Summary of Contents for Ferrari DAYTONA SP3

  • Page 2 Important note Some of the information in this pamphlet has been taken from the Owner's Manual supplied with the vehicle. Therefore, any references to chapters refer to the "Owner's Manual" and must be consulted there.
  • Page 4 Electronic alarm ........6 Doors .
  • Page 5 Starting the vehicle...
  • Page 6 Electronic alarm The electronic alarm system performs the following functions: ● remote control for central door locking/unlocking; ● perimeter surveillance, detecting if doors and lids are opened; ● seat surveillance; ● vehicle movement surveillance. Activation From outside the vehicle, press button on the key once to activate the alarm system: ●...
  • Page 7 Deactivation From outside the vehicle, press button on the key once to deactivate the alarm system: ● the turn indicators flash twice; ● the system beeps twice; ● the red LED on the dashboard goes out; ● the ceiling lights come on; ●...
  • Page 8 ● Put the metal insert into the lock on the bottom of the handle The installed electronic alarm system complies with EU (European Union) recess and turn it counterclockwise to deactivate the door locking regulations on electromagnetic compatibility and it is marked accordingly. device: the alarm siren will activate.
  • Page 9 Opening the doors from outside Opening of the doors To open the vehicle using the external handle, the vehicle does not The doors open like butterfly's wings moving first outwards and then have to be unlocked: if the handle is used with the key in the driver's upwards.
  • Page 10 opening or closing the door and do not force the door, as this may Warning damage the seals or the window. Always stand on the rear side of the door before opening it, as the If the battery state of charge is below 8V, the system lowers the opening movement of the door itself may cause serious injury or window into the "target position"...
  • Page 11 WAL (Walk Away Locking) function Locking the doors from inside Both doors can be locked by activating/deactivating button on the roof Important note panel. When the door lock is activated, the light on button comes on. To deactivate the door lock, press button until the light goes out.
  • Page 12 Doors and mirrors Automatic door lock Driver only Door unlock Mirror closing by key Welcom in car 23.5 °C 22:38 Opening the doors from inside Press button on the roof panel to deactivate the switching on of the dome lights when the doors are opened and closed at KEY OFF. Press the button shown on the inner door panel to release the lock and open the door lifting it by the handle: the window will move down to its “target position”.
  • Page 13 Emergency opening of the doors from inside Important note If the door unlocking system using the button on the inner door panel is not working properly, the lock can be manually released using the pull Contact the F as soon as possible to correct ERRARI ERVICE ETWORK...
  • Page 14 When the fuel inertia switch is activated, the doors are also unlocked (if locked) and the dome lights come on. Warning The fuel pump relays can be reactivated by pressing the button on the inertia switch A which can be accessed from the flap on the top outer corner of the passenger-side footrest B.
  • Page 15 Disconnecting the battery The battery is located on the driver-side rear side panel. To disconnect the power supply from the battery to the electrical system, remove the cover and use the quick release lever to loosen the clamp on the negative terminal of the battery. Starting the vehicle...
  • Page 16 vehicle software ECUs and may result in error codes, data loss or If the battery is flat inaccurate data. The vehicle is equipped with a maintenance-free sealed 12V battery located in a special compartment in the engine compartment. Warning Warning In the event of a simultaneous failure of both the 12V battery and the alternator, the electronic control unit may implement an emergency Do not place the battery near sources of heat, sparks or naked flames.
  • Page 17 Warning To avoid damaging the conditioner and vehicle, always disconnect the magnetic coupling before starting the vehicle. Important note More detailed technical information and safety instructions relative to the use of the device are given in the specific manual included in the box of the battery conditioner.
  • Page 18 Warning Warning Before starting the engine, wait at least 60 seconds after activating To avoid damage, check there is enough room to open the luggage the instrument panel to allow the electronic system that controls the compartment lid. motor-driven valves and the AC ECU to run a self-acquisition process. During this period, no devices must be activated.
  • Page 19 Closing Emergency Opening Lower the lid until it rests on the lock. If the luggage compartment lid release button on the driver-side door panel does not work, there is a string, as shown in the figure, for manual Then press the lid above the lock until you hear it click in place. emergency opening on the chassis inside the driver side door which can only be accessed when the door is open.
