Wren CCK014P4M Product Information

P R O D U C T I N F O R M AT I O N
C A M E R A S O L U T I O N S
STEALTH
CAMERA
The Stealth Camera is a covert color camera with a pinhole lens that allows you
to monitor areas without being detected. The camera's unique design ensures
proper installation in the ceiling tile and secures it against accidental dislocation or
movement. It features the installer-friendly. auto-sensing, dual-voltage circuitry.
This solution is durable and cost-effective and meets the needs of a wide range
of businesses and applications.
CAMER A SPECIFICATIONS
Image Device
Picture Elements
Resolution
Scanning System
Min. Illumination
S/N Ratio
Shutter Speed
Auto Gain Control
White Balance
Backlight Compensation
Video Output
Power Supply
Weight
www.wrensolutions.com
STANDARD RESOLUTION COLOR
1/3" CCD Image sensor
NTSC 512 H x 492 V
330 TVL
2:1 Interlace
1.0 Lux F 2.0
>48 dB
Up to 1/100,000 sec.
Automatic
Automatic
Automatic
1.0Vp-p, 75 Ohm composite
24VAC or 12VDC ±10%
50g
(800) 881-2249
F E AT U R E S
• Dual voltage operation,
12VDC or 24VAC,
auto-sensing
• Professional-grade
• Excellent image quality
• NTSC standard,
PAL option available
