Winbook SI User Manual

Winbook si: user guide
Hide thumbs Also See for SI:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
1. General Information ....................................................................................3
2. Safety Precautions .......................................................................................5
3. Features ......................................................................................................7
4. Dimensions .................................................................................................8
5. Ports ...........................................................................................................9
6. Control Buttons .........................................................................................11
7. Accessories ...............................................................................................12
8. Remote Control .........................................................................................13
9. Summary of Remote Control Functions .................................................................14
Adjustment ............................................................................................15
Turning the LCD TV On and Off ................................................................15
Viewing the Menus and On-Screen Displays .................................................15
Switching Language Modes ........................................................................16
Setting the Sleep Timer ..............................................................................17
Auto Power Off ......................................................................................17
How to enter Menu Items .......................................................................18
Adjusting the Volume ..................................................................................18
B. PC mode Adjustment ..............................................................................19
Adjusting Contrast and Brightness Settings .................................................19
Adjusting Picture Settings ......................................................................20
Adjusting Image Settings .......................................................................21
Adjusting Audio Settings .......................................................................23
Viewing Picture-in-Picture (PIP) ..................................................................26
C. TV mode Adjustment ...............................................................................28
Adjusting the TV Settings ........................................................................28
Sound Options .........................................................................................29
Adjusting the Picture Settings ..................................................................30
Memorizing Channels ..............................................................................31
Changing Channels ..................................................................................35
Using Parental Controls .........................................................................35
Setting Up Your Personal ID Number (PIN) ...............................................36

Table of contents

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winbook SI

Summary of Contents for Winbook SI

  • Page 1: Table Of Contents

    Table of contents 1. General Information ...3 2. Safety Precautions ...5 3. Features ...7 4. Dimensions ...8 5. Ports ...9 6. Control Buttons ...11 7. Accessories ...12 8. Remote Control ...13 9. Summary of Remote Control Functions ...14 10. Controls & Adjustment A.
  • Page 2 Viewing Closed Captions ...42 D. Other functions ...43 11. Troubleshooting ...45 12. Specifications ...49...

  • Page 3: General Information

    General Information This 27” and 30” wide active matrix TFT (thin film transistor) liquid crystal display is designed for use as a stand alone TV as well as a display device for video electronics appliances and personal computers. CAUTION Important Information R i s k o f e l e c t r i c s h o c k .
  • Page 4 WARNING: Do not leave stationary images, patterns, PIP windows, or letterbox images on the screen for prolonged periods of time as this may result in permanent damage to the LCD panel. This type of damage is not covered under warranty. The following are examples of, but not limited to, potentially hazardous display output: side bar images, video game patterns, closed captioning, channel logos and letterbox black bars.

  • Page 5: Safety Precautions

    Safety Precautions 1. Cleaning: Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. 2. Water and moisture: Do not use the product near water or areas of high moisture content such as swimming pools, bathtubs or wet basements.
  • Page 6 6. Stand: Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product.

  • Page 7: Features

    Features List of Features Your TV is designed with the latest technology and is a high-performance display device that includes the following features: • Multiple input sources including antenna terminal, D-sub (15pin VGA), composite, S-Video and component ports. • Easy-to-use remote control and on-screen-display (OSD) menu system. •...

  • Page 8: Dimensions

    Dimensions Unit: mm...

  • Page 9: Ports

    Ports Video Input device DVD player Satellite receiver Set top box VIDEO Input device Digital Camera Satellite receiver Set top box...

  • Page 11: Control Buttons

    Control Buttons These buttons control your TV’s basic features, including the on-screen menu. To use advanced features you must use the remote control. P O W E R : turn the LCD TV on or off. set up the input source ( PC, AV, SV, TV, CV ). S O U R C E : M E N U : display the main menu.

  • Page 12: Accessories

    Accessories...

  • Page 13: Remote Control

    Remote Control...

  • Page 14: Summary Of Remote Control Functions

    Power Control POWER button Selecting the primary signal source TV button AV button SV button CV button PC button Menu Settings MENU/ENTER button TITLE/EXIT button Changing Channels UP button DOWN button 0~9 ; +100 button RETURN button Sound Control VOL+ button VOL- button MUTE button MTS button...

  • Page 15: Controls & Adjustment

    Controls & Adjustment A. General Adjustment Turning the LCD TV On and Off Plug the power cable into the socket located on the right rear of the LCD TV. Press the button on the Remote Control or use the Power button located within P O W E R the control buttons panel found on top of the TV.

  • Page 16: Switching Pc/Composite/S-Video/Tv/Component Modes

    Switching PC/Composite/S-Video/TV/Component Modes 1. Turn on the power. 2. Select an input source as described below: Power button to switch to TV mode. button to switch to PC mode (VGA). button to switch to Composite mode. button to switch to S-Video mode. button to switch to Component mode (Y, Pb/Cb, Pr/Cr).