  • Page 20 Closing Lower the engine lid until it rests on the lock. Then press the lid above the lock until you hear it click in place. Warning Before opening or closing the engine lid, make sure there are no persons, animals or objects in the immediate vicinity. Warning Always check manually that the engine compartment lid has been Warning...
  • Page 21 Fuel filler flap emergency opening device To release the closing device and manually open the fuel flap, pull the cable on the LH side of the lid. Starting the vehicle...
  • Page 22 Fuel filler neck Closing the fuel filler flap To close the fuel filler flap, push it until it clicks in place. Warning Refuelling in enclosed areas is not allowed. Always turn off the engine when refuelling. Do not smoke or use naked flames when refuelling. There is a risk of fire.
  • Page 23 If it is necessary to refuel from a portable fuel container, only use the funnel included in the tool kit, which releases the automatic filler neck locking mechanism. Fuel supply Warning Place the nozzle in the filler neck carefully to avoid damaging the device seal.
  • Page 24 EPB - Electric parking brake ......26 Before a trip ......... . 26 Starting the vehicle .
  • Page 25 Moving the vehicle...
  • Page 26 EPB - Electric parking brake brake must be manually activated by pulling lever A. To re-enable automatic activation of the EPB at the next KEY-OFF, press button The parking brake acts on the rear discs using brake callipers operated by again before KEY-OFF;...
  • Page 27 - the doors are closed; Starting the vehicle - the seat and steering wheel are in the correct position; System start-up (KEY-ON) - the external and internal rearview mirrors are in the correct position. When you perform a KEY-ON, the instrument panel and all the on-board controls (steering wheel, dashboard, etc.) are switched on: at the same Check the following at regular intervals and always before long trips: time, a system diagnosis is carried out.
  • Page 28 ● KEY-ON: to activate the vehicle system (instrument panel, air dedicated warning light will appear. For further information, see the conditioning and heating system, infotainment system, etc.), “Maintenance Schedule” in the "Warranty Booklet". press and quickly release the ENGINE START/STOP button on the At each KEY-ON, once the diagnostic cycle is complete, if applicable, a steering wheel without depressing the brake pedal.
  • Page 29 If the key battery has a charge level that is only just sufficient, the vehicle Starting the vehicle informs the driver via a pop-up on the instrument panel with a message Gearbox mode at start-up and recommends replacing the battery as soon as possible. The standard DCT gearbox transmission is “Automatic”.
  • Page 30 Control” is not available. If the gear engaged was R, repeat the above procedure twice to engage 1 gear. This mode is indicated on the gearbox area of the instrument panel by a number or letter corresponding to the selected gear: 1, 2, 3, 4, 5, 6, 7 and N without AUTO.
  • Page 31 In any event, it is advisable to: DOWN ● shift gears without releasing the accelerator pedal if pressed; ● wait until gearshifting has been completed before requesting the next shift, avoiding a rapid sequence of multiple requests. UP-shifting due to overrevving The system automatically engages a higher gear if the accelerator pedal is pressed and the engine approaches the “runaway speed rate”...
  • Page 32 The DOWN-shift request from the paddle is ignored if gearshifting is already in progress due to engine under-revving. Sequential downshifting During deceleration, with the brake pedal pressed and the ABS system disabled, sequential down-shifting can be performed by holding the left- hand “DOWN”...
  • Page 33 In this mode, the system will automatically UP-shift and DOWN-shift Stopping the vehicle according to vehicle speed, engine revs and the torque/power request of When the vehicle stops, the system automatically engages 1st gear unless the driver. Neutral has already been requested. When the vehicle is stationary while To exit “Auto easy exit”...
  • Page 34 Switching off the engine and vehicle system Warning Switching off/stopping the engine Never leave the vehicle with the gearbox in “N”. Always make sure that the letter “P” (Parking) appears in the gearbox area of the Warning instrument panel. If the Park Lock system is not working properly (gearbox locked in “N”...
