WALL/WINDOW TYPE ROOM AIR CONDITIONER

Owner's Manual

ETTW08D

ETTW10D

ETTW10DV

ETTW12D

ETTW12DV

ETTW14DV

IMPORTANT NOTE:

Before using your air conditioner, please read

this manual carefully and keep it for future reference.

TTW Series

Table of Contents

Need help?

Do you have a question about the ETTW08D and is the answer not in the manual?

Questions and answers

Summary of Contents for Element ETTW08D

Page 1 WALL/WINDOW TYPE ROOM AIR CONDITIONER Owner’s Manual ETTW08D ETTW10D ETTW10DV ETTW12D ETTW12DV ETTW14DV IMPORTANT NOTE: TTW Series Before using your air conditioner, please read this manual carefully and keep it for future reference.
Page 2: Table Of Contents
CONTENTS ......................Safety precautions Installation Instructions ......................What is in the box ....................Before you get started ....................Installing your product Operation Instructions ....................Get to know your AC ....................Get to know the features ....................Cleaning & Maintenance ......................Troubleshooting...
Page 3: Safety Precautions
Safety Precautions Must Read the Warning Message. Inside you will ﬁnd many helpful hints on how to use and maintain To prevent injury to the user or other people and property your air conditioner properly. Just a little preventive care on your damage, the following instructions must be followed.
Page 4 WARNING Plug in power plug properly. Otherwise, it may cause electric shock Unplug the unit if strange sounds, smell, or smoke or ﬁre due to excess heat generation. Do not operate or stop the unit comes from it. It may cause a ﬁre and electric shock. by inserting or pulling out the power plug.It may cause electric shock Do not use the socket if it is loose or damaged.
Page 5 CAUTION unless they have been given supervision or instruction Hold the plug by the head of the power plug when taking concerning use of the appliance by a person responsible for it out as it. It may cause electric shock and damage. Turn o the their safety.
Page 6 Operation of Current Device The power supply cord contains a current device that senses damage to the power cord. To test your power supply cord do the following: Plug in the Air Conditioner. The power supply cord will have TWO buttons on the plug head. Press the TEST button, you will notice a click as the RESET button pops out.
Page 7 WARNING Electrical Information For Your Safety The complete electical rating of your new room air conditioner Do not store or use gasoline or other ﬂammable vapors and is stated on the serial plate. Refer to the rating when checking liquids in the vicinity of this or any other appliance. the electrical requirements.
Page 8 WARNING for Using R32 Refrigerant Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater).
Page 9 WARNING -Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. -DO NOT modify the length of the power cord or use an extension cord to power the unit. -DO NOT share a single outlet with other electrical appliances.
Page 10 1.Transport of equipment containing ﬂammable refrigerants See transport regulations. 2.Marking of equipment using signs See local regulations. 3.Disposal of equipment using ﬂammable refrigerants See national regulations. 4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions. 5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
Page 11 6) No ignition sources No person carrying out work in relation to a refrigerating system which involves exposing any pipe work that contains or has contained ﬂammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of ﬁre or explosion.
Page 12 2) Particular attention shall be paid to the following to ensure that by working on electrical components, the casing is not altered in such a way that the level of protection is a ected. Check for damage to cables, excessive number of connections, terminals not made to original speciﬁcation, damage to seals, incorrect ﬁtting of glands, etc.
Page 13 11.Removal and evacuation When breaking into the refrigerant circuit to make repairs or for any other purpose conventional procedures shall be used. However, for ﬂammable refrigerants it is important that best practice is followed since ﬂammability is a consideration. The following procedure shall be adhered to: -Safely remove refrigerant following local and national regulations -Evacuate -Purge the circuit with inert gas (optional for A2L)