  • Page 17: Setting The Sleep Timer

    Setting the Sleep Timer You can set the Sleep Timer to automatically turn off the LCD TV. 1. Press the Timer screen. 2. Toggle the ( i n 30 minute i n t e r v a l s ) . 30 min | 60 min | 90 min | OFF Note: The Sleep Timer screen automatically disappears in 3...

  • Page 18: How To Enter Menu Items

    How to enter Menu Items 1. Press the button to display the main MENU menu screen. NTSC 31.2 kHz V 50.2 Hz 2. Press the button to toggle VOL (+) VOL (-) through the menu options. Then press the button to access sub-menu items. 3.

  • Page 19: Pc Mode Adjustment

    Adjusting the Contrast & Brightness Settings Each viewing mode supports separate adjustments for brightness and contrast levels. PC mode is best viewed with lower brightness and contrast levels as compared to other modes. 1. Press the 2. Press the cursor to the Picture Adjust menu. 3.

  • Page 20: Adjusting Picture Settings

    5. Press the button to return to the previous EXIT screen or exit. Adjusting Picture Settings 1. Press the button to display the main menu. M E N U 2. Press the VOL (+) VOL (-) cursor to the Picture Adjust menu. Cool Neut.

  • Page 21: Adjusting Image Settings

    5.1 If selecting User, press the E NT E R enter the User Color Adjust sub-menu. 5.2 Press the button to access the the DOWN desired color option (R, G, B) 5.3 Press the button to set the VOL (+) VOL ( -) color level.
  • Page 22 3. Press the button to access the sub-menu. E NT E R 4. Press the button to access the D OW N desired item. 5. Press the button to set the desired VOL (+) VOL (-) item. H Position V Position Cloc 6.

  • Page 23: Adjusting Audio Settings

    Adjusting Audio Settings 1. Press the button to display the main menu. M E N U NTSC 31.2 kHz 2. Press the button to move the VOL(+) VOL(-) cursor to the Audio Adjust menu. JAZZ Classic User There are 6 equalizer modes as shown below: 50.2 Hz ROCK Normal...
  • Page 24 3. Personal equalizer preferences can be adjusted via the User and Normal modes. Press the button to enter the Audio E NT E R Adjust menu. Press the DOWN access the Equalizer sub-menu. Press the VOL (-) (b) Press the button to enter User or Normal E NT E R mode, then press the...
  • Page 25 Main 4. Press the button to return to the previous E X I T screen or exit.

  • Page 26: Viewing Picture-In-Picture (Pip)

    Viewing Picture-in-Picture ( PIP) PIP: While viewing content on the main display, you have the option to select a secondary signal as a sub-display in a picture in picture window. This feature allows you to watch two video sources simultaneously. Activating Picture-in-Picture 1.
  • Page 27 4. Press the button to access the PIP sub-menu. E N T E R 5. Press the button to select the desired DOWN PIP function. 6. Press the button to set the desired VOL (+) VOL (-) PIP function. Sharpness 7.

  • Page 28: Tv Mode Adjustment

    C. TV Mode Adjustment Adjusting the TV settings 3. Press the button to display the main menu. MENU 4. Press the button to enter the Management ENTER menu, then press the DOWN Main Display (TV) sub-menu. NTSC 31.2 kHz 1. Press the button to select the VOL (+) VOL (-)

  • Page 29: Sound Options

    Press the button to select the desired D OW N item. Press the button to set the desired VOL (+) VOL (-) item. Press the button to return to the previous screen E X I T or exit from the Menu. Sound Options Choosing a Multi-Channel Sound (MTS) Soundtrack...

  • Page 30: Adjusting The Picture Settings

    Adjusting Picture Settings 1. Press the button to display the main menu. MENU 2. Press the button to enter the Management ENTER menu. Press the DOWN Main Display (TV) sub-menu. PC AV SV CV 3. Press the button to select the VOL (+) VOL (-) desired Main Display source.

  • Page 31: Memorizing Channels

    Saturation 7. Press the Memorizing Channels Your TV can memorize and store all of the available channels for both standard broadcast (antenna) and cable channels. After the available channels are memorized, press the button to view stored channels. You can also view any channel D O W N (even non-memorized) by directly entering the channel digits via the remote control.
  • Page 32 3. Press the TV source. Press the previous screen. 4. Press the Setting menu. Note: 1. ANT is Over The Air (OTA) broadcast television that is public domain or free for viewing. 2. STD, IRC and HRC T/CATV are all formats of cable o Scan TV.
  • Page 33 Memorizing Channels (Automatic Method) First, select the correct signal source as described in the previous step. Then perform the following actions: 1. Press the button to display the main menu. ME NU 2. Press the button to select the VOL (+) VOL (-) TV Setting menu item.
  • Page 34 Adding and Erasing Channels (Manual Method) 1. Press the button to display the main menu. MENU 2. Press the button to select the TV VOL (+) VOL (-) Setting menu. 3. Press the button to access the TV Setting. ENTER 4.

