Mechanical Lift base design
Kensington compatible lock design
3.2. Operational Specification
3.2.1 Power supply
Item
Input Voltage range
Input Current range
Power Consumption
DPMS
DPMS
Inrush Current
Earth Leakage Current
Hi-Pot
Power Line Transient
Power cord
Condition
Universal input full range 90~264VAC /47~63Hz
90 ~ 264VAC
Normal "On" operation
DPMS "Sleep" state
DPMS "Off" state
110 VAC
220 VAC
264 VAC/50Hz
1. 1500VAC, 1 sec
2. Ground test: 30A,
1sec
IEC1000-4-4
IEC1000-4-5 (Surge)
- 7 -
No
Yes
Spec
< 1.2 Arms
<
31W
< 2 W
< 1 W
< 30 A (peak)
< 60 A (peak)
< 3.5 mA
Without damage
< 0.1 ohm
1KV
Common: 2KV,
Differential: 1KV
Color: Black
Length: 1800 +/- 50 mm
OK N.A Remark
LED: Blue
LED: Amber
LED: OFF
Cold-start
(on-line test)
(in-lab test)
