BOERPLAY PSTE120.002 Manual

Multi-play equipment
Hide thumbs Also See for PSTE120.002:

Advertisement

Quick Links

Download this manual
Multi-play equipment
PSTE120.002

Advertisement

loading
Need help?

Need help?

Do you have a question about the PSTE120.002 and is the answer not in the manual?

Questions and answers

Related Manuals for BOERPLAY PSTE120.002

Summary of Contents for BOERPLAY PSTE120.002

  • Page 1 Multi-play equipment PSTE120.002...

  • Page 2: Main Dimensions

    Dimensions principales 2,09 m 2,08 m 1,99 m 1,88 m 1,55 m 1,20 m 0,85 m 0,76 m 0,00 m 0,00 m 1,60 m 0,59 m 0,00 m < 0,20 m PST 120 002 © Copyright BOERplay 25-8-2022 Revision: G...
  • Page 3 Zona libre de obstáculos Zone libre d’obstacles 5,36 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacles PST 120 002 © Copyright BOERplay 25-8-2022 Revision: G...
  • Page 4 Bodemplan Bodenplan Plan de superficie Plan de surface 2,96 m 2,25 m 2,65 m Grondmarkering Ground level marker 0,50 m 0,70 m PST 120 002 © Copyright BOERplay 25-8-2022 Revision: G...

  • Page 5: Order Of Assembly

    Rev. Benaming Opmerking Driehoeksvloer 0,59 en 0,95 Grond frame 1,45 Staander 2,3 m Railing L = 1,3 m Wand/Telbollen Klimwand 0,59 m Oploopnet 0,59 m Wiebelbrug 2,20 m Glijbaan 59 cm PST 120 002 © Copyright BOERplay 25-8-2022 Revision: G...
  • Page 6 > 0.60 m < 0,85 m 1,26 m PST 120 002 © Copyright BOERplay 25-8-2022 Revision: G...
  • Page 7 LOGBOOK Type indication Adventure Play Article number PSTE120.002 Product Name Multi-play equipment Maximum fall height 0,6 m Construction year 2023 Certificate 032712 Inspection body TUV Nederland QA BV Ekkersrijt 4401 5692 DL Son Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk...
  • Page 8 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...

  • Page 9: Inspection And Maintenance Intervals

    Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear.
  • Page 10 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
  • Page 12 Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Draadeind+borgm.+ringen+dop M12, L= 260, RVS A2-70 30x30x14 Afstandsbus Driehoeksvloer 0,59 en 0,95 MAP 01 001 © Copyright BOERplay 14-2-2023 Revision:...
