Summary of Contents for Ferrari Purosangue 2023

  • Page 2 Important note Some of the information in this pamphlet has been taken from the Owner's Manual supplied with the vehicle. Therefore, any references to chapters refer to the "Owner's Manual" and must be consulted there.

  • Page 4: Table Of Contents

    Electronic alarm ........6 Doors .
  • Page 5 Vehicle intervention...

  • Page 6: Electronic Alarm

    properly and close any door or lid that is open without deactivating the Electronic alarm alarm system. When the luggage compartment is closed properly, it will The electronic alarm system performs the following functions: be included in the perimeter surveillance function. If an attempt is made to lock the vehicle and a compartment is open, it will remain unlocked ●...
  • Page 7 ● the red LED on the dashboard goes out; cycle, together with the message “Break-in attempted”, this means there has been an attempt to break into the car, causing the alarm to activate. ● the ceiling lights come on; ● the central door locking system of the vehicle is deactivated and the When the engine/motors are switched on, the alarm system memory is doors are unlocked.

  • Page 8: Doors

    Doors This is the first 4-door F : the rear doors are rear-hinged and open ERRARI using an innovative "Welcome door" system. This type of opening has been chosen to make it easier to get into the vehicle and easier to use; the rear doors have also been equipped with a fully servo-powered opening and closing mechanism.
  • Page 9 reaches the “upper limit”. If the window is manually lowered by the user To open the vehicle using the rear doors, approach the vehicle and with below the "target" position, it will not be automatically closed when the the key near the door, touch the rear door lever 1: the vehicle is unlocked door is closed.
  • Page 10 If you hold the rear door lever and turn it outwards and hold it down for Important note longer, the lock is released and the door automatically opens completely. It only opens completely when the window is raised; this function is We recommend controlling door movement at all times to ensure deactivated when the window is down.
  • Page 11 Opening the doors from inside Press the button on the inner door panel to release the lock and open the front doors. After pressing the door opening button, the window moves down to its "target position". From this position, when the door is closed, it automatically moves up until it reaches the “upper limit”.
  • Page 12 Rear doors When you press the button to open the rear door, the lock is released and the door automatically opens slightly. Hold the handle and open the door accompanying it as it moves. Important note The door opening/closing assist function is not available if the battery is flat or disconnected.
  • Page 13 From outside the vehicle, press and hold down the door lever turning it Closing the doors outwards: the door closes automatically in a fully closed position. To close the doors, the locks have a Soft Close function which can be used to close the doors by simply accompanying the door with your hand until you hear the first click of the lock;...
  • Page 14 ● if the antipinch system starts to operate, i.e,, you stop the door with your hand; ● if you use the external door lever; ● if you press the button inside the vehicle on the pillar; ● if you press the button on the inner door panel. When the door is not being used and is in an open position, the system keeps the door in this position even if the vehicle is on a slope.
  • Page 15 AUTOMATIC DOOR LO... DOORS UNLOCK DRIVER ONLY UNLOCK BY INTERNAL... SINGLE DOOR POWER DOOR ALERT Child Lock (Child Lock) - Rear doors For the increased safety of children transported on the rear seats, the rear doors have a special door lock system called "Child lock". To activate or deactivate the "Child lock"...
  • Page 16 Emergency opening of the doors from inside Pull the pull ring out. When the pull ring comes out, you can hear a click. Turn the pull ring until the lock is unlocked and the door opens. If the door unlocking system using the button on the inner door panel is After releasing the lock, the lever must be moved back into its original not working properly, the front door locks can be manually released using the pull ring in the panel pocket of each door.

  • Page 17: Reactivating The Fuel Inertia Switch

    ● Put the metal insert into the lock on the bottom of the handle accompanied until it closes to avoid damaging the window which may recess and turn it clockwise to activate the door locking device. collide with the weather strip. ●...
  • Page 18 Important note If a collision occurs and the airbags are deployed, the fuel pump relays cannot be reactivated for safety reasons. If this occurs, contact the ERRARI ERVICE ETWORK Vehicle intervention...

  • Page 19: Disconnecting The Battery

    Disconnecting the battery To cut off the power supply from the battery to the electrical system, use the quick-connect terminal on the LH side of the battery until it is released. Vehicle intervention...

  • Page 20: If The Battery Is Flat

    vehicle software ECUs and may result in error codes, data loss or If the battery is flat inaccurate data. The vehicle is equipped with a maintenance-free sealed 12V battery located in a special compartment in the engine compartment. Warning Warning In the event of a simultaneous failure of both the 12V battery and the alternator, the electronic control unit may implement an emergency Do not place the battery near sources of heat, sparks or naked flames.
  • Page 21 Warning To avoid damaging the conditioner and vehicle, always disconnect the mag netic coupling before starting the vehicle. Important note More detailed technical information and safety instructions relative to the use of the device are given in the specific manual included in the box of the battery conditioner.