Page 14 a) Become familiar with the equipment and its operation. b) Isolate system electrically. c) Before attempting the procedure ensure that: Mechanical handling equipment is available, if required, for handling refrigerant cylinders; all personal protective equipment is available and being used correctly; the recovery process is supervised at all times by a competent person;...
Page 15: What Is In The Box
What's in the Box. Package Content Air Conditioner Unit Trim Frame (top & bottom legs)*2 Trim Frame (side legs)*2 Wall Sleeve (purchase separately) Aluminum Grille Plastic Grille (1/8"x4-1/2"x14-1/2") Centering/Support Blocks(Blue)*4 (4-1/2"x3-1/2"x1-1/2") Tapered Spacer Block(Blue)*2 (7/8"x1-1/8"x17") Stu er-seal*1 (1"x1-1/2"x84") Seal*2 (1"x1-1/2"x14") Seal*2 (1"x3/4"x14") Seal*2 (1"x3/8"x14") Seal*2 (1"x3/8"x25")
Page 16: Before Getting Started
Before Getting Started Preparations Before Installation NOTE The installation must be carried out n u a Installing your AC should take about in strict accordance with the instructions 60 minutes. Save Carton and these Installation in this manual. Instructions for future reference. The carton is the best way to store unit during winter, or when We’re here if you need us, please contact...
Page 17 Complete the Installation of the Wall Sleeve Preparations Before Unit Installation Install the wall sleeve and make grounding connection Remove old Air Conditioner from wall sleeve and prepare wall If there is no ground wire installation hole, please drill a 1/8 clearance sleeve (if any).
Page 18 Installation of Aluminum Grille Installation of New Grille Provided with Unit NOTE We have a new design for the rear grille (two rear air intakes) to improve the performance of the product. Please be sure to use the aluminum grille we provide for installation to achieve the best performance of the product. Most decorative exterior grilles may be left in place as long as the proper interior air direction grille is installed.
Page 19: Installing Your Product
Installing Your Product Installation Overview #9 White Westinghouse or Frigidaire for example NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly di erent. The actual shape shall prevail. IMPORTANT Nine installation methods we will If you have di culty Save these instructions for local inspectors provide, please choose one of the...
Page 20 #1 Emerson (15" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the plastic grille(NO.6) in the back, and attach it to the top of the...
Page 21 #2 Fedders (19-3/4" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the plastic grille(NO.6) in the back, and attach it to the top of the...
Page 22 #3 Fedders or Friedrich (16-3/4" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the plastic grille(NO.6) in the...
Page 23 #4 General Electra/Hotpoint (16-7/8" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the Cut the Seal(NO.12)
Page 24 #5 Sears or Carrier 51S Series (18-5/8" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the Cut the Seal(NO.12)
Page 25 #6 Whirlpool (17-1/8" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the Cut the Seal(NO.12) plastic grille(NO.6) in the...
Page 26 #7 Whirlpool (23" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the plastic grille(NO.6) in the For the sleeve with too Tear the Seal(NO.13) paper...
Page 27 #8 White Westinghouse/Frigidaire/ Installation Guide Carrier 52F Series (16/17-1/2" Deep) NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the Tear the Seal(NO.13) paper from the plastic grille(NO.6) in the...
Page 28 #9 White Westinghouse or Frigidaire (22" Deep) Installation Guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installing before embedding the product into the wall Don't forget to place the plastic grille(NO.6) in the For the sleeve with too...
Page 29 Installing the Aluminum Grille First Installation Guide NOTE The previous directions are the preferable way to mount the new Aluminum Grill. The units performance is slightly better and the possibility of droughts is reduced. As a last resort, direct mounting of the grille to the unit can be considered (the installation tutorial follows). The Aluminum Grille must be installed prior to inserting the unit into the sleeve.
