2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.

5. Before starting the equipment

Warning!
Always remove the battery pack before making
adjustments to the equipment.
5.1 Safety guard (Fig. 2/Item 15)
•
The safety guard (15) protects the user from
accidentally touching the saw blade (12) but
still gives you an unobstructed view of the
cutting area.
•
The safety guard (15) must always be fitted
and in position before starting any sawing
work.
•
The safety guard (15) can removed by pulling
to the front as shown in Fig. 2.
5.2 Changing the saw blade (Fig. 3/Item 12)
Warning!
Remove the battery pack before you fi t or re-
place a saw blade.
•
You can fit or replace saw blades without
using any other tools.
•
Set the selector switch for pendulum action
(8) to position 0.
•
The teeth of the saw blade are very sharp!
•
Remove the safety guard (15).
•
Press the blade holder (14) and insert the
saw blade (12) into the blade holder (14) as
far as the stop (Fig. 3). The teeth on the saw
blade must be pointing forwards.
•
Allow the saw blade holder (14) to slide back
into position. The saw blade (12) must sit in
the guide roller (10).
•
Check that the saw blade (12) is securely
mounted in the blade holder.
•
To remove the saw blade, follow the instruc-
tions above in reverse order.
5.3 Installing the parallel stop (Fig. 4/Item 11)
•
The parallel stop (11) enables you to saw
parallel cuts.
•
Undo the two locking screws for the parallel
stop (13) on the soleplate (7).
•
Now slide the parallel stop (11) into the
guides on the soleplate (7). You can fit the
parallel stop (11) on either the left or right of
Anl_TC-JS_18-2700_Li_Globus_SPK7.indb 19 Anl_TC-JS_18-2700_Li_Globus_SPK7.indb 19
GB
the equipment.
•
The guide strip must always face downwards.
Set the required distance using the measu-
rement scale on the parallel stop (11) and
tighten the locking screws for the parallel stop
(13) again.
Important!
The read-off point for the measurement scale is at
point (a) or (b), as shown in Fig. 4, depending on
which side the parallel stop is inserted from.
The mark in the center of the soleplate is only pro-
vided for cutting along a line and not for reading
the measurement scale.
5.4 Setting the soleplate for miter cuts
(Fig. 5 and 6)
•
For miter cuts you must remove the locking
screw for the parallel stop (13) as well as the
splinter guard (17).
•
Take off the safety guard (15).
•
Slacken the socket head screws (A) using the
supplied hex key (16).
•
Push the sole plate (7) to the back slightly.
The soleplate can now be swiveled by up to
45° to the left or to the right.
•
Pushing the soleplate to the front again works
only in the locking positions at 0°, 15°, 30°
and 45°, which are marked on the graduated
scale for the soleplate (9). Move the soleplate
into the required position and tighten the so-
cket head screws (A).
•
Setting the soleplate (7) to another angle is
possible directly however. To do so, push the
soleplate (7) to the back, set the required
angle and retighten the socket head screw
(A).
Important! For miter cuts you must remove the
locking screws for the parallel stop (13) and the
splinter guard (17).
5.5 Adapter for dust extraction system
(Fig. 1/Item 5)
•
Connect your cordless jigsaw to a vacuum
cleaner using the adapter for chip extraction
(5). This will ensure optimum chip extraction
from the workpiece. The benefits are that you
will protect both the equipment and your own
health. Your work area will also be cleaner
and safer.
•
Dust created when working may be dange-
rous. Refer to the section entitled "Safety
information".
•
The dust extraction adapter (5) is fixed to the
tool and cannot be removed.