  • Page 22: Engine Compartment Lid

    The engine lid lifts up slightly. Accompanying the lid with your hand, lift Warning it until it is fully open. Before starting the engine, wait at least 60 seconds after activating The lid is held open by two shock absorbers. the instrument panel to allow the electronic system that controls the motor-driven valves and the AC ECU to run a self-acquisition process.
  • Page 23 Safe opening and closing of the lid is g uaranteed by a protection system In addition, when the lock is unlocked, the luggage compartment can that can automatically stop any movement when it encounters an be opened from the outside by pressing the button in the centre of the obstacle in its path both when opening and closing.
  • Page 24 The lid is held open by two shock absorbers. The luggage compartment is illuminated by two light units which activate automatically when the luggage compartment lid is opened. Personalising height of luggage compartment opening To avoid problems in limited space, you can set the height at which the luggage compartment opening can be blocked.
  • Page 25 Warning If the key is left inside the luggage compartment, it will reopen automatically. Warning Always check manually that the luggage compartment lid has been closed properly to prevent it from opening while driving. Warning Only open or close the luggage compartment lid when the vehicle is stationary.

  • Page 26: Fuel Filler Flap Emergency Opening Device

    Fuel filler flap emergency opening device To release the closing device and manually open the fuel flap, pull the cable indicated on the RH rear side of the luggage compartment. Vehicle intervention...

  • Page 27: Fuel Filler Neck

    Fuel filler neck Closing the fuel filler flap To close the fuel filler flap, push it until it clicks in place. Warning Refuelling in enclosed areas is not allowed. Always turn off the engine when refuelling. Do not smoke or use naked flames when refuelling. There is a risk of fire.
  • Page 28 If it is necessary to refuel from a portable fuel container, only use the funnel included in the tool kit, which releases the automatic filler neck locking mechanism. Warning If the conditions that allow refuelling are not met or the system that controls the opening of the fuel filler flap is faulty, pop-up messages indicating that refuelling is not available or malfunctioning will be displayed on the instrument panel.
  • Page 29 Vehicle intervention...
  • Page 30 Using the electric parking brake - EPB ....32 Before a trip ......... . 32 Starting the vehicle .
  • Page 31 Starting and driving the vehicle...

  • Page 32: Using The Electric Parking Brake - Epb

    Using the electric parking brake - EPB Warning Using the electric parking brake Always apply the parking brake when the vehicle is parked. The vehicle The parking brake acts on the rear discs using brake callipers operated by should be blocked. If this is not the case, please contact the F ERRARI an electric actuator.

  • Page 33: Starting The Vehicle

    - the seat and steering wheel are in the correct position; If diagnosis detects any errors, they are only displayed once the 5 seconds required for the check have elapsed. The cases listed below are - the external and internal rearview mirrors are in the correct position. an exception and errors are displayed as soon as the key is turned to on, even during diagnosis: Check the following at reg ular intervals and always before long trips:...
  • Page 34 ● after two minutes a pop-up is displayed with the message “Battery voltage in discharge – please turn on the engine” accompanied by an Important note acoustic signal; Hold the brake pedal down while starting the engine. ● two more minutes later, the same pop-up is displayed accompanied once again by an acoustic signal;...

  • Page 35: Starting The Vehicle

    deactivation and door opening command is given on any registered key, With the engine started, the vehicle stationary and the brake pedal the ENGINE START function is reset. pressed, pull the right-hand UP paddle towards the steering wheel and release it to engage 1st gear. If the engine still fails to start after several attempts, check for one of the Release the brake pedal and press the accelerator to start off.

  • Page 36: Using The Gearbox

    Push start DOWN Warning Push starting is not allowed. Using the gearbox Using the gearbox in “Manual” mode To set the gearbox "Manual" mode, pull the central lever of the gearbox selector on the centre console onto M and release it so that it goes back into its initial position: the M on the gearbox selector will turn red.
  • Page 37 In any event, it is advisable to: The DOWN-shift request from the paddle is ignored if gearshifting is already in progress due to engine under-revving. ● shift gears without releasing the accelerator pedal if pressed; Sequential downshifting ● wait until g earshifting has been completed before requesting the next shift, avoiding a rapid sequence of multiple requests.

  • Page 38: Selecting Reverse Gear - R

    When “Automatic” mode is selected, the system automatically shifts “N” (Neutral) request UP and DOWN in relation to vehicle speed, engine speed and the With the engine running, pull both the UP and DOWN paddles towards torque/power requested by the driver. the steering wheel at the same time without pressing the brake pedal to When in “Automatic”...

