  • Page 1 Multi-play equipment BBPE160.2RR...
  • Page 2 0,00 m 0,07 m 0,95 m * 0,47 m 0,87 m 1,41 m 1,82 m 0,95 m 0,15 m 0,00 m * Vloerhoogte (Floor height) Benaming TOE BBP 160 2RR Klimklauter, 1 toren Title Tekening Opmerking Boer Basic play Drawing Comment Datum Hoofdafmetingen Main dimensions...
  • Page 3 4,43 m Opvangzone Impact area Obstakelvrije zone Obstacle free zone Benaming TOE BBP 160 2RR Klimklauter, 1 toren Title Tekening Opmerking Boer Basic play Drawing Comment Datum Obstakelvrije zone Obstacle free zone 4-12-2019 Date...
  • Page 4 1,57 m 1,59 m 1,47 m 0,80 m 0,40 m 0,25 m 0,50 m Grondmarkering Ground level marker 0,59 m 0,50 m Benaming TOE BBP 160 2RR Klimklauter, 1 toren Title Tekening Opmerking Boer Basic play Drawing Comment Datum Bodemplan Groundplan 4-12-2019 Date...
  • Page 5 Geleverde modules: Supplied modules: Zie tabel See table Montageinstructie: Assembly instruction: - De hoofdmaten geven de maten van de staanders en vloeren aan - The main dimensions indicate the dimensions of the posts and floors - De detailtekeningen geven specifiek de maten van de verbindingen aan - The detailed dimensions show the specific dimensions of the connections - The modules which contain tubes are dimensioned at the top of the flanges - De modules met buizen zijn op de tekeningen bemaat op bovenkant kopplaat...
  • Page 6 1,82 m 1,74 m 1,70 m 0,00 m Voor (Front) 1,82 m 1,70 m 0,95 m 0,00 m Rechts (Right) Benaming TOE BBP 160 2RR Klimklauter, 1 toren Title Tekening Opmerking Boer Basic play Drawing Comment Datum Afmetingen Dimensions 4-12-2019 Date...
  • Page 7 1,82 m 1,74 m 1,70 m 0,95 m 0,00 m Achter (Back) 1,82 m 1,70 m 0,95 m 0,00 m Links (Left) Benaming TOE BBP 160 2RR Klimklauter, 1 toren Title Tekening Opmerking Boer Basic play Drawing Comment Datum Afmetingen Dimensions 4-12-2019 Date...
  • Page 8 LOGBOOK Type indication Basic Play Article number BBPE160.2RR Product Name Multi-play equipment Maximum fall height 1,0 m Construction year 2023 Certificate 142791 Inspection body Keurmerkinstituut Groeneweg 2e, Zoetermeer 2718AA Zoetermeer Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk...

  • Page 9: Inspection And Maintenance

    LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...

  • Page 10: Inspection And Maintenance Intervals

    Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear.
  • Page 11 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
  • Page 13 Type Progr. Bew. Rev. Benaming Volgnr Opmerking Klinknagel bolkop 4,8 x 18 - RVS A2-70 Staander 2,3m 0,95m vloer Voetplaat 100 x 100 Benaming MOD BBP 001 R Staander 0,95m Title Tekening Opmerking Boer Basics Drawing Comment Datum Samenstelling module Assembly module 9-3-2018 Date...
  • Page 14 Type Progr. Volgnr. Bew. Rev. Benaming Opmerking SLUITRING Borgmoer M10 - RVS A2-70 Zeskantbout M10 x 190 - VZ 8.8 Beschermdop M10-M12 Donut wit Dop wit Beschermdop M10-M12 VLOER BOER BASIC PLAY Schroef Assy 6 x 120 - RVS A2-70 Schroef Assy 5 x 50 - RVS A2-70 Vloerplaat...
  • Page 15 Grondmarkering Ground level marker Let op: toestel bij voorkeur niet met de glijbaan op het zuiden plaatsen. Type Progr. Volgnr Bew. Rev. Benaming Opmerking DOPMOER BORG RVS M10 Attention: it is advisable not to oriënt Slotbout M10 x 110 - RVS A2-70 playground equipment with the slide Slotbout M10 x 40 - RVS A2-70...
  • Page 16 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBP 009 x © Copyright BOERplay 22-2-2022 Revision: A...
  • Page 17 Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois 18 mm 50 mm BSR.014.005.052 BSR.002.005.050 KST.ROR.006.000 ø5mm ø3mm x 30 BSR.002.005.050 BSR.014.005.052 KST.ROR.006.000 MOD BBP 009 x © Copyright BOERplay 22-2-2022 Revision: A...
  • Page 18 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBP 016 x © Copyright BOERplay 24-2-2022 Revision:...
  • Page 19 Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 BSR.002.005.070 BSR.014.005.053 KST.ROR.006.000 MOD BBP 016 x © Copyright BOERplay 24-2-2022 Revision:...
  • Page 20 Type Progr. Volgnr Bew. Rev. Benaming Opmerking Blindklinknagel bolkop 4.8 X 30 - Huls ALU, trekpen staal Schroef Assy 5 x 50 - RVS A2-70 Borgdopmoer M10 - RVS A2-70 SLOTBOUT M10 x 90 M10 x 40 - RVS A2-70 Slotbout SLUITRING Hoekje rood...
  • Page 21 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBP 046 x © Copyright BOERplay 24-2-2022 Revision:...
  • Page 22 Poteaux en plastique ou en bois OME.KAP.100.xxx xxx: 204 Orange RAL2004 Oranje / Orange / Naranja / Orange xxx: 524 Light blue RAL5024 Licht blauw, Hellblau, Azul claro, Bleu clair BSR.002.005.050 OME.KAP.100.xxx MOD BBP 046 x © Copyright BOERplay 24-2-2022 Revision:...