Page 30 Cosmetic Work on Your Product Installation Guide Step 2 Step 1 Step 3 Do Some Cosmetic Work Installation is Complete Step 1: Assemble the Trim Step 2: Install the Long Step 3: Slide the frame, seal Congratulations on the installation, but Frame (No.
Page 31 Getting to Know Your AC AC Unit Overview Components of the Product Adjust the Air Direction Center Handles Air Direction Levers Status Display and Display Filter Handle Front Intake Grille Air directional levers control air ﬂow direction. Your air conditioner has the 4-way directional system described below.
Page 32: Get To Know The Features
Get to know the Features Electronic Control Operating Instructions NOTE Before you begin, thoroughly familiarize yourself with the control panel as shown below and all its functions, then follow the symbol for the functions you desire. The unit can be controlled by the unit control alone or with the remote. This control panel is based on the typical model.
Page 33: Energy Saver Feature
ELECTRONIC CONTROL OPERATING INSTRUCTIONS 6. ENERGY SAVER FEATURE: 8. TO SELECT THE OPERATING MODE: Press Energy Saver button to initiate this To choose operating mode, press Mode button. To operate on COOL mode: function. This function is available on COOL, DRY, Choose Cool Mode to set the cooling Each time you press the button, a mode is AUTO (only AUTO-COOLING and AUTO-FAN)
Page 34 ELECTRONIC CONTROL OPERATING INSTRUCTIONS 9. TIMER: AUTO START/STOP FEATURE: 10. DISPLAY: When the unit is on or o , ﬁrst press Timer button, Error codes: the TIMER ON indicator light illuminates. It indicates Displays AS-Room temperature sensor error-Unplug the the Auto Start program is initiated. unit and plug it back in.
Page 35 One More Thing Additional Notes Your AC May Look Additional Things Normal Sounds / You Should Know Sound Performance a Little Di erent All the illustrations in this manual are Now that you have mastered the operating High Pitched Chatter or explanation purpose only.
Page 36: Cleaning & Maintenance
Cleaning & Maintenance How to Clean & Change Your Filter Check the air ﬁlter at least once a month to see if cleaning is necessary. Air Filter Cleaning Energy Saving Note The air ﬁlter should be checked at In order to reach the maximum energy least once a month to see if cleaning saving and comfort, it is recommended is necessary.
Page 37: Troubleshooting
Power is OFF. Turn power ON. Room temperature below 62°F(17°C). Cooling may not occur until room temperature rises above 62°F(17°C). Air from unit does Temperature sensing behind air ﬁlter element touching cold coil. Keep it from the cold coil. not feel cold enough.
Page 38 Problem Solving Problem Solution Dirty air ﬁlter- air restricted. Clean air ﬁlter. Refer to Care and Cleaning section. Temperature is set too High, set temperature to a Lower setting. Air conditioner cooling, but room Air directional louvers positioned improperly. Position louvers for better air distribution. is too warm- NO ice forming on Front of units is blocked by drapes, blinds, furniture, etc.
Page 39: Warranty & Service
Product (“Warranty”) as follows: * PLEASE NOTE – Proof of purchase evidencing the date of purchase by the Original Purchaser from an authorized Element retailer (“Valid Proof of Purchase”) is required for all Warranty service. The express Warranty set forth herein is subject to all terms and conditions set forth below.
Page 40 Product if it was purchased and serviced in the United States. The addition of equipment or features to the Product that are not manufactured or recommended by Element could affect the intended function of the Product, and therefore may void the Warranty.
Page 41 ELEMENT SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THE PRODUCT. THESE INCLUDE, BUT ARE NOT LIMITED TO, ANY DAMAGES IN THE FORM OF LOST PROFITS, LOSS OF USE, LEGAL FEES, ECONOMIC LOSS, PERSONAL INJURIES, OR ANY OTHER DAMAGES CAUSED BY CIRCUMSTANCES BEYOND THE CONTROL OF ELEMENT.
Page 44 Element, the Element Logo, and Bring it home are trademarks of Element Brand Holding, LLC. All other trademarks are the property of their respective owner, who has not sponsored, endorsed, or approved this product. ©2024 Element Appliance Company, LLC. All rights reserved.
