- Page 1 Doc. no. CE*-OMB0075-F PRODUCT NAME Precision MONOSASHI-KUN (High Precision Stroke Reading Cylinder) MODEL / Series / Product Number CEP1* Series...
-
Page 2: Table Of Contents
Contents 1. Safety Instructions ·······································································2~6 2. Product Summary 2-1. System Configuration ································································· 7 2-2. How to Order ············································································ 7 2-2-1. Precision MONOSASHI-KUN ·············································· 7 2-2-2. Applicable Auto-Switch Models ··········································· 7 2-2-3. Options ·········································································· 8 2-3. Precautions on Selection ······················································ 8 3. -
Page 3: Safety Instructions
1.Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 1.Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 design a structure to avoid contact with human Operating and Storage Environments body. ！ 3. Securely tighten all stationary parts and Warning connected parts of cylinders so that they will 1. Envionments to avoid not become loose. Avoid using or storing the products in the Tighten cylinders securely especially when they following environments which may cause failures.
- Page 6 Installation Selection ！ ！ Warning Warning 1. Do not give torque to the piston rod. 1. Confirm the specifications. Giving torque to the piston rod may cause The product in this manual is designed to be damage and malfunction. used only in industrial compressed air system. The product should not be used with pressures or temperatures outside the range of the specifications, as this may cause damage or...
- Page 7 is performed, it should be continued since the Warning ！ initial lubricant flows out causing malfunction. 1. Preparation for wiring Sensor Unit Shut off the power before wiring (including insertion and removal of connectors). Mount a ！ Caution protective cover on the terminal block after wiring.
-
Page 8: Product Summary
2. Product Summary Precision MONOSASHI-KUN is a cylinder that has a built-in linear encoder. The scale of the magnetic rod and magnetic sensor detects change in piston position, and pulse signal is outputted with A/B quadrature pulse (90 ﾟ nominal phase relationship). Position detection in 0.01 mm resolution is possible by inputting this signal to Multi-counter CEU5. -
Page 9: Options
Stroke position is not indicated correctly with 3-Point Preset Counter CEU1. ● For SMC CEP1 series and SMC CEU5 series, operation check was performed with SMC extension cable CE1-R※※ for the maximum wire length of 23m. Since operation check was not performed with other counters and cables, a system designer who selects equipment should check the operation. -
Page 10: Specifications
3. Specifications 3-1 Cylinder Specifications Model CEP1B12 CEP1B20 Action Double acting, single rod (Non-rotating piston rod) Fluid Proof pressure 1.5MPa Max. operating pressure 1.0MPa Min. operating pressure 0.15 MPa 0.1 MPa Operating piston speed 50~300mm/s 0~60゜（No freezing） Ambient & fluid temperature 25~85%RH（No dew condensation）... -
Page 11: Wiring
4. Wiring 4-1 Connector Wiring Table The table below shows combinations of contact mark and wire core color. The connector pin layout shows the layout of CEP1 with connector. 4-2 Wiring for CEU5 CEU5 sensor input part Monosashi-kun series The wiring for CEU5 and MONOSASHI-KUN +12V +12V uses three twisted-pair cables. -
Page 12: Structure And Measuring Principle
5. Structure and Measuring Principle 5-1 Structure Sensor head Rod cover Ellipse piston Boss cut ring Piston rod Scraper Rod packing Gasket Bush Bush Rod packing Through-hole for mounting ・A part of the piston rod has scale (magnetic scale). In order to maintain the relative position of the scale and the sensor head, ellipse piston is used to have a structure of non-rotating cylinder. -
Page 13: Measuring Principle
5-2 Measuring Principle Precision MONOSASHI-KUN is an air cylinder that has a function to output piston stroke movement as pulse signal in 0.01 mm resolution (at four times multiplier). Measuring Principle is as follows. Amplification ① ② Counter & Interpolation Circuit 0.00 0.04... -
Page 14: Troubleshooting
6. Troubleshooting 6-1 Troubleshooting for Measuring Function Page of Failure Cause Countermeasure reference １０ Isn’t the wiring removed, or is it Does not Check the wiring and connector count. correct? loosening. １０ Is 12VDC or 24VDC supplied to Supply rated power the sensor? (12VDC-24VDC) -
Page 15: Troubleshooting For Cylinder Operation
Page of Failure Cause Countermeasure reference ９ Isn’t cylinder speed out of the Measured Cylinder speed should be in the range value does specified range? of 50 mm/s to 300 mm/s. In addition, not have When cylinder speed is too fast, prevent knocking and bounding. - Page 16 Revision history First edition: March 1998 A: Revised in May 1999 B: Revised in July 2011 C: Revised in May 2013 D: Revised in March 2014 E: Revised in March 2023 F: Revised in February 2024 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
