User's Manual
Monochrome LCD Monitor
It shall be assured that the final system is in compliance
to IEC60601-1-1 requirements.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC-2091 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eizo FC-2091

Summary of Contents for Eizo FC-2091

  • Page 1 User’s Manual Monochrome LCD Monitor It shall be assured that the final system is in compliance to IEC60601-1-1 requirements.
  • Page 2 This is a monitor intended for use in a medical setting. Copyright© 2003 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.

  • Page 3: Table Of Contents

    English TABLE OF CONTENTS PRECAUTIONS ..................4 1. INTRODUCTION ..................9 1-1. Features ......................9 1-2. Package Contents..................9 1-3. Controls & Connectors ................10 2. CABLE CONNECTION ................. 12 2-1. Connecting the signal cable ................12 3. SETTINGS..................... 14 3-1. Using the OSD ....................14 3-2.

  • Page 4: Precautions

    English PRECAUTIONS IMPORTANT! This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below).
  • Page 5 English WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
  • Page 6 English WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock. To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electric shock.
  • Page 7 English WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly.
  • Page 8 English CAUTION Unplug the unit before cleaning it. Cleaning the unit while it is plugged into a power outlet may result in electric shock. If you plan to leave the unit unused for an extended period, disconnect the power cord from the wall socket after turning off the power switch for the safety and the power conservation.

  • Page 9: Introduction

    English 1. INTRODUCTION Thank you very much for choosing an EIZO Monochrome Monitor. 1-1. Features DVI (p.28) Digital input (TMDS (p.28)) compliant Resolution: 3M pixels (1536 dots × 2048 lines) Horizontal scanning frequency: 92.86 ~ 96.72 kHz Vertical scanning frequency: 60 Hz USB (Universal Serial Bus) hub supported.

  • Page 10: Controls & Connectors

    English 1-3. Controls & Connectors Front Control Panel Main Power Switch Power Indicator Yellow Power save mode Flashing yellow Power save mode (2 times for each) Flashing yellow slowly Power is off (Main power is on) Operation mode / Main power off Power Button Brightness Adjustment Buttons ( , ) Contrast Adjustment Buttons ( , )
  • Page 11 This connector is used for specified photo sensor only (p.17). Other peripheral equipment cannot be connected to the connector. This connector is used for the connecting the photo sensor. Please buy EIZO original optional calibration kit (p.26). 1. INTRODUCTION...

  • Page 12: Cable Connection

    English 2. CABLE CONNECTION 2-1. Connecting the signal cable NOTE Be sure that the power switches of both the PC and the monitor are OFF. Please refer to the manual of the PC also to connect the monitor. Pivot the panel in the counter-clockwise to fix in portrait position. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC.
  • Page 13 English NOTE When housing the cables into the cable holder, lead them to the cable entrance side and pinch the projection to open the cable entrance. The cables are recommended to lead with slight sag for the smooth motion of the stand.

  • Page 14: Settings

    English 3. SETTINGS 3-1. Using the OSD The following settings are available by using the OSD function. Adjustment Lock ID setting Displaying the usage time How to use the OSD Adjustment buttons Button for switching the OSD menu Button for entering the KEY DISABLE ON Main power Switch Switch on the...

  • Page 15: Power Save

    English Adjustment Lock (KEY DISABLE) Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Brightness Adjustment Buttons Contrast Adjustment Buttons Unlocked function Power Button ID settings ID number setting from 1 to 4 for the monitor is available. Set the ID numbers when calibrating several monitors at the same time (p.18).

  • Page 16: Panel Protector

    English 4. PANEL PROTECTOR The panel protector is enclosed into the package for the protecting the LCD panel. Please install it as following installation procedure. NOTE Surface of the panel protector shows the dirt (dust or finger prints) easily. Please use the enclosed gloves while installing and removing the panel protector.

