FOLLOW ME button Press this button will alternate the temperature When the FOLLOW ME function is activated, display between the °C & °F. the remote display is actual temperature at its location.
  • Page 53 SHORTCUT function(some models) SHORT CUT Used to restore the current settings or resume previous settings.(For some models) Push this button when remote controller is on, the system will automatically revert back to the previous settings including operating mode, setting temperature, fan speed level and sleep feature(if activated).
  • Page 54 47 CFR § 2.1077 Compliance Information Unique Identifier: RG51G(1)/CEFU1,RG51G5(1)/CEU1 Responsible Party U.S. Contact Information Element Appliance Company, LLC jay.p@elementelectronics.com FCC Compliance Statement (e.g., products subject to Part 15) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 55 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CR252-RG51G(1)B...
