2.3 .Compliance Statement

Caution: This Optical Storage Product contains a Laser device. Refer to the product specifications
and your local Laser Safety Compliance Requirements.

2.4. General Descriptions

This Service Manual contains general information. There are 3 levels of service:
Level 1: Cosmetic / Appearance / Alignment Service
Level 2: Circuit Board or Standard Parts Replacement
Level 3: Component Repair to Circuit Boards

3. Product Overview

3.1. Introduction

X193HQ is defined as our new 18.5W model in ACER X series which will be the ACER project in
Qisda. X193HQ is defined as 18.5"W LCD Monitor supports 1366(H) x 768(V) resolution with
DPMS (Display Power Management System) and ACER eColor function. There are triple input
types, D-sub, DVI. X193HQ adopts AUO panel M185XW01 V7. X193HQ has included 1W+1W
speaker. X193HQ also support ACM 8000000:1.(Theoretical value)
The features summary is shown as below,
*All panel spec. in Q201 definition depends on the variance of panel source.
*All spec. of monitor need to warm up at least 1hr.
* To test the "Contrast Ratio" and "Luminance" functions, the color status must be "User preset"
mode.
* 1. "Contrast Ratio": Set "brightness" at 100, and "contrast" at 50.
* 2. "Luminance": Set "brightness" at 100, and "contrast" at 100.
Feature items
Panel supplier & module name
Screen diagonal
Display Format
Pixel Pitch
Viewing Angle (@ Contrast Ratio >= 10)
Analog interface with Scaling supported
Specifications
AUO M185XW01 V7
470.1 mm(18.51")
1366(H) x 768 (V)
0.3(H) x 0.3(V) (TYP.)
R/L:170 degrees (typ)
U/D: 160 degrees (typ)
Yes
- 5 -
Remark
TN, Normally white
409.8 mm(H) x230.4
mm(V)
Panel Display information
per one triad
With 15-pin D-sub