  • Page 17: Calibration

    English 5. CALIBRATION The calibration is available when connecting the specified optional calibration kit (p.26). Accessories for calibration kit Photo Sensor × 1 Maintenance cable × 4 Calibration Software Mini DIN 6 pin Maintenance cable Photo Sensor D-Sub 9 pin Plug the maintenance cable into the REMOTE IN (Mini DIN 6 pin) connector of the monitor and the other end of the cable into the serial port (D-Sub 9 pin) of the PC.
  • Page 18 English Calibrating the several monitors A remote control adjustment for the several monitors is available by using the maintenance cable (Maximum 4 monitors). Example (4 monitors) ID=NO.1 ID=NO.3 ID=NO.2 ID=NO.4 Maintenance cable Photo Sensor Plug the maintenance cable into the REMOTE IN (Mini 6 pin) connector of the first monitor and the other end of the cable into the serial port (D-Sub 9 pin) of the PC.

  • Page 19: Making Use Of Usb (Universal Serial Bus)

    English 6. MAKING USE OF USB (Universal Serial Bus) This monitor provides a hub which supports the USB standard. When connecting to a USB compliant PC or another hub, the monitor functions as a hub to which the USB compliant peripherals can be easily connected. Required system environment PC equipped with USB ports or another USB hub connected to the USB compliant PC USB Cable...
  • Page 20 English After setting up, the monitor’s USB hub is available for connecting USB compliant peripherals to the downstream ports of the monitor. Connecting Examples Monitor Mouse Keyboard Printer Downstream ports: Downstream Connect the cables from USB compliant peripherals such as a mouse, keyboard, etc.

  • Page 21: Attaching An Arm Stand

    English 7. ATTACHING AN ARM STAND The LCD monitor can be used with an arm or stand by removing the tilt stand and attaching the arm stand to the LCD monitor. NOTE If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting.

  • Page 22: Troubleshooting

    English 8. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. Problems Points to check with possible solutions Check that the power cord is correctly connected. 1. No picture If the problem persists, turn off the monitor power...
  • Page 23 Check the downstream ports by connecting the do not operate. peripherals to other downstream ports. If the problem is solved by doing this, contact an EIZO dealer. (For details, refer to the manual of the PC.) Try executing the following method.

  • Page 24: Cleaning

    English 9. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or panel.

  • Page 25: Specifications

    English 10. SPECIFICATIONS LCD Panel 53 cm (20.8 inch), TFT Monochrome LCD panel Anti-Glare Hard Coating 2H Viewing Angle Horizontal: 170 , Vertical: 170 Dot Pitch 0.207 mm Horizontal Scan Frequency 92.86 96.72 kHz (Automatic) Vertical Scan Frequency 60 Hz Resolution 3M pixels (1536 dots ×...
  • Page 26 English Optional Calibration Kit EIZO RadiForce Calibration Kit GX1 (Accessories: Photo Sensor × 1, Maintenance cable × 4, Calibration Software) mm (inches) Dimensions 368(14.5) 3.0(0.12) 320(12.6) 3.0(0.12) 83.5(3.29) 60.0(2.36) 100(3.9) 4-M4 22.0(0.87) 326(12.8) 209(8.2) Pin Assignment DVI-D Connector Signal Signal...
  • Page 27 English Remote Out connector (D-Sub 9 pin connector) Pin No. Signal (*NC: No Connection) Remote In connector (Mini DIN 6 pin) Pin No. Signal (*NC: No Connection) Photo sensor connector (Mini DIN 8 pin) Pin No. Signal (*NC: No Connection) USB Ports Signal Signal...

  • Page 28: Glossary

    English 11. GLOSSARY Afterimage The Afterimage is particular to LCD monitors when the monitor screen is left on for a long period without use. The “Afterimage” can be removed gradually by changing the displayed image. (Digital Visual Interface) A digital flat panel interface. DVI can transmit digital data from the PC directly without loss with the signal transition method “TMDS”.
  • Page 29 Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Cord...
  • Page 30 Vous trouvez tous les renseignements pour le sujet de recyclage sur la page WEB de I’UNION DE BRAN CHE SWICO. http://www.eizo.com/cotact/index.html Recycling Information for customers in USA: All recycling information is placed in the EIZO Nanao Technologies, Inc’s website. http://www.eizo.com/contact/index.html Återvinnings information för kunder i Sverige: All information om återvinning finns på Eizo Nordics hemsida:...
