Summary of Contents for Element EWR06BE
- Page 1 REMOTE CONTROL OWNER’S MANUAL EWR06BE EWR08BE EWR10BE EWR12BE EWR14B EWR18BE EWR25BE IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference.
-
Page 2: Table Of Contents
Table of Contents Remote Control Specifications ..........02 Handling the Remote Control ..........03 Buttons and Functions ..............04 Remote Screen Indicators ............08 How to Use Basic Functions ............09 How to Use Advanced Functions ..........12... -
Page 3: Remote Control Specifications
Remote Control Specifications RG51G(1)/CEFU1,RG51G(1)/EFU1,RG51G1(1)/EFU1, Model RG51G4(1)/EU1,RG51G5(1)/EU1, RG51G4(1)/CEU1 RG51G5(1)/CEU1 3.0V( Dry batteries R03/LR03×2) Rated Voltage Signal Receiving Range 23°F~140°F (-5°C~60°C) Environment Quick Start Guide AUTO COOL HEAT FIT BATTERIES SELECT MODE SELECT TEMPERATURE AUTO HIGH SELECT FAN SPEED POINT REMOTE TOWARD UNIT PRESS POWER BUTTON NOT SURE WHAT A FUNCTION DOES? Refer to the How to Use Basic Functions and How to Use Advanced Functions sections... -
Page 4: Handling The Remote Control
Handling the Remote Control Inserting and Replacing Batteries NOTES FOR USING REMOTE CONTROL The device could comply with the local national Your air conditioning unit may come with two regulations. batteries(some units). Put the batteries in the • In Canada, it should comply with remote control before use. -
Page 5: Buttons And Functions
Buttons and Functions Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air conditioner, refer to the How to Use Basic Functions section of this manual. - Page 6 TEMP Decreases temperate in 1°F (1°C) increments. Min. temperature is TEMP 62°F(17°C). Increases temperate in 1°F (1°C) increments. ON/OFF Turns the unit on or Max. temperature is off. 86°F(30°C). MODE FAN SPEED Scrolls through Selects fan speeds in operation modes the following order: as follows:...
- Page 7 TEMP Increases temperate in1°F (1°C) increments. TEMP Max. temperature is Decreases temperate 86°F(30°C). in1°F (1°C) increments. Press together Min. temperature is NOTE: & buttons at the 62°F(17°C). same time for 3 seconds will alternatethe ON/OFF Turns the unit on or temperature display off.
- Page 8 TEMP Decreases temperate TEMP in1°F (1°C) increments. Increases temperate Min. temperature is in1°F (1°C) increments. 62°F(17°C). Max. temperature is 86°F(30°C). ON/OFF Turns the unit on or off. MODE Scrolls through operation modes as follows: FAN SPEED AUTO COOL ...
-
Page 9: Remote Screen Indicators
Remote Screen Indicators Information are displayed when the remote control is power up. Mode display COOL AUTO AUTO HEAT COOL HIGH Displayed when data transmitted. Displayed when remote controller is ON. HEAT Displayed when TIMER ON time is set Displayed when TIMER OFF time is set Shows set temperature or room temperature, or time under TIMER setting... -
Page 10: How To Use Basic Functions
How to Use Basic Functions Basic operation AUTO Mode ATTENTION! Before operation, please ensure the unit is plugged in and power is available. COOL Mode In AUTO mode, the unit will automatically select the COOL, FAN, or HEAT operation based on the set temperature. 1. - Page 11 1. Press the MODE button to select DRY. FAN Mode 2. Set your desired temperature using the button. TEMP TEMP 3. Press the button to start the unit. ON/OFF FAN SPEED cannot be changed NOTE: in DRY mode. ...
- Page 12 Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER ON button to Press Temp. up or down button for Point remote to unit and wait initiate the ON time sequence.
-
Page 13: How To Use Advanced Functions
How to Use Advanced Functions FOLLOW ME (some models) °C/°F (some models) Press FOLLOW ME button Press this button will alternate the temperature When the FOLLOW ME function is activated, display between the °C & °F. the remote display is actual temperature at its location. - Page 14 SHORTCUT function(some models) SHORT CUT Used to restore the current settings or resume previous settings.(For some models) Push this button when remote controller is on, the system will automatically revert back to the previous settings including operating mode, setting temperature, fan speed level and sleep feature(if activated).
- Page 15 47 CFR § 2.1077 Compliance Information Unique Identifier: RG51G(1)/CEFU1,RG51G5(1)/CEU1 Responsible Party U.S. Contact Information Element Appliance Company, LLC jay.p@elementelectronics.com FCC Compliance Statement (e.g., products subject to Part 15) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 16 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CR252-RG51G(1)B...
