American Standard Gold 824
Smart Control User Guide
The Gold 824 is an easy-to-
use, programmable control
with a color touch-screen.
When connected with
®
American Standard
Home
you can control your home's
heating and cooling system
and up to 230 separate
Z-Wave™ devices from a
smartphone, PC or tablet
from virtually anywhere.
This guide will help you
con gure and connect your
Gold 824 Smart Control
quickly and easily.
Start using your
new Gold 824
now! See "Start
Here!" on page
3.
012-5060-06C-EN
