Winbook LC32D User Manual

Winbook lc32d: user guide

User manual (77 pages)

Table of Contents

Quick Links

Download this manual

V32FCBB-U21/M21

1. General Information .........................................................................................................

2. Safety Precautions .............................................................................................................

3. Features ..............................................................................................................................

5. Dimensions .........................................................................................................................

6. Ports....................................................................................................................................

7. Control Buttons ................................................................................................................. 11

8. Accessories ......................................................................................................................... 12

9. Remote Control ................................................................................................................. 13

10. Summary of Remote Control Functions ......................................................................... 14

11. Controls & Adjustments

A. General Adjustments......................................................................................................... 15

Turning the LCD TV On and Off ..................................................................................... 15

Viewing the Menus and On-Screen Displays ................................................................... 15

Switching between PC/Composite/S-Video/TV/Component Modes ............................... 16

Switching Language Modes.............................................................................................. 16

Setting the Sleep Timer..................................................................................................... 17

Auto Power Off................................................................................................................. 17

Adjusting the Volume....................................................................................................... 17

B. PC mode Adjustments....................................................................................................... 18

Adjusting Contrast and Brightness Settings ..................................................................... 18

Adjusting PC Settings....................................................................................................... 18

Adjusting Audio Settings.................................................................................................. 20

Viewing Picture-in-Picture (PIP) Settings........................................................................ 22

C. TV mode Adjustment........................................................................................................ 23

Adjusting the TV Settings................................................................................................. 23

Sound Options................................................................................................................... 24

Adjusting Picture Settings ................................................................................................ 24

Memorizing Channels....................................................................................................... 25

Changing Channels ........................................................................................................... 28

Using Parental Controls .................................................................................................... 28

Setting Up Your Personal ID Number (PIN).................................................................... 29

How to Set up Restrictions Using the "Block Passward" option...................................... 31

How to Set up Restrictions Using the "Block Movie" option .......................................... 33

Viewing Closed Captions ................................................................................................. 35

2005/3/30

下午 01:15

Table of Contents

Need help?

Do you have a question about the LC32D and is the answer not in the manual?

