- Page 1 Original operating manual OPERATING MANUAL ERGONOMIC STACKER S L R S E 0 0 0 8 07/2023 – V01...
- Page 2 © 07-2023. TVH and TotalSource are registered trademarks. TVH Parts NV, Brabantstraat 15, B-8790 Waregem. All rights reserved. No ® ® part of this publication may be reproduced or communicated in any form or by any means, electronic or mechanical, including copying, recording or use in an information storage or retrieval system, without prior and explicit permission of TVH Parts NV.
- Page 3 Bulgarian Можете да намерите това ръководство на Вашия език чрез линка, посочен по – долу. Czech Tento návod najdete ve svém jazyce prostřednictvím odkazu níže. Danish Du kan finde denne vejledning på dit sprog via nedenstående link. German Sie finden diese Bedienungsanleitung in Ihrer Sprache unter folgendem Link. Greek Μπορείτε...
- Page 4 Thank you for using our product. For your safety and to ensure a correct operation, we would like to bring to your attention some aspects of this manual: • This booklet supplies useful instructions for the correct operation and maintenance of the product.
-
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................DESCRIPTION . -
Page 6: Introduction
INTRODUCTION This manual contains all the necessary information on the installation and operation of the semi-electrical ergonomic stacker. Some of the maintenance operations should only be carried out by professional technicians. If you require this information and the maintenance steps, please contact your dealer. Also included in this manual are a number of safety instructions to create a safe working environment. -
Page 7: Description
DESCRIPTION 2.1. Technical data Always check the type plate for the correct information. Model 127TA3160 165TA8072 165TA8071 Edition With platform With 2 booms With 1 boom Load capacity (kg) Lifting height (mm) 1420 1420 1420 Minimum height (mm) 1958 1958... -
Page 8: Main Components Of The Product
2.2. Main components of the product N° Component Handle Operating panel Motor compartment Rear wheels with brake Front wheels Support legs Platform Booms Lifting belt 8/28... -
Page 9: Placement Of The Decals
2.3. Main components of the product The safety and warning labels should be placed as described in the pictures below. See chapter 3 for the explanation of the safety warnings. If the decals are damaged or missing, replace them. N° Decal Explanation Reference... -
Page 10: Type Plate
2.4. Type plate N° Component Type xxxxxx Fork length xxxx mm Type Serial n° xxxxxx Total width xxx mm Serial number Capacity xxxx kg Lifting height Capacity Net weight xx kg Year of manufacturing xxxx Weight Manufactured outside the EU for: TVH PARTS NV Name and address of the Brabantstraat 15 •... -
Page 11: Safety Instructions
SAFETY INSTRUCTIONS 3.1. General safety instructions • Do not use the device to lift or transport people. • Never exceed the maximum allowed weight that is indicated on the type plate or on the ergonomic stacker. • Do not use the ergonomic stacker for any other purposes than those intended. •... -
Page 12: Safety Instructions For The Use Of Batteries
3.2. Safety instructions for the use of batteries • Do not short-circuit the positive and negative terminals of the battery. • Avoid collisions, handle the ergonomic stacker gently, and protect the battery from excessive vibration, external impact or high drops. •... -
Page 13: Transport And Storage
TRANSPORT AND STORAGE 4.1. Parking the ergonomic stacker • Park the ergonomic stacker securely in a dry and frost-free environment. • Do not park on an inclined surface. • Always completely lower the platform. • If the parking duration is less than a month, fully charge the battery. If the parking duration is over one month, the battery needs to be charged once a month (See chapter 6). -
Page 14: Transporting The Stacker
4.2. Transporting the stacker • Make sure the ropes, cables, hooks, etc. are suitable for the weight of the ergonomic stacker. • Always transport the ergonomic stacker in its lowest position. • Apply the brake during transport. Safely transport the ergonomic stacker by following these steps: 1. -
Page 15: Assembly And Installation
ASSEMBLY AND INSTALLATION 5.1. Packing list Description Amount Reference Stacker complete with platform* 127TA3160 Stacker complete with 1 boom* 165TA8071 Stacker complete with 2 booms* 165TA8072 Operating manual 168TA3985 Spare parts list Please contact your dealer External charger 168TA2688 * Only one reference applies. -
Page 16: Operation
OPERATION 6.1. Safety instructions for operating the product • A damaged or malfunctioning machine must never be used. If damage or malfunctions are discovered during pre-operation inspection or function tests, the machine must be tagged and removed from service. • The operator must wear safety shoes and safety gloves when using or maintaining the ergonomic stacker. -
Page 17: Operating Instructions
6.2. Operating instructions Please see chapter 7 for the daily maintenance schedule. Operating panel N° Down Input charger ON / OFF Loading and unloading the stacker: 1. Position and level the stacker as close as possible to the goods you wish to transport or lift. 2. - Page 18 Foot brake The ergonomic stacker is equipped with a foot brake on the rear wheels. When applied, the foot brake prevents the ergonomic stacker from moving. To apply the brake, push the brake down with your feet. To release the brake, pull the brake up. Always use the foot brakes when loading and unloading the ergonomic stacker.
-
Page 19: Maintenance
MAINTENANCE 7.1. Safety instructions for the maintenance of the product • No modifications or alterations that may affect the capacity, stability or safety requirements of the ergonomic stacker, but not limited to these examples, shall be made without the prior written approval of the original manufacturer, its authorised representative, or a successor thereof. - Page 20 3. Cleaning Do not use a high-pressure cleaner to clean the ergonomic stacker. The environment in which the ergonomic stacker is used, determines the cleaning frequency. It is recommended to assess the need for cleaning based on the applicable rules in the company.
-
Page 21: Troubleshooting
TROUBLESHOOTING N° Problem Cause Action The platform or the booms Switch is in the ‘off’ position. Turn the stacker on. can’t be raised (up to the maximum height). Battery charge too low. Check battery charge, check battery if necessary. The platform or the booms Stacker in charge mode. -
Page 22: Temporarily Out Of Order
TEMPORARILY OUT OF ORDER 9.1. Decommissioning the ergonomic stacker If the ergonomic stacker is to be out of operation for more than 2 months, it must be parked in a frost-free and dry location and all necessary measures as described must be taken before, during and after decommissioning. -
Page 23: Final Decommissioning And Disposal
FINAL DECOMMISSIONING AND DISPOSAL Final, proper decommissioning or disposal of the product must be performed in accordance with the regulations of the country in which the product is used. In particular, regulations governing the disposal of batteries, fuels and electronic and electrical systems must be observed. -
Page 24: Annexes
