Framed Cabinetry - Sub-Zero 736TC Specifications

Planning Information
Integrated Model 736TC(I)
F R A M E D C A B I N E T R Y
IMPORTANT NOTE: The depth of each Integrated
unit is 24" (610) from the front of the unit to its
back. Your design may necessitate moving the unit
back, or cabinets forward to achieve a flush fit.
LINE OF INTERFERENCE*
AT MAXIMUM DOOR OPENING
1
(3) MIN.
8
REVEAL
24
(610)
TO BACK
OF UNIT
FLUSH
FURNITURE
FINISH
Door closed – full scale (top view)
Dimensions in parentheses are in
millimeters unless otherwise specified.
SUB-ZERO
105˚ maximum door opening –
MOUNTING BRACKET SCREW
PANEL
3
(19)
4
7
34
APPLIANCE DOOR WIDTH
8 (886)
SUB-ZERO DOOR
LINE OF INTERFERENCE*
SIDE MOLDING AND
INSTALLATION HARDWARE
PROVIDED BY SUB-ZERO
*If the panel is thicker than
utilize the built-in 90˚ door stop to prevent damage to the panel
and face frame.
DOOR
24
T
(610)
TO BACK
LINE OF INTERFERENCE*
OF UNIT
1
/ scale (top view)
4
3
/ " (19), it is recommended that you
4
14