Questions and answers

Summary of Contents for Winbook LC32D

Page 1: Table Of Contents
10. Summary of Remote Control Functions ... 14 11. Controls & Adjustments A. General Adjustments... 15 Turning the LCD TV On and Off ... 15 Viewing the Menus and On-Screen Displays ... 15 Switching between PC/Composite/S-Video/TV/Component Modes ... 16 Switching Language Modes... 16 Setting the Sleep Timer...
Page 2 V32FCBB-U21/M21 2005/3/30 下午 01:15 D. Other Functions ... 36 12. Troubleshooting... 37 13. PC Input Preset Timing Table ... 40 14. Specifications ... 42...
Page 3: General Information
V32FCBB-U21/M21 General Information This 32” wide active matrix TFT (thin film transistor) liquid crystal monitor is designed for use as a stand alone TV as well as a display device for video electronics appliances and personal computers. Important Information Warning: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
Page 4 下午 01:15 Thank You for Choosing This Product Your new LCD TV was built utilizing the latest advancements in television technology. We are proud to offer you a product that will provide convenient, dependable service and enjoyment for years to come.
Page 5: Safety Precautions
V32FCBB-U21/M21 Safety Precautions 1. Cleaning: Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. 2. Water and moisture: Do not use the product near water or areas of high moisture content such as swimming pools, bathtubs or wet basements.
Page 6 V32FCBB-U21/M21 6. Stand: Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product.
Page 7: Features
V32FCBB-U21/M21 Features List of Features Your TV is designed with the latest technology and is a high-performance unit that includes the following special features: Multiple input sources including Antenna terminal, DVI connector, Composite, S-Video, and Component ports. Easy-to-use remote control and on-screen-display (OSD) menu system.
Page 8: Dimensions
V32FCBB-U21/M21 2005/3/30 下午 01:15 Dimension Unit: mm...
Page 9: Ports
V32FCBB-U21/M21 2005/3/30 下午 01:15 Ports...
Page 10 V32FCBB-U21/M21 2005/3/30 下午 01:15 Video Subwoofer Antenna Set Top Box Device Amplifier...
Page 11: Control Buttons
ON. The MAIN POWER switch is located at the bottom-left back of the LCD display (near by Power Inlet). Function Key These buttons control your TV’s basic features, including the on-screen mean. To use advanced features, you must use the remote control. POWER: turn the LCD-TV on or off.
Page 12: Accessories
V32FCBB-U21/M21 2005/3/30 下午 01:15 Accessories User’s manual Remote control & Batteries (AAA x2) Power Cord DVI-D Cable...
Page 13: Remote Control
V32FCBB-U21/M21 2005/3/30 下午 01:15 Remote Control...
Page 14: Summary Of Remote Control Functions
APC button (Automatic Picture Control) SLEEP button C.C. button 2005/3/30 下午 01:15 Turn the TV on or off Switch to TV mode Switch to AV (composite mode) Switch to S-Video mode Switch to CV (component) mode (Y/Pb/Pr) Switch to PC mode (DVI or D-sub) Display the on-screen menu or enter a sub-menu Display the current channel;...
Page 15: Controls & Adjustments
A. General Adjustment Turning the LCD TV On and Off Plug the power cable into the AC-in socket located on the left rear of the LCD TV. Plug the other end into an electrical socket. Press the main Once the main power button is engaged, press the power button on the remote control or use the power button located within the control buttons panel on underside of the TV to turn the TV on.
Page 16: Switching Between Pc/Composite/S-Video/Tv/Component Modes
下午 01:15 1. Turn on the power. 2. Select an input source as described below: button to switch to TV mode. button to switch to PC mode (Analog or Digital). button to switch to AV mode. (Composite) button to switch to S-Video mode.
Page 17: Setting The Sleep Timer
V32FCBB-U21/M21 Setting the Sleep Timer Auto Power Off The TV will automatically power off if no signal is detected for 10 minutes. Adjusting the Volume 2005/3/30 下午 01:15 You can set the Sleep Timer to automatically turn off the LCD TV.
Page 18: Pc Mode Adjustments
V32FCBB-U21/M21 B. PC Mode Adjustment Adjusting the Contrast & Brightness Settings Each viewing mode supports separate adjustments for brightness and contrast levels. PC mode is best viewed with lower brightness and contrast levels as compared to other modes. Adjusting PC Settings 2005/3/30 下午...
Page 19 V32FCBB-U21/M21 2005/3/30 下午 01:15 DIGITAL INPUT 1. Press the PC button twice to set the main display to PC Digital mode. 2. Press the ◁ or ▷ button to select Picture or Window sub-menus for adjustment.
Page 20: Adjusting Audio Settings
V32FCBB-U21/M21 Adjusting Audio Settings 2005/3/30 下午 01:15 1. Press the button to display the main menu. MENU 2. Press the ◁ or ▷ button to move the cursor to the Audio sub-menu. 3. Audio quality can be further adjusted within the Sound Effects sub-menu.
Page 21 V32FCBB-U21/M21 USER: JAZZ: ROCK: 2005/3/30 下午 01:15 POP: VOICE: CLASSIC: 5. Selecting the USER pre-set allows you to manually adjust the frequency response.
Page 22: Viewing Picture-In-Picture (Pip) Settings
V32FCBB-U21/M21 Viewing Picture-in-Picture ( PiP) PiP: While viewing content on the main display, you have the option to select a secondary signal as a sub-display in a picture in picture window. This feature allows you to watch two video sources simultaneously. 2005/3/30 下午...
Page 23: Tv Mode Adjustment
PiP source, wait a moment for the display to update. Note: D-Sub and DVI sources cannot be displayed at the same time. 1. Press the TV button to set the main display to TV mode. Press the Menu button to access TV settings options.
Page 24: Sound Options
