CIDOO ABM618 - Aluminum Mechanical Keyboard Manual

Product Features

1. 60% Anodized Aluminum Mechanical Keyboard
2. Anodized aluminum: Anodized aluminum outer case provides a classy look and feel.
3. Immersion gold PCB: The immersion gold process is anti-oxidation, long life, strong conductivity, and greatly improves the transmission speed.
4. Adopts high-quality stabilizers, all stabilizers were pre-lubed.
5. Dual switch compatibility: PCB has cutouts to support both Plate-mount and PCB-mount switches
6. Fiberglass Plate: Strong and flexible fiberglass resists deformation and provides a unique typing sound profile.
7. Sound insulation: EVA insulation layer in combination with metal base provide a quiet, user experience.
8. Coiled removable USB Cable: Utilizes USB-C for fast data transmission and durability.
9. Built in magnetic 2.4Ghz dongle.
10. Bluetooth 5.0/2.4G/USB-C Tri-use mode: Compatible with Windows, Mac, iOS, and Android operating systems. Utilizes the latest Bluetooth 5.0 technology for lower power consumption and long-range operation. Supports multiple connection profiles to save settings for up to three devices.
11. RGB lighting: Static and animated RGB lighting effects support up to 16.8 million different colors.
12. Come with powerful musical rhythm software.
13. Rechargeable lithium battery: 4000 mA lithium battery for long-lasting battery life.
14. Product dimensions: 305.3*132.8*43mm
15. Product weight: 1598g±10g
16. Product color: Coffee, Dark green, White
17. Current/Voltage: 5V~300mA
18. Executive Standard: GB/T14081-2010

Package Contents

Barebones*1 (Without keycap and switch)
Cable*1
User Manual *1

Toggle wired/Bluetooth/2.4Ghz mode

The keyboard backlight will flash red 3 times indicating that its under wired mode.
The keyboard backlight will flash white 3 times indicating that its under Bluetooth mode.
The keyboard backlight will flash cyan 3 times indicating that its under 2.4Ghz mode.

Bluetooth Pairing Instructions

This Bluetooth keyboard can be paired with up to three devices at the same time. The three pairings are saved to Q (default), W, and E. Quickly switch between pairings by holding down the FN key and pressing Q, W, or E.
Perform the following steps to pair this keyboard with your device(s).

1. Set switch on the back of the keyboard to the ON position.
2. Press and hold the FN and Q / W / E keys for 3-5 seconds. When Q/W/E starts flashing, the keyboard is ready to connect.
3. Open the Bluetooth settings on your device and scan for available devices.
   Locate and select the "ABM648 Mechanical Keyboard" entry.
4. Once the keyboard has connected to your device, the Q/W/E key will cease flashing, indicating that Bluetooth pairing was successful.

2.4Ghz pairing instructions

Switch the keyboard to 2.4Ghz mode. Press+ space key. Space key will flash repeatedly. Plug the USB dongle to USB port (Make sure that keyboard is close to USB port), Space key will cease flashing, indicating that pairing was successful.

Auto sleep mode

After 5 minutes without a keypress the backlighting will turn off to conserve battery.
After 30 minutes, the keyboard will enter standby mode and disconnect from Bluetooth.
Any keypress will reconnect the keyboard.

FN combination keys

Battery Charging

FN key will blink repeatedly when the keyboard is low on battery.

RGB Backlighting and Animations

FN+I = Static, Single-on, Single-off. Rotate, Scroll, Roll
FN+O = Fall, Colorful, Glitter, Ripples, Explode, Launch
FN+P = Breath, Outward, Spectrum, Pulsate, Flow, Tilt

(FN + left Ctrl to switch function mode, "Ctrl" key led will change to white color after pressing FN + left Ctrl)

For software download, pls visit website: WWW.CIDOOO.COM
