Stack-On SECURITY PLUS Instructions Manual

IMPORTANT
Record the serial number from the tag located on the lower right corner
of the door front or from the tag located under the lock cover plate.
Record your combination number.
Keep keys and combination in a secure place away from children.
Do not store your keys or combination inside the safe.
OPENING THE SAFE WITH THE KEY
You will need to use the key to open the safe the first time in order to install the batteries. At a later time you may need to open the safe with
the key if your batteries run down or if you forget your combination.
Remove the lock cover plate from the front of the control panel. Insert the key and turn counterclockwise. Turn the knob clockwise and open
the door.
BATTERY INSTALLATION
When you open the safe door for the first time you will need to install the batteries.
This safe uses 4 - 1.5V,AA alkaline batteries (included). The battery compartment is located on the back of the door. Remove the cover
and install all new batteries. NOTE: You must reprogram your combination after you change batteries.
Under normal use, batteries will last about 1 year. When the batteries are low, the red light will come on warning you that the batteries are
low. To test the batteries, enter your security code. If the batteries are low the red light will start to flash.
PROGRAMMING YOUR OWN COMBINATION
With the door open and the batteries installed you can now program your own combination. For security, you must reprogram your safe
changing the preset factory code (1 - 5 - 9 - # ). Write your new combination on this form and keep this form and the emergency back up
key in a place separate from your safe. Do not close the door until you have confirmed your new combination has been entered correctly.
1. Press the red button on the hinge side of the door. You will hear a beep and the yellow light will go on. You will have 20 seconds to
enter your own combination
2. Enter your own (3 to 8) digit combination then press the " # " key to enter your new combination. The yellow light will go out and
your personal combination has been entered.
3. Before closing the door try your new combination. Enter your combination followed by the " # " key. When the green light goes on
turn the knob clockwise to retract the locking bolts. If this fails repeat steps 1-3 again.
SECURITY NOTE: If the combination is entered incorrectly 3 consecutive times the keypad will lockout for 20 seconds. If the incorrect
combination is entered an additional 3 times the keypad will lockout for 5 minutes before you can try the combination again.
TURNING THE KEYPAD SOUND OFF/ON
You can turn off the "Beep" sound of the keypad by entering the code
To turn the "Beep" sound on, enter the code
ACCESSORIES
Use the adhesive backed straps to secure pistols to the back of the safe. The tags can be used
to organize keys. The file folder is great for storing documents.
MAINTENANCE
If the door starts to rub on the frame use an Allen Wrench to adjust the threaded stem on the
door hinges in order to center the door.
SELECTING A LOCATION
For best results install your safe in an isolated, dry and secure area.
INSTALLING THE SAFE
Figure 1 shows the installation of the safe in a wood framed wall (16" centers) covered with wall board.
Your situation may vary from this but in general the safe should be attached to the internal structure of a
wall with the frame of the safe flush to the wall surface.
In the figure shown, mount the safe between two wall studs. Cut a hole in the wall the same size as the
back of the safe. Use filler blocks and a bottom support as required. Mount the safe to the studs from the
inside as shown.
IMPORTANT
Keep your combination number and keys in a secure place, away from children. Keep this record of your serial number, combination number
and key number in a secure place separate from your safe. You will need the serial number as a reference for obtaining replacement keys.
To order a replacement key set, follow the instructions on the attached form.
STACK-ON PRODUCTS CO., P.O. BOX 489, WAUCONDA, IL 60084
R
Instructions
Serial No:
Your Combination:
633.
66.
®
Home Security Safe
16"
Filler block
Bottom
support
1
40031-0708
1 9