Stereo, Mono, or a Separate Audio Program. (SAP audio is usually a foreign-language translation). 1. Press the TV button to set the main display to TV mode. Press the Menu button to access TV settings options.
Page 25: Memorizing Channels
V32FCBB-U21/M21 Memorizing Channels Your TV can memorize and store all of the available channels for both standard broadcast (antenna) and cable channels. After the available channels are memorized press the △ or ▽ button to view stored channels. You can also view any channel (even non-memorized) by directly entering the channel digits via the remote control.
Page 26 V32FCBB-U21/M21 2005/3/30 下午 01:15 4. Press the ◁ or ▷ button to select between Antenna, Cable_STD, Cable_HRC, or Cable_IRC source signals. Storing Channels (Automatic Method) 1. From the tuner input sub-menu, press the △ or ▽ button to select Auto search. 2.
Page 27 V32FCBB-U21/M21 2005/3/30 下午 01:15 Adding and Erasing Channels (Manual Method) 1. From the tuner input sub-menu, press the △ or ▽ button to select Tuner Source. 2. Press the ◁ or ▷ button to select the TUNER CHANNEL. 3. Press the ▽ button to select Edit channels or Edit favorites;...
Page 28: Changing Channels
V32FCBB-U21/M21 Changing Channels This LCD TV turner provides the ability to display up to 125 channels (1 to 125). To select a channel, enter the channel number using 1 to 3 digit numbers. Using Parental Controls The Parental Control feature allows you to block channels from being viewed unless an unlock PIN code is correctly entered.
Page 29: Setting Up Your Personal Id Number (Pin)
V32FCBB-U21/M21 Setting Up Your Personal ID Number (PIN) 1. Press the button . 2. Press the button to display the main menu. MENU 3. Press the ▷ button to select the SETTINGS sub-menu; then Press the ▽ button to select Content blocking.
Page 30 7. Press the △ and ▽ buttons to enter a 6 digit PIN. 8. Press the EXIT button to exit the menu. How to Enable / Disable Parental Controls 1. Press the TV button to set the main display to TV mode. Press the Menu button to access TV settings options.
Page 31: How To Set Up Restrictions Using The "Block Passward" Option
Setting up restrictions using the “BLOCKING PASSWORD” function. The BLOCKING PASSWORD option utilizes the Television ratings system for determining blocked programming. When the parental control lock is enabled, the TV will automatically block any programs that are coded with objectionable ratings.
Page 32 If the channel is set to a restricted channel, the parental controls will automatically block it, and the “ ” icon will appear: 2005/3/30 下午 01:15 7. Under the “BLOCKING TV” screen, press the △ or ▽ button to select a TV category. Press the MENU button to select “lock or unlock”...
Page 33: How To Set Up Restrictions Using The "Block Movie" Option
The BLOCKING MOVIE option utilizes the Motion Picture Association of America (MPAA) ratings system for determining blocked programming. When the parental control lock is enabled, the TV will automatically block any programs that are coded with objectionable ratings. 2005/3/30 下午 01:15 1.
Page 34 V32FCBB-U21/M21 : General audience (no restrictions). : Parental guidance suggested. PG13 : Parents strongly cautioned. : Restricted. Children under 17 should be accompanied by an adult. NC17 : No Children : Adults only under 17. If the channel is set to a restricted channel, the parental controls will automatically block it, and the “...
Page 35: Viewing Closed Captions
V32FCBB-U21/M21 Viewing Closed Captions This LCD TV has the ability to decode and display closed caption content if supported by the program. These captions are usually used for the hearing impaired or for foreign language translations. Most VCR's can record the closed caption signal from television programs. Most pre-recorded commercial videotapes also provide closed captioning as well.
Page 36: Other Functions
˙There are three supported MTS modes: “Mono”, “Stereo” or “SAP” (Secondary Audio Program). ˙This LCD TV has the ability to decode stereo or SAP broadcasts. RESET ˙Under Under PC mode, the reset button restores the following settings to factory values: (Brightness, Contrast, Color, Temp, Volume, Treble, Bass, and Balance) ˙Under Video mode, the reset button restores the following settings to factory values:...
Page 37: Troubleshooting
V32FCBB-U21/M21 Troubleshooting There is no picture or sound. • Make sure the AC adapter is connected. • Verify that there is a valid source signal. • Make sure the correct input mode is selected. • Make sure the master power switch has been turned on. There is no picture from AV.
Page 38 • Check input connections. Picture is light or improperly tinted. • Check the Hue, Saturation and Color adjustments. • Reset the TV to the factory default settings. The picture is too dark. • Select a different APC mode. • Check the PICTURE and BRIGHTNESS adjustments.
Page 39 • Check input connections. The picture is spotted. • There may be interference from other appliances nearby or around the LCD TV. There may be interference between the source cable and the power cable. Make sure they don’t touch. There are stripes on the screen or colors fade.
Page 40: Pc Input Preset Timing Table
V32FCBB-U21/M21 2005/3/30 下午 01:15 PC Input Preset Timing Table...
Page 41 V32FCBB-U21/M21 2005/3/30 下午 01:15...
Page 42: Specifications
Display Area (opening) H x V Pixel Pitch Panel Display colors Contrast Ratio Brightness Viewing Angle Response Time (GTG) Broadcasting System Receiving Channel TV Function Sound System Data Broadcasting Video Input Signal Connection PnP Compatibility PC Input Scanning Frequency (analog) Recommended...
Page 43 V32FCBB-U21/M21 2005/3/30 下午 01:15...
Page 44 V32FCBB-U21/M21 2005/3/30 下午 01:15...