  • Page 39: Switching Off The Engine And Vehicle System

    letter “P” is displayed on the instrument panel to inform the driver that Important note the Park Lock has been activated. When reverse is selected, an acoustic safety signal beeps intermittently as long as “R” (reverse) is engaged. For information on the Park Lock, see chapter "Park Lock". Switching off the engine and vehicle system Warning Never leave the vehicle with the gearbox in “N”.
  • Page 40 off. If the vehicle remains stationary with the engine running for more than 20 minutes without using the brake or accelerator, a pop-up is displayed on the instrument panel with the message "Turn OFF engine" and a 30 second countdown begins. When the countdown has ended, a loud acoustic signal is emitted.
  • Page 41 Starting and driving the vehicle...
  • Page 42 Dimensions and weights ....... 44 Tool kit and tyre inflation and/or repair kit ... . . 46 Equipment supplied .
  • Page 43 Vehicle recovery...

  • Page 44: Dimensions And Weights

    Dimensions and weights Tables Wheelbase 3018 mm Max. length 4973 mm Max. width 2028 mm Max. width (with rear-view mirrors unfolded) 2182 mm Max. height 1589 mm Max. height with "LIFT PLUS" system activated 1619 mm Front track 1737 mm Rear track 1720 mm Front overhang...
  • Page 45 9 6 9 3 0 1 8 9 8 6 4 9 7 3 1 7 3 7 1 7 2 0 2 1 8 2 2 0 2 8 Vehicle recovery...

  • Page 46: Tool Kit And Tyre Inflation And/Or Repair Kit

    Tool kit and tyre inflation and/or repair kit The tool kit and emergency tyre inflation and repair kit are stored in the luggage compartment. Vehicle recovery...

  • Page 47: Equipment Supplied

    Equipment supplied Warning Before carrying out any maintenance work, technical support and/or inspection work on the vehicle, always make sure that KEY-OFF has been performed correctly. Tool kit Warning Before carrying out any maintenance work, technical support and/or The tool kit contains the following tools needed for emergency repair jobs: inspection work on the vehicle, always make sure that KEY-OFF has been performed correctly.

  • Page 48: In Case Of A Tyre Puncture

    In case of a tyre puncture Useful accessories In addition to the tools supplied with the vehicle, the hazard warning triangle and fluorescent safety jacket should always be kept on board in order to signal hazardous situations in compliance with traffic regulations. Emergency tyre repair and inflation kit Kept in the tool kit in the luggage compartment, it can be used in the event of a puncture or low tyre pressure to repair and/or inflate a tyre...
  • Page 49 Warning Warning Damage to the wheel rim that causes air leaks cannot be repaired. Do If pressure has dropped to below 1.8 bar, stop driving: the kit cannot not remove foreign objects (screws or nails) that have penetrated the guarantee the correct hold because the tyre is too damaged. Contact the tyre.
  • Page 50 be used by asthma sufferers. Do not inhale vapours during use. In the event of an allergic reaction, seek immediate medical advice. Store the STANDARD RUN FLAT bottle in the bag in the luggage compartment away from sources of heat. The liquid sealant has an expiry date: the expiry date is indicated on the kit bottle.

  • Page 51: Replacing A Wheel

    Environment Important note Maintaining correct tyre pressure helps to improve tyre rolling and If the wheel is replaced, use new stud bolts. New stud bolts can be used reduce fuel consumption. on an old wheel. Replacing a wheel Towing Warning Warning The procedure to change a wheel is very delicate and must only be Towing is not allowed.
  • Page 52 ● select the tow hook from the tool kit; Important note ● remove the protective cover cap from the tow hook seat on the left Maximum angles of tow of the tow hook in the two tow levels: 25° and hand side of the bumper;...

  • Page 53: Emergency Release Of The Electric Parking Brake - Epb

    Park Lock emergency release Warning If there is an electrical system failure, release the EPB and Park Lock Warning manually. The Park Lock must only be released using the special tool after checking that the parking brake has been applied and is an operation that must only be carried out by specialised workshop technicians.

  • Page 54: Towing The Vehicle With The Wheel Axle Lifted

    ● remove the protective cover of the device on the bottom of the luggage compartment; ● place the release wrench in the manual release device housing. ● to perform the emergency release, turn the release wrench counterclockwise for a quarter turn. If the electrical system allows it, switch on the instrument panel and check in the gearbox area that the letter “N”...

  • Page 55: Securing The Vehicle To The Trailer

    This procedure is necessary when the vehicle has to be moved with the Warning engine off and when washing the vehicle. Do NOT pull the vehicle onto the trailer using the wheel spokes as anchors to avoid damaging the wheels. Warning When the Park Lock device is electronically deactivated (Carwash procedure), the vehicle may move.

  • Page 56: Technical Support Information And Online Technical

    ERRARI published on the website if in possession of the expertise and tools necessary. Ferrari S.p.A. cannot be held responsible for any procedures carried out incorrectly due to improper usage of the technical information provided.
  • Page 57 Vehicle recovery...
  • Page 58 Edition 1, December 2022 Edited by STAR7 S.p.A. Printed by STAR7 S.p.A. Alessandria - Italia...