  • Page 35: Changing Channels

    Changing the Channel This LCD TV tuner provides the ability to display up to 125 channels (1 to 125). To select a channel, enter the channel number using 1 to 3 digit numbers. NUMBER BUTTONS Press the R E T U R N When you press the changes channel in sequence.

  • Page 36: Setting Up Your Personal Id Number (Pin)

    Setting Up Your Personal ID Number (PIN) 1. Press the button to display the main menu. M E N U 2. Press the button to select the TV Setting menu. V O L ( + ) V O L ( - ) 3.
  • Page 37 7. Press to access the Please Enter New Pin: ENTER screen. Enter any 4 digit sequence for your new PIN. VOL(-) VOL(+) Change Pin OK!! MENU/ENTER As soon as the 4 digits are entered, the “Change Pin TITLE/EXIT screen appears. Your new PIN has been OK!!”...

  • Page 38: How To Set Up Restrictions Using The "Tv Rating

    6. Press the then press the and ”MPAA” controls will lock out the channels that your specify. If you want to disable the Parent Control Function, select Off on “Parent Control". Any blocked programs will immediately become viewable. How to Set up Restrictions Using the “TV Rating” Set up a personal identification number (PIN), then enable the Parent Control option.
  • Page 39 TV-Y Young children TV-Y7 Children 7 and over General audience TV-G TV-PG Parental guidance Viewers 14 and over TV-14 TV-MA Mature audience 7. The “TV Rating” screen will appear. Press the Press the 8. Press the TV level of restriction. Press select a category of restriction.

  • Page 40: How To Set Up Restrictions Using The "Mpaa

    How to set up Restrictions using the “MPAA” The MPAA ratings system for parental controls uses the Motion Picture Association of America (MPAA) ratings system for movies. When the parental controls are enabled, the TV will automatically block any programs that are coded with MPAA ratings codes that you deem objectionable.
  • Page 41 7. Press the particular MPAA rating. Press the button to select either "B" or "U". Press the (B: Block; U: Unblock) : General audience (no restrictions). : Parental guidance suggested. PG13 : Parents strongly cautioned. : Restricted. Children under 17 should be accompanied by an adult.

  • Page 42: Viewing Closed Captions

    Viewing Closed Captions This LCD TV has the ability to decode and display closed caption content if supported by the program. These captions are usually used for the hearing impaired or for foreign language translations. Most VCR's can record the closed caption signal from television programs.

  • Page 43: Other Functions

    D. Other Functions UP/DOWN: Under TV mode, keys are for changing channels. UP/DOWN UP/DOWN VOL (+) VOL (-): Under any display mode, “VOL (+) When entering the OSD, the “VOL (+) or VOL (-)” menu options. When entering sub-menu items, the are for adjusting functions.
  • Page 44 (Multi-Television-Sound): M T S There are three supported MTS modes: “Mono”, “Stereo” or “SAP” (Secondary Audio Program) This LCD TV has the ability to decode stereo or SAP broadcasts. R E S E T : Under PC mode, the reset button restores the following settings to factory values: (Brightness, Contrast, Color, Temp, Volume, Treble, Bass, and Balance) Under Video mode, the reset button restores the following settings to factory values: (Brightness, Contrast, Hue, Saturation, Sharpness, Volume, Treble, Bass, and Balance)

  • Page 45: Troubleshooting

    Troubleshooting There is no picture or sound. Make sure the AC adapter is properly inserted into the power outlet. Verify that there is a valid source signal Make sure the input mode is set to TV. Make sure the TV is powered on. There is no picture in AV mode.
  • Page 46 Picture is light or improperly tinted. Check the Hue, Saturation and Color adjustments. Reset the TV to the factory default settings. Select a different APC mode. Check the Picture and Brightness adjustments. The fluorescent lamp may have reached the end of its life.
  • Page 47 The picture is not sharp. The source signal may be weak. Your provider may be experiencing difficulties. Check your input connections. The picture moves. The source signal may be weak. Your provider may be experiencing difficulties. Check your input connections. The picture is doubled or tripled.
  • Page 48 There may be interference from other appliances. There may be interference between the video source cable and the power cable. Make sure the power and video cables are not touching. Check the Hue, Saturation and Color adjustments. Note: If an issue cannot be immediately resolved, unplug the power cord for 8~10 seconds. Then check again to see if the TV is operating normally.

  • Page 49: Specifications

    Specifications 27” LCD TV Spec For USA ITEMS Screen Size Aspect Ratio Resolution Display Area (opening) H x V Pixel Pitch Panel Display colors Contrast Ratio Brightness Viewing Angle Response Time TV standard TV Tuning System TV Function STEREO CATV Composite Signal Video Input...
  • Page 50 30” LCD TV Spec For USA ITEMS Screen Size Aspect Ratio Resolution Display Area (opening) H x V Pixel Pitch Panel Display colors Contrast Ratio Brightness Viewing Angle Response Time TV standard TV Tuning System TV Function STEREO CATV Composite Signal Video Input Y, C...