  • Page 35 Switching off the vehicle system (KEY-OFF) After performing the ENGINE STOP function or KEY-ON, you must performing a KEY-OFF by pressing the ENGINE START/STOP button on the steering wheel to switch off the vehicle system. Warning KEY-OFF is only performed correctly if the engine has been switched off.
  • Page 36 Dimensions and weights ....... 38 Tool bag and tyre inflation and/or repair kit ... 40 Equipment supplied .
  • Page 37 Towing the vehicle...
  • Page 38 Dimensions and weights Wheelbase 2650 mm Max. length 4686 mm Max. width 2050 mm Max. width (with rear-view mirrors unfolded) 2338 mm Max. height 1142 mm Front track 1708 mm Rear track 1664 mm Front overhang 1145 mm Rear overhang 890 mm Front ramp angle 5.8°...
  • Page 39 1 1 4 5 2 6 5 0 8 9 0 4 6 8 6 1 7 0 8 1 6 6 4 2 3 3 8 2 0 5 0 Towing the vehicle...
  • Page 40 Tool bag and tyre inflation and/or repair kit The tool bag and emergency tyre inflation and repair kit are stored in the luggage compartment. Towing the vehicle...
  • Page 41 In addition to these tools, the tool kit also includes a pair of cotton gloves. Equipment supplied Warning Before carrying out any maintenance work, technical support and/or inspection work on the vehicle, always make sure that KEY-OFF has been performed correctly. The equipment supplied with the vehicle is kept in a tool kit in the luggage compartment.
  • Page 42 Warning Warning Repair work using the tool kit requires: Give the instruction booklet supplied with the kit to the personnel that will have to deal with the tyre treated with the tyre repair kit. - suitable protective equipment (e.g. gloves) - suitable precautions to be taken and minimum specific skills when Warning working in contact with electrical parts/components (e.g.
  • Page 43 treated with the tyre repair kit. Drive carefully especially on bends. Warning Avoid sudden accelerations or braking. Keep the kit in its box and out of children’s reach. Warning Do not inhale or swallow the fluid in the bottle and avoid contact with the skin and eyes.
  • Page 44 maximum speed of 80 km/h and drive carefully, especially around bends Warning and when overtaking, avoiding sudden acceleration or braking. Do not exceed the approved weight limits. Do not fit snow chains on the spare The sealant in the kit tank can damage the sensor inside the wheel rim wheel.
  • Page 45 As soon as possible, tighten the stud bolts with the torque wrench to a torque of 120 Nm. Warning The space saver spare wheel does not have a tyre pressure monitoring sensor (see label on spare wheel tool bag). After fitting, it is not checked by the system but complies with international regulations ECE R64/01.
  • Page 46 To prevent damage to the anti-seize coating, never use solvents or other aggressive or abrasive products to clean the conical stud seats on the wheel and on the stud bolt taper and stem. Towing Warning Towing is not allowed. Towing can cause serious damage to the vehicle. Warning Use of the tow hook provided is only allowed in an emergency to load Important note...
  • Page 47 ● take the tow hook out of the tool bag; Warning ● make sure that the area is free of dirt and tightly screw the tow hook into place on the front grille which can be accessed via the special If there is an electrical system failure, perform the manual emergency hole;...
  • Page 48 If the system cannot be released, contact the nearest F To perform the Park Lock emergency release procedure, do the following: ERRARI ERVICE ENTRE ● Take wrench and extension out of the tool bag. ● Join the two parts together and fasten with clip C. If the vehicle needs to be moved but the EPB cannot be disengaged due to a flat battery or a failure in the electrical system controlling the parking brake, the emergency release procedure must be performed by a F...
  • Page 49 ● Open the engine compartment lid. Loading the vehicle onto the trailer ● Insert the wrench/extension into the opening between the central ● Manually release the Park Lock. trim panel and the air filter box in line with the sloped socket and attach the seven-sided end.
  • Page 50 “N”; published on the website if in possession of the expertise and tools ● necessary. Ferrari S.p.A. cannot be held responsible for any procedures turn off the engine; carried out incorrectly due to improper usage of the technical information ●...
